User Manual for ACTi Q950 6MP Outdoor Video Door Station with Night Vision Click to enlarge the picture
Contents of the user manual for the ACTi Q950 6MP Outdoor Video Door
- Product category: Door Stations ACTi
- Brand: ACTi
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ACTi Door Stations
|
User manual for the ACTi Q950 6MP Outdoor Video Door contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ACTi product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ACTi user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ACTi product will considerably shorten its lifespan!
|
Product description Monitor an entrance or access point with the Q950 6MP Outdoor Video Door Station with Night Vision from ACTi. Its 6MP 1/1.8" progressive scan CMOS sensor allows the door station to capture 3072 x 2048 resolution video at up to 20 fps both during the day and at night thanks to a mechanical IR cut filter and IR LEDs. Its wide, 198.5° field of view provides a view of an entire area with its 1.65mm fisheye lens. With RFID card compatibility, you can grant access to entrances with RFID cards as well as facial recognition for added security. Communicate with visitors with the built-in microphone and speaker. Enclosed in an IP66- and IK09-rated housing, the door station is protected from dust, water, and impact, making it suitable for use outdoors and in high-risk areas. The microSD slot allows for local storage via a microSD card (available separately). - Video door station with doorbell button
- 6MP camera captures 3072 x 2048 resolution video at up to 20 fps
- Mechanical IR cut filter and IR LEDs for night vision up to 16'
- 1.65mm fisheye lens has a 198.5° field of view to see the entire area in front of the door
- RFID reader for 13.56 MHz smart card compatibility
- Built-in PIR sensor to detect motion
- Wide dynamic range up to 130dB and 2D/3D-DNR for increased image clarity and accuracy
- VMS-based analytics with software (available separately)
- Two-way audio communication via the built-in microphone and speaker
- microSD card slot for local storage
- RJ45 Ethernet connection with PoE
- IP66-rated for outdoor use
- IK09-rated for vandal resistance
UPC: 888034009554 In the Box ACTi Q950 6MP Outdoor Video Door Station with Night Vision RFID Card Drill Template Hex Screwdriver Mounting Hardware 2 x 2-Pin Terminal Blocks 5-Pin Terminal Block 6-Pin Terminal Block Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the ACTi Q950 6MP Outdoor Video Door Station with Night Vision in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersACTi Q950 Specs | Maximum Resolution | 6 MP | Image Sensor | 1/1.8" progressive scan CMOS sensor | Effective Pixels | 3096 x 2080 (6.44 MP) | Minimum Illumination | Color: 0.1 lux at f/2.8 with 30 IRE, 2400K B&W: 0 lux at f/2.8 with IR LED on | Day/Night | Mechanical IR cut filter | IR LED Range | Up to 16.4' (5 m) | Horizontal Resolution | 1800 TVL | S/N Ratio | 56 dB | | Focal Length | 1.65mm fixed | Aperture | f/2.8 | Iris | Fixed | Focus | Fixed | Lens Mount | Board mount | Field of View | Horizontal: 198.5° | | Compression | H.264 (baseline, main, high profile), MJPEG | View Mode | Fisheye, dewarped | Resolutions Supported | Fisheye View: 20 fps at 3072 x 2048 30 fps at 2048 x 2048 20 fps at 1280 x 960 30 fps at 1024 x 768 30 fps at 800 x 600 30 fps at 640 x 480
Dewarped View: 30 fps at 1920 x 1080 30 fps at 1280 x 720 30 fps at 640 x 480 | Multi-Streaming | Simultaneous triple streams based on three configurations | Bit Rate | 128 kbps to 12 Mbps (per stream) | Bit Rate Mode | Constant, variable | Wide Dynamic Range | Up to 130 dB | Image Enhancement | White balance, brightness, contrast, sharpness, automatic gain control, flickerless, defogging | Digital Noise Reduction | 2D- and 3D-DNR | Privacy Masking | 8 configurable regions | Analytics | Built-In: Tamper, shock detection VMS-Based Analytics: Object counting, people counting, face detection, object based motion detection, tamper, line crossing, enter area, missing object, unattended object, smoke detection, heat map, dwell time, direction detection, license plate recognition, people queue management Note: VMS-based analytics require a computer-based or standalone IVS or ALPR Server (available separately). | | Type | Two-way with built-in microphone and speaker Line out | Audio Compression | 8 kHz, 16-bit encoding, mono, PCM, G.711 | | Network Protocols | IPv4/v6, TCP, UDP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, NTP, RTP, RTSP, RTCP, SMTP, FTP, IGMP, ICMP, ARP, Bonjour, UPnP, QoS, SNMP, IEEE 802.1X | Ethernet Port | 1 x RJ45 connector | Security | IP address filtering, HTTPS encryption, password-protected user level, anonymous login, IEEE 802.1X network access control | | Event Trigger | PIR sensor, push button activation, RFID detection, sound detection, tampering detection | Event Response | Notify control center, change camera settings, command other devices, email notification with snapshots, save video to local storage, upload video or snapshot to FTP server, activate external device through digital output | | Frequency | 13.56 MHz | Standards | ISO/IEC 14443-3 (Type A/B), ISO/IEC 15693, ISO/IEC 18000-3M1, NFC Forum (Type 1/2/3/4) | | Unified Solution | Fully compatible with ACTi software | GPS | Position: Manual setting | ONVIF Conformance | Profiles S and G | Compliance | GB828181 | Web Browser Support | Microsoft Internet Explorer 9 and later, Mozilla Firefox with VLC, Google Chrome with VLC, Apple Safari with QuickTime | Firmware Upgrade | Auto | | Serial Port | 1 x RS-485/RS-422 | Memory Card Support | microSDHC/XC cards (available separately) | Digital Input/Output | 1/1 | | Power Source | 12 VDC, PoE Class 3 (IEEE 802.3af) | Power Consumption | PoE: 12.95 W | IP Rating | IP66 | IK Rating | IK09 | Approvals | CE, FCC, IP66, IK09, NEMA 4X | Mount Type | Surface, gang box | Starting Temperature | -40 to 122°F (-40 to 50°C) | Operating Temperature | -40 to 122°F (-40 to 50°C) | Dimensions | 7.0 x 4.3 x 1.9" (17.8 x 11.0 x 4.8 cm) | Weight | 1.52 lb (689 g) |
