User Manual for AKG PZM-11 - Wall Plate Mountable Security Microphone Click to enlarge the picture
Contents of the user manual for the AKG PZM-11 - Wall Plate Mountable
- Product category: Paging & Security Microphones AKG
- Brand: AKG
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for AKG Paging & Security Microphones
|
User manual for the AKG PZM-11 - Wall Plate Mountable contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any AKG product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official AKG user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a AKG product will considerably shorten its lifespan!
|
Product description The Crown PZM-11 pressure zone microphone designed for fixed installation in restaurants, toll booths, box offices, outdoor intercoms, home automation applications and more. The hemispherical polar pattern, delivers clear signal response at the direct and indirect sections of the microphone. The PZM-11 will conveniently install into a standard electrical outlet box and is powered by 12-48V phantom power. The microphone's connections are screw terminal type and are labeled, Audio + / Audio - and Ground for easy installation. - Easy Installation
- The microphone conveniently installs into a standard electrical outlet box and features labeled screw terminal connections for easy installation.
- Tailored Frequency Response
- The frequency response is tailored so that low frequency noise due to cars and street noise are eliminated and frequencies associated with voice are accentuated.
- Rugged Design
- The rugged steel construction is capable of withstanding the rigors of use in commercial establishments such as restaurants and theaters.
UPC: 885038024835 In the Box AKG PZM-11 - Wall Plate Mountable Security Microphone (White) 3 Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the AKG PZM-11 - Wall Plate Mountable Security Microphone in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAKG PZM-11 Specs | Transducer | Electret Condenser | | Polar Pattern | Hemispherical (Half-Sphere) | | Frequency Response | 80Hz - 10kHz | | Dynamic Range (Typical) | not specified by manufacturer | | Signal-to-Noise Ratio | 68dB @ 94dB SPL | | Maximum Input Sound Level | 100dB SPL produces 3% THD @ Max Gain | | Power Requirements | 12-48V phantom power | | Output Impedance | 75 ohms , balanced. Recommended minimum load 1000 ohms | | Output Connectors | Screw Terminals: Audio + / Audio - / Ground | | Pad | No | | Low Frequency Roll-Off | No | | Dimensions | 4.53 x 2.78 x 1.722 (115 x 70.61 x 43.69mm) (LxWxD) | | Weight | 2.5 oz (71 g) | | | | Package Weight | 0.38 lb | | Box Dimensions (LxWxH) | 5.9 x 3.8 x 2.75" |
Rating80% users recommend this product to others. And what about you?
This product has already been rated by 28 owners. Add your rating and experience with the product.
