Audix VX10 - Handheld Cardioid Condenser

Search your instruction manual in PDF to download

User Manual for Audix VX10 - Handheld Cardioid Condenser Microphone

Click to enlarge the picture
Audix VX10 - Handheld Cardioid Condenser Microphone Contents of the user manual for the Audix VX10 - Handheld Cardioid Condenser
  • Product category: Handheld Performance Microphones Audix
  • Brand: Audix
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for Audix Handheld Performance Microphones

Audix VX10 - Handheld Cardioid Condenser Microphone Audix VX10 - Handheld Cardioid Condenser Microphone Audix VX10 - Handheld Cardioid Condenser Microphone Audix VX10 - Handheld Cardioid Condenser Microphone Audix VX10 - Handheld Cardioid Condenser Microphone
User manual for the Audix VX10 - Handheld Cardioid Condenser contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any Audix product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official Audix user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a Audix product will considerably shorten its lifespan!



Product description

The Audix VX-10 is a professional handheld condenser microphone designed for stage performances and broadcast applications. The wide frequency response of 40Hz to 20kHz enables the microphone to accurately reproduce signals with great detail. The result is the clarity necessary for professional performances without unwanted low frequency noise. The cardioid polar pattern effectively rejects signal at the sides of the capsule, minimizing ambient noise and reducing feed-back. The VX-10 operates on 48V to 52V phantom power and low noise electronic circuitry with balanced output prevent interference from radio frequencies. The rugged enclosure is designed to withstand the rigors of heavy use.
    Wide Frequency Response
  • The wide frequency response provides detailed signal reproduction and minimizes noise and unwanted "boominess".
    Cardioid Polar Pattern
  • The cardioid polar pattern provides a focused pick up pattern and eliminates noise and audio at the off-axis sections of the microphone.
UPC: 687471201008 In the Box Audix VX10 - Handheld Cardioid Condenser Microphone
  • 3-Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the Audix VX10 - Handheld Cardioid Condenser Microphone in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    Audix VX10 Specs

    Transducer Condenser
    Polar Pattern Cardioid
    Frequency Response 40Hz to 20kHz
    Dynamic Range (Typical) Not Specified by Manufacturer
    Signal-to-Noise Ratio 73dB
    Maximum Input Sound Level 138dB
    Power Requirements 48V to 52V Phantom Power
    Output Impedance 250 Ohms
    Output Connectors 3-pin XLR male
    Pad No
    Low Frequency Roll-Off No
    Dimensions 7.7 x 1.97" (180 x 50mm) (Length x Diameter)
    Weight 11.24oz (318.6g)
    Package Weight 2.1 lb
    Box Dimensions (LxWxH) 9.6 x 5.8 x 3.9"
