User Manual for ACTi PPSW-0101 8-Port 802.3at Managed PoE Data Switch Click to enlarge the picture
Contents of the user manual for the ACTi PPSW-0101 8-Port 802.3at Managed PoE
- Product category: Network Switches, Bridges & Hubs ACTi
- Brand: ACTi
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ACTi Network Switches, Bridges & Hubs
|
User manual for the ACTi PPSW-0101 8-Port 802.3at Managed PoE contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ACTi product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ACTi user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ACTi product will considerably shorten its lifespan!
|
Product description Provided by third party: The GS-4210-8P2T2S is the new generation of PLANET Managed Gigabit PoE+ Switch featuring PLANET intelligent PoE functions to improve the availability of critical business applications. It provides IPv6/IPv4 dual stack management and built-in L2/L4 Gigabit Switching engine along with 8 10/100/1000Base-T ports featuring 30-watt 802.3at PoE+, 2 additional Gigabit copper ports and another 2 extra 100/1000Base-X SFP fiber slots. Each of the eight Gigabit ports provides 30 watts of power, which means a total power budget of up to 240 watts can be utilized simultaneously without considering the different types of PoE applications being employed. It provides a quick, safe and cost-effective Power over Ethernet network solution to IP security surveillance for small businesses and enterprises.
- Key Features
-
- A perfect managed PoE+ switch with full PoE+ power budget
- Intelligent powered device alive-check
- Scheduled power recycling
- PoE schedule for energy saving
- PoE usage monitoring
- Environment-friendly, smart fan design for silent operation
- IPv6 / IPv4 dual stack
- Robust layer 2 features
- Efficient traffic control
- Powerful security
- Advanced network security
- Friendly and secure management
- Flexibility and long-distance extension solution
- Intelligent SFP diagnosis mechanism
In the Box ACTi PPSW-0101 8-Port 802.3at Managed PoE Data Switch (200W PoE Power Budget) Planet GS-4210-8P2T2S 4 rubber feet, 2 port dust covers(SFP) Serial adapter Rack mounting kit Table of Contents
|
Upload User Manual
Have you got an user manual for the ACTi PPSW-0101 8-Port 802.3at Managed PoE Data Switch in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersACTi PPSW-0101 Specs | | | Device Type | Switch - 8 ports - managed | | Enclosure Type | Desktop, rack-mountable 1U | | Subtype | Gigabit Ethernet | | Ports | 8 x 10/100/1000 (PoE+) + 2 x 10/100/1000 + 2 x SFP | | Power Over Ethernet (PoE) | PoE+ | | PoE Budget | 200 W | | Routing Protocol | IGMPv2, IGMPv3, MLDv2, MLD | | Remote Management Protocol | SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, SSH | | Encryption Algorithm | SSL | | Authentication Method | Secure Shell (SSH), RADIUS, TACACS+ | | Features | VLAN support, DoS attack prevention, port mirroring, MAC address filtering, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), IP-MAC binding, IP source guard, ARP inspection | | Compliant Standards | IEEE 802.3af, IEEE 802.1x, IEEE 802.3at | | Status Indicators | Power, PoE, link/activity | | | | Interfaces | 8 x 1000Base-T RJ-45 PoE+ - 30 W
2 x 1000Base-T RJ-45
2 x 1000Base-X SFP
1 x console RJ-45 | | | | Power Device | Internal power supply | | Voltage Required | AC 120/230 V (50/60 Hz) | | Power Consumption Operational | 330 Watt | | | | Included Accessories | 4 rubber feet, 2-port dust covers(SFP) | | Cables Included | 1 x serial adapter | | Rack Mounting Kit | Included | | Compliant Standards | FCC Part 15 A | | | | Width | 13 in | | Depth | 7.9 in | | Height | 1.8 in | | Weight | 4.41 lbs | | | | Min Operating Temperature | 32
