User Manual for AJA JPEG 2000 IP Video & Audio to HDMI Converter Click to enlarge the picture
Contents of the user manual for the AJA JPEG 2000 IP Video &
- Product category: Signal Converters AJA
- Brand: AJA
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for AJA Signal Converters
|
User manual for the AJA JPEG 2000 IP Video & contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any AJA product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official AJA user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a AJA product will considerably shorten its lifespan!
|
Product description Provided by third party: Bridging JPEG 2000 over IP to HDMI, the IPR-1G-HDMI is a VSF TR-01 to HDMI receiver suited for point of use applications including source monitoring, digital signage, and video walls. The IPR-1G-HDMI decodes VSF TR-01 JPEG 2000 streams then formats the data for output on a full size HDMI interface. The audio associated with the video stream is extracted, synchronized, and then embedded into the HDMI signal as well as output on an analog RCA audio interface.
- Key Features
-
- Compact and portable
- Universal power supply
- Compact and portable
- AJA mini-converters are small enough to fit behind a monitor, in the back of a rack or directly on a camera rig. A locking power connector can't accidentally pull loose and an optional P-TAP power cable allows for battery power in remote locations.
- Universal power supply
- All AJA Mini-Converters ship with a universal power supply that includes international plug connections for use around the world.
UPC: 812321030570 Table of Contents
|
Upload User Manual
Have you got an user manual for the AJA JPEG 2000 IP Video & Audio to HDMI Converter in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAJA IPR-1G-HDMI Specs | | | Type | JPEG 2000 audio/video over IP to HDMI Converter | | Width | 5.5 in | | Depth | 4.5 in | | Height | 1 in | | Weight | 10.58 oz | | | | Nominal Voltage | AC 120/230 V | | Frequency | 50/60 Hz | | Max Power Consumption | 12 W | | Low Voltage Power | DC 5 - 20 V | | | | Kit Content | (1) x power adapter | | | | Terminals | (1) x audio line-out - RCA x 2
(1) x HDMI output - 19 pin HDMI Type A
(1) x USB 2.0 - mini-USB Type B
(1) x network - RJ-45
(1) x remote control bus - RJ-45 | | | | Min Operating Temperature | 32
