User Manual for Acer Predator Z1 Z271T01 Tbmiphz 27" 16:9 Curved 144 Hz G-SYNC LCD Monitor with Tobii Eye Tracking Technology Click to enlarge the picture
Contents of the user manual for the Acer Predator Z1 Z271T01 Tbmiphz 27"
- Product category: Computer Monitors Acer
- Brand: Acer
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Acer Computer Monitors
 |
User manual for the Acer Predator Z1 Z271T01 Tbmiphz 27" contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Acer product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Acer user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Acer product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More Experience fast and fluid gaming with the Predator Z1 Z271T01 Tbmiphz 27" 16:9 Curved 144 Hz G-SYNC LCD Monitor from Acer. This monitor is built with a Vertical Alignment (VA) panel that provides you with wide 178° viewing angles and vivid colors. The 1800R curvature of the display wraps around your field of view, putting you right in the middle of the action. Furthermore, it supports NVIDIA G-SYNC technology, which synchronizes the graphics card with the display to output content at variable refresh rates, eliminating screen stuttering and tearing. A 144 Hz refresh rate will also add to a smoother gaming experience if the graphics card is capable. The Predator Z1 Z271T01 has a 1920 x 1080 Full HD resolution for crisp and clear pictures. Combined with a 3000:1 static contrast ratio, 300 cd/m² brightness rating, support for 16.7 million colors, and a 4 ms response time, you'll be able to enjoy vivid, lag-free content reproduction with darker blacks and brighter bright colors. Connect this display to your system via HDMI or DisplayPort and then adjust it your viewing preference.
- Tobii Eye Tracking Technology
- The Predator Z271 with Tobii Eye Tracking is designed for simulation and action adventure games. The eye tracking technology combined with the curved 1800R screen provides a more immersive gaming experience.
- NVIDIA G-SYNC Technology
- NVIDIA G-SYNC Technology syncs the display's refresh rate with the graphics card's frame rate output to reduce screen tearing, stuttering, and ghosting for a smoother gameplay experience.
- 144 Hz Refresh Rate
- The refresh rate is how many times per second a display refreshes its image. With a faster refresh rate, you'll be able to enjoy less blurring, screen tearing, and a more responsive gaming experience. Please note that refresh rate is not to be confused with frame rate, and having a fast refresh rate will not improve your experience unless you have a capable graphics card.
- Acer VisionCare Technologies
- Acer VisionCare Technologies include Acer Flicker-less, BlueLightShield, ComfyView, and Low-dimming technologies to help reduce eye strain caused by long gaming sessions.
UPC: 191114094808 In the Box Acer Predator Z1 Z271T01 Tbmiphz 27" 16:9 Curved 144 Hz G-SYNC LCD Monitor with Tobii Eye Tracking Technology Power Cable HDMI Cable DisplayPort Cable USB 3.0 Cable Limited 3-Year Warranty User Manual PDF 1.6mb Table of Contents
|
Upload User Manual
Have you got an user manual for the Acer Predator Z1 Z271T01 Tbmiphz 27" 16:9 Curved 144 Hz G-SYNC LCD Monitor with Tobii Eye Tracking Technology in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAcer Z271 Specs | Viewable Area | 27" / 68.58 cm
1800R curved display
16:9 aspect ratio | | Eye Tracking | Integrated Tobii eye tracking technology | | Panel Type | VA (vertical alignment) | | Resolution | 1920 x 1080 | | Refresh Rate | 144 Hz - using DisplayPort
60 Hz - using HDMI port | | Pixel Pitch | 0.3114 | | Brightness | 300 cd/m² | | Contrast Ratio | 3000:1 | | Anti-Glare Panel | Yes | | Response Time | 4 ms | | Colors | 16.7 million | | Viewing Angles (H/V) | 178°/178° | | User Controls | Power on/off button | | Signal Inputs | 1 x DisplayPort
1 x HDMI | | Speakers | 2 x 7 W speakers | | Ports | 4 x USB 3.0 ports
1 x AC power input | | Power | Normal Operation: <27 watts
Off (power-save): <1 watt
100-240 VAC; 50/60 Hz | | Certifications | UL, cUL, FCC Class B, CE, TUV/GS, VCCI, RoHS, MPRII, TCO, ENERGY STAR | | Ergonomics | Tilt: -5 to 25°
Height Adjustment: 5" / 127 mm
Swivel: ±30° | | VESA Hole Configuration | 100 x 100 mm | | Dimensions | 24.37 x 15.71-20.44 x 10.57" / 319 x 399.1-519.1 x 268.4 mm | | Weight | 16.76 lb / 7.6 kg | | | | Package Weight | 26.0 lb | | Box Dimensions (LxWxH) | 28.0 x 20.2 x 12.6" |
Rating90% users recommend this product to others. And what about you?
This product has already been rated by 33 owners. Add your rating and experience with the product.
