Adder CCS-PRO4 Command & Control Switch

Search your instruction manual in PDF to download

User Manual for Adder CCS-PRO4 Command & Control Switch

Click to enlarge the picture
Adder CCS-PRO4 Command & Control Switch Contents of the user manual for the Adder CCS-PRO4 Command & Control Switch
  • Product category: KVM Switches Adder
  • Brand: Adder
  • Description and content of package
  • Technical information and basic settings
  • Frequently asked questions – FAQ
  • Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
  • Authorized service for Adder KVM Switches

Adder CCS-PRO4 Command & Control Switch Adder CCS-PRO4 Command & Control Switch Adder CCS-PRO4 Command & Control Switch
User manual for the Adder CCS-PRO4 Command & Control Switch contain basic instructions that need to be followed during installation and operation. Before starting your appliance, the user manual should be read through carefully. Follow all the safety instructions and warnings, and be guided by the given recommendations. User manual is an integral part of any Adder product, and if it is sold or transferred, they should be handed over jointly with the product. Following the instructions for use is an essential prerequisite for protecting health and property during use, as well as recognition of liability on the part of the manufacturer for possible defects should you make a warranty claim. Download an official Adder user manual in which you will find instructions on how to install, use, maintain and service your product.

And do not forget – unsuitable use of a Adder product will considerably shorten its lifespan!



Product description

Multi-Monitors: Maximizing Multitasking Read More tfuecyvzsubefdcyuccfstq Interact with up to four computers using a single mouse and keyboard with the CCS-PRO4 Command & Control Switch from Adder. Users will be able to select the computer they wish to control simply by moving the mouse across the border of the associated display, thus selecting the computer they wish to operate. This helps users operate multiple desktops within a workspace that occupies less area. No software is required for single-screen computers, and optional interactive light modules help users identify which screen is currently active. The CCS-PRO4 Command & Control Switch is compatible with SunOS, Windows, and Mac operating systems. It is well-suited for air traffic control & management, banking, broadcast, command & control, defense, government/federal, and medical industries. Included is a power adapter that operates using 100-240 VAC at 50/60 Hz and a power cord.

General Features

    Seamless Switching with Adder Free-Flow Technology
  • Free-Flow allows users to automatically switch between target computers simply by moving the mouse pointer from screen to screen. Unlike software-only variants, no software or networking is required on your mission-critical computers for Free-Flow to work.
    Improved Desk Ergonomics
  • With only one keyboard and mouse required to operate up to four computer systems, your desk space can be made more ergonomically effective, which also reduces the time taken for operators to multiplex to different systems.
    Multi-Monitor Free-Flow
  • The system can support up to eight monitors per computer. To enable Free-Flow on multi-monitor computers, a driver must be installed on the target computer. This feature is currently available for Windows computers only.
    External Control Options
  • The unit can be controlled and switched via hotkeys, mouse clicks, Ethernet, RS232, or a remote 3-button mouse. With the open API, the unit can be easily set up and integrated into 3rd-party systems.
    Instant Switching with True USB Emulation
  • Adder's True USB Emulation technology allows you to use the extra function keys, wheels, buttons, and controls on your peripherals without sacrificing switching times.
    Independent Simultaneous Device Selection
  • Switching options enable you to use the keyboard and mouse on one computer while your USB peripherals and speakers are independently connected to different computers. You can, of course, still switch all the connected devices to any one of the connected computers.
    Screen Illumination Module
  • The CCS-XB illumination module is an optional accessory that connects to the CCS-PRO4. It gives users the option to have a LED indicator positioned on each screen to identify which screen is currently controlling. The color and intensity can be controlled for each screen. A maximum of ten LED indicators can be supported.
    Redundant Power
  • For mission critical applications, dual power inlets are now available.
In the Box Adder CCS-PRO4 Command & Control Switch
  • Power Adapter with Locking Connector
  • Power Cord
  • 4 x Adhesive Rubber Feet
  • Limited 2-Year Warranty
  • Table of Contents




    Upload User Manual

    Have you got an user manual for the Adder CCS-PRO4 Command & Control Switch in electronic form? Please send it to us and help us expand our library of instruction manuals. Thank you, too, on behalf of other users.

    To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
    Upload PDF user manual Upload DOC user manual
    Please enter here the link to the user manual of this product:





    OR

    Enter here the file with the user manual of this product from your computer/phone:
    (60MB max; Permitted formats: PDF)

    0%


    Technical parameters

    Adder CCS-PRO4-US Specs

    CPU Connections 4 x USB 2.0 Type-B
    4 x 3.5 mm Microphone
    Console Connections 4 x USB 2.0 Type-A
    1 x 3.5 mm Audio-Out
    Control Connections 1 x RJ45
    1 x RJ50
    Operating System Support Windows, macOS/OS X
    AC Input Power 100 to 240 VAC, 50 / 60 Hz at 0.7 A
    DC Input Power 12 VDC at 0.67 A
    Dimensions 11.4 x 1.2 x 5.1" / 289.6 x 30.5 x 129.5 mm
    Weight 2 lb / 0.9 kg
    Package Weight 3.7 lb
    Box Dimensions (LxWxH) 13.7 x 12.8 x 3.7"
