User Manual for AKG PCC-170SWO Supercardioid Boundary Layer Microphone with Remote Sensing MOS Switch Click to enlarge the picture
Contents of the user manual for the AKG PCC-170SWO Supercardioid Boundary Layer Microphone
- Product category: Boundary Microphones AKG
- Brand: AKG
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for AKG Boundary Microphones
|
User manual for the AKG PCC-170SWO Supercardioid Boundary Layer Microphone contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any AKG product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official AKG user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a AKG product will considerably shorten its lifespan!
|
Product description The PCC-170SWO from AKG is a surface-mounted supercardioid boundary layer microphone of professional quality suitable for boardrooms, churches, courtrooms, and council chambers. Because of its highly directional pickup pattern, the PCC-170SWO minimizes background noise and feedback.
The PCC-170SWO has a silent-operating membrane switch which is normally off. The switch can be configured for touch on/off, momentary on or momentary off operation. This configuration is set by a bottom-mounted DIP switch. A high intensity LED lights when the unit is on. The PCC-170SWO is intended for multiple microphone use on a conference table where each person wants control of his or her microphone.
A pair of extra leads in the microphone cable allows isolated remote sensing of the microphone switch closure. In a typical distance-learning application, a video camera would track to the person who switched on the microphone. The microphone can be set to be always on. In this mode, the switch only activates the remote sensing and LED. This is useful when using an external gated mixer (automatic mixer). Remote sensing is done by a patented opto-coupled MOS switching circuit. At the remote-sensing leads, the resistance goes low when the mic is on.
Since the microphone capsule is placed on a boundary or surface, direct and reflected sounds arrive at the diaphragm in-phase. This coherent addition of direct and reflected waves increases sensitivity 6 dB and prevents phase cancellations. The microphone capsule is small enough to ensure phase coherency up to the highest frequencies in the audible spectrum, resulting in a wide, smooth frequency response free of phase interference. Clarity and reach are also enhanced.
Self-contained electronics eliminate the need for an in-line preamp. Powered by 12 - 48V phantom power, the PCC-170SWO has a low-impedance balanced output which permits long cable runs without hum pickup or high-frequency loss. Self-noise is low and sensitivity is very high and an RFI suppression is included. A bass-tilt switch allows the user to tailor the low-end response for particular applications. - Supercardioid polar pattern reduces muddy-sounding room acoustics and background noise
- PCC technology (phase coherent cardioid) for clear and natural sound
- Programmable, silent operating on/off membrane switch
- Extra leads in mic cable allow remote sensing of mic switch closure
In the Box AKG PCC-170SWO Supercardioid Boundary Layer Microphone with Remote Sensing MOS Switch 15' TA3F to A3M XLR Microphone Cable Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the AKG PCC-170SWO Supercardioid Boundary Layer Microphone with Remote Sensing MOS Switch in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAKG PCC170 Specs | | | Polar Pattern | Supercardioid | | Frequency Range | 50 Hz to 20 kHz | | Signal to Noise Ratio | 72 dB A-Weighted | | Equivalent Noise Level | 22 dB A-Weighted | | Sensitivity | 22 mV/Pa | | | | Output Connectors | 1 x 3-Pin XLR | | Operating Voltage | 12 V
24 V
48 V | | Length | 4.84" / 123 mm |
