Product description The black 6x21 G-Force DX 1300 ARC Laser Rangefinder from Bushnell is equipped with an eye-safe IR laser that measures distances from 5 to 1300 yards, and an integrated inclinometer to measure the relative angle to a target up to 90° uphill or downhill. Designed for bow and rifle shooters, it is packed with a variety of technologies to get them precisely on target. Bushnell's proprietary Angle Range Compensation (ARC) system gives rifle hunters ballistic drop compensation information, using such variables as distance, angle, caliber and ammo load along with the appropriate hold over/under. For the bow hunter, the system will display the line of sight distance, degree of elevation, and adjusted horizontal distance from 10-99 yd/m so the hunter can adjust the shot.Designed for those who need quick reactions and readings, the G-Force employs a simple two-button interface and an in-view display intended to give clear and concise information without cluttering the field of view. A simple reticle and icons combined with an adjustable intensity helps to streamline the ranging process. The lightweight and durable chassis is wrapped in a slip-resistant rubber armoring, while the interior is nitrogen-filled and O-ring sealed to be waterproof and fogproof in all weather conditions. For those who are staying in one place, such on tree stands or in blinds, there is a 1/4"-20 tripod mount; and the rangefinder is also compatible with Bushnell's proprietary Magnetic Attachment System. - Optical Performance
-
- 6x magnification
- 21mm objective
- Compact roof prism optical path
- Fully multi-coated optics improve light transmission, color rendition, and contrast
- RainGuard HD lens coatings: Permanent coatings that bead moisture off lens and prevents exterior fogging for clearer views
- 393' field of view at 1000 yards
- Comfortable 3.5mm exit pupil
- Long 16mm eye relief
- Rangefinder
-
- Class 1 eye-safe IR laser
- Spot and scan modes
- Range displayed in yards or meters
- Range:
- 300 yards to a reflective target
- 900 yards to trees
- 500 yards to a deer
- ±1 yd/m accuracy
- Integrated inclinometer:
- Measures relative angle to target
- ±90° angle range, ±0.1° accuracy
- Used to calculate adjusted range for accurate holdover/under
- 2nd Gen E.S.P. (Extreme. Speed. Precision.) processor
- Five-times faster than the previous version
- Allows displayed range down to 1/10 of a yd/m
- Increased precision with shorter processing time
- Technologies
-
- Angle Range Compensation (ARC):
- Calculates adjusted range based on line-of-sight distance and angle of shot
- Bow mode:
- Displays line of sight distance, degree of elevation, and true horizontal distance from 10-99 yd/m with max ±90° angle
- Rifle mode:
- Calculates the bullet drop to the target in inches, centimeters or MOA
- Enter caliber and ammo load being used to calculate precise BDC
- Preset ballistic groups for center fire and black powder/muzzleloader rifles
- Regular mode: Displays line-of-sight distance only without angle or BDC compensation
- Selective Targeting Modes:
- Standard mode:
- Spot: Range to a single stationary target
- Scan: Range to a single moving target or multiple targets continuously
- Bull's-eye mode:
- Allows easy acquisition of small targets
- Eliminates accidentally ranging to background objects
- If multiple subjects are detected, the system will display range to the closest one
- Brush mode:
- Allows objects such as brush and tree branches to be ignored so that the distance to only background objects are displayed
- If multiple subjects are detected, the system will display range to the furthest one
- Variable Sight-In (VSI):
- Available only when in rifle mode
- Choose from four sight-in distances: 100/150/200/300 yd/m
- Provides holdover/ BDC in inches, centimeters, MOA, or Mils
- Use and Handling
-
- Center aiming circle with crosshair reticle
- Crosshairs visible only when actively ranging to keep view uncluttered
- Crosshairs blink to indicate when laser is firing
- Focusing ring around eyepiece
- Vivid Display Technology:
- Red display won't affect vision in low light such as at dawn and dusk
- In-view display for all information including range, BDC and battery life
- Four selectable intensity levels
- Ranging information goes away after 3 seconds to preserve battery life
- Intuitive two-button control: Power and Mode
- Compatible with Bushnell's proprietary Magnetic Attachment System
- Runs on one CR2 battery
- Construction Details
-
- Lightweight and durable aluminum alloy chassis
- Slip-resistant black rubber armoring
- Pebble-textured grip for more secure handling in cold and wet weather
- Nitrogen-filled housing for water and fogproof performance
- Secure Posi-Thread battery door maintains waterproof seal
- 1/4"-20 tripod mount
- Lightweight: 8 ounces
UPC: 029757024602 In the Box Bushnell 6x21 G-Force DX 1300 ARC Laser Rangefinder (Black) CR2 Battery Carrying Case Wrist Strap Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Bushnell 6x21 G-Force DX 1300 ARC Laser Rangefinder in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersBushnell 202460 Specs | Prism Type | Roof | | Magnification | 6x | | Objective Lens Diameter | 21mm | | Field of View | 393.0' @ 1000 yd / 131.0 m @ 1000 m | | Laser Type | Class 1 eye-safe IR | | Metering Range | 5 - 1300 yd / 5 - 1189 m | | Metering Accuracy | 5-199 yd, ±½ yd / 5-182 m, ±½ m
200-1300 yd, ±1 yd / 183-1189 m, ±1 m | | Exit Pupil Diameter | 3.5 mm | | Eye Relief | 16 mm | | Weatherproofing | Nitrogen filled, water and fogproof | | Tripod Socket | 1/4"-20 | | Power Source | 1 x CR2 lithium battery | | Dimensions | 4.0 x 2.9 x 1.3" / 10.2 x 7.4 x 3.3 cm | | Weight | 8.0 oz / 226.8 g | | | | Package Weight | 0.95 lb | | Box Dimensions (LxWxH) | 5.591 x 5.039 x 2.913" |
