User Manuals for Burst Electronics

Looking for help with a Burst Electronics product? Have you lost your user manual? Download the Burst Electronics manual in which you will find instructions on how to install, use, maintain and service your product. Find your instruction manual using the search button, or by searching for the specific Burst Electronics product in the relevant category.

Choose the category:
Distribution Amplifiers (DA's) - Routers & Switchers - Signal Converters - Logo Generators

Showing: 1-9 productsTotal: 9 products
Burst Electronics HDLG HD SD-SDI Color
Rating: 3 of 5
Burst Electronics HDLG HD SD-SDI Color The HDLG HD/SD-SDI Color Logo Generator from Burst Electronics is a self-contained in-line HD/SD-SDI logo generator. The HD/SD-SDI program video path is a full 10-bit resolution, while the resolution of the logos are 8-bit RGB (24-bit total) bitmap images. These logos can be switched on/off or faded in/out of the program path using either a Window...
Burst Electronics HDSR HD SD SDI
Rating: 4 of 5
Burst Electronics HDSR HD SD SDI The HDSR HD/SD SDI 2-Output Distribution Amplifier from Burst Electronics is a studio quality HD/SD SDI 1 x 2 distribution amplifier with equalized input and selectable reclocked/non-reclocked outputs. Each output can drive up to 330' of HD/SD SDI with embedded audio (Belden 1694). A front panel switch selects between reclocked and non-reclocked o...
Burst Electronics DV-1 Serial Digital to
Rating: 5 of 5
Burst Electronics DV-1 Serial Digital to The DV-1 Serial Digital to Analog Converter from Burst Electronics converts serial digital video into analog video. The output is selectable for composite or Y/C. This converter can also be used as a Full Field Colorbar Generator. NTSC/PAL NTSC pedestal on or off 10-bit internal 4:2:2 270 Mb SMPTE 259M Serial digital input Ju...
Burst Electronics 8-Output Differential Amplifier
Rating: 4 of 5
Burst Electronics 8-Output Differential Amplifier The Burst Electronics 8-Output Distribution Amplifier uses high-speed monolithic operational amplifier technology for high gain stability, low differential gain, and differential phase. Internally regulated bipolar power supplies powered by a 12V external DC power supply provide 5V DC. With a wide bandwidth (33 MHz) and an adjustable gain of &plus...
Burst Electronics VDA-4 Four Output Distribution
Rating: 4 of 5
Burst Electronics VDA-4 Four Output Distribution The Burst Electronics' VDA-4 Four Output Distribution Amplifier offers wide bandwidth and high gain in a compact enclosure that allows it to be used on a tabletop or in an optional rackmount. Featuring internal regulated bipolar supplies and looping input, the VDA-4 also offers a rear panel switch for selecting an internal 75 Ohm termination resis...
Burst Electronics VS4x1 Four Input Active
Rating: 4 of 5
Burst Electronics VS4x1 Four Input Active The Burst Electronics VS4x1 4-input Active Switcher is a vertical interval video switcher with 4 inputs and 1 output and features digital logic to restrain selection of an idle input (no video). Jump-free switching between genlocked sources is achieved by DC-clamped inputs (back porch) and DC-clamped output. Besides allowing selection of only acti...
Burst Electronics AV4X1P Passive AV Switcher
Rating: 4 of 5
Burst Electronics AV4X1P Passive AV Switcher The AV4X1P Passive AV Switcher from Burst Electronics allows you to switch between (4) audio and video input sources on (1) output device. Video is managed on BNC connectors while audio is managed on RCA connectors. Source selection can be controlled with the unit's front-panel pushbuttons. This unit uses passive power from the signal connections ...
Burst Electronics DSR8x1 SD HD-SDI Switcher
Rating: 4.5 of 5
Burst Electronics DSR8x1 SD HD-SDI Switcher The DSR8x1 SD/HD-SDI Switcher from Burst Electronics is a routing switcher that accepts (8) SD/HD-SDI source signals and selectively routes them to (1) output display. Use this convenient unit to switch between SD/HD-SDI video devices without the need to repeatedly connect and disconnect equipment. The switcher can be controlled via its front-pa...
Burst Electronics DSR4x1 SD HD-SDI Switcher
Rating: 3 of 5
Burst Electronics DSR4x1 SD HD-SDI Switcher The DSR4x1 SD/HD-SDI Switcher from Burst Electronics is a routing switcher that accepts (4) SD/HD-SDI source signals and selectively routes them to (1) output display. Use this convenient unit to switch between SD/HD-SDI video devices without the need to repeatedly connect and disconnect equipment. The switcher can be controlled via its front-pa...
Showing: 1-9 productsTotal: 9 products
