User Manual for AJA HD10CEA SD HD-SDI to Analog Audio Video Converter Click to enlarge the picture
Contents of the user manual for the AJA HD10CEA SD HD-SDI to Analog
- Product category: Signal Converters AJA
- Brand: AJA
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for AJA Signal Converters
|
User manual for the AJA HD10CEA SD HD-SDI to Analog contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any AJA product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official AJA user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a AJA product will considerably shorten its lifespan!
|
Product description AJA's HD10CEA SD/HD-SDI to Analog Audio / Video Converter is a miniature monitoring solution that converts SD or HD SDI video with embedded audio to analog video and 4-channel balanced analog audio. SD-SDI video can be configured to output YPbPr, RGB or YC, and HD-SDI to YPbPr or RGB. Analog audio outputs are balanced and can be selected from group 1 to 4. A breakout cable with 25-pin D-sub connectors for the analog outputs is included and all configuration for conversion, for both video and audio, is done by external dipswitch selection. The converter also features two loop-thru SDI/HD-SDI outputs. -
- SD/HD-SDI to analog audio and video converter
- Analog output breakout cable with 25-pin D-sub connectors included
- SDI with embedded audio input
- SD-SDI outputs to YPbPr, RGB, composite or YC
- HD-SDI outputs to YPbPr or RGB
- 4-channel balanced analog audio output
- All conversion configuration is done by external dipswitch selection
- 2 equalized, loop-through SD/HD-SDI outputs
- Selectable audio channel pair/group
UPC: 812321030211 In the Box AJA HD10CEA SD/HD-SDI to Analog Audio / Video Converter Breakout Cable Power Supply Limited 5-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the AJA HD10CEA SD HD-SDI to Analog Audio Video Converter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAJA HD10CEA Specs | Inputs | 1x SD/HD-SDI with embedded audio | | Outputs | SD video: YPbPr (SMPTE, EBU-N10, Betacam), RGB, YC (S-Video), NTSC, PAL
HD video: YPbPr, RGB
Audio: 4-channel balanced
Video/audio outputs on 25-pin D-sub connectors
2x SD/HD-SDI equalized loop-through | | User Controls | External dipswitch
Video format
Pedestal
H/V blanking
Audio group 1 - 4
Audio level (adjustable via switch selection): +24, +18, +15, +12 dBu, full scale digital | | Power | +5-18 V DC, regulated, 4 watts
Included power supply:
100-240v, 50/60Hz universal input
+5V DC regulated output
7.5 watt capacity | | Dimensions | 5.8 x 3.1 x 1" (14.7 x 8 x 2.5 cm) | | | | Package Weight | 2.55 lb | | Box Dimensions (LxWxH) | 9.8 x 7.3 x 2.9" |
