Product description The Allen and Heath ZED-428 Mixing Console is a flexible, compact mixing desk for today's home studio, project recording and small live sound reinforcement applications. The ZED-428 features 24 inputs comprised of 24-mono and 2-stereo channels. The mono inputs provide high quality microphone preamps and three-band EQ.Four assignable output buses are featured for comping or routing individual channels to multitrack recorders, monitors, etc. The ZED-428 features a USB connector for direct integration with Mac and Windows computers and a copy of Sonar LE recording software is included. - USB Connection
- A USB connection provides direct connection to Mac and Windows computers. Sonar LE recording software is also included.
- Four Buss Outputs
- Four assignable output buses are featured for comping or routing individual channels to multitrack recorders, monitors, etc.
- 24 Mono Inputs
- There are 24 mono channels with line and microphone input connections.
- Two Stereo Inputs
- The two stereo channels feature stereo-paired 1/4" phone connectors for stereo devices such as recorders, effects, keyboards, etc.
- Flexible EQ Section
- All mono channels feature a 3-band EQ with sweepable mid-range. The stereo channels feature 2-band EQ.
- Inserts
- Inserts on all mono channels and stereo output provide flexible routing and control to outboard processors, effects, monitors, etc.
- Balanced Outputs
- The main output section feature a pair of balanced XLR connectors.
In the Box Allen & Heath ZED428 - 28-Input, 4-Buss Recording Mixer with USB Connection USB Cable Power Cable Sonar LE Install CD 1 Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Allen & Heath ZED428 - 28-Input, 4-Buss Recording Mixer with USB Connection in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAllen & Heath ZED-428 Specs | Total # Of Inputs | 28 | | Mic/Line Inputs | 3-pin XLR Balanced Microphone x24
1/4" Phone Balanced Line x28 | | Stereo Line Inputs | ST1 - ST2 1/4" Phone L/R Stereo | | In-Line Inputs/Returns | No | | AUX Sends | 1/4" TRS Phone x4 | | AUX Returns | No | | Inserts | 1/4 TRS Phone x30 (Mono chs., Main Stereo Out and Four Buses) | | BUS (Group) Outputs | 1/4" TRS Phone x4 | | 2 Trk Master I/O | Main Output: Balanced 3-pin XLR
Mono Output: Balanced 3-pin XLR | | ALT I/O | USB Connector
1/4" Phone Mono Output 1/4" Phone Direct Outputs x16 | | Monitor Outputs | RCA Stereo Phono - ALT Out
RCA Stereo Phono - REC Out | | EQ Section | 3-Band with Mid Sweep On all Mono Channels
2-Band On Stereo Channels | | Solo/Mute | Mute and PFL Solo | | Channel Level Control | 100mm Fader | | Trim/Gain Control | Rotary Control | | Phantom Power | +48V Switched Globally | | Metering | 12 Segment Peak LEDs | | Frequency Response | 20Hz to 20kHz | | Dynamic Range | Not Specified By Manufacturer | | Signal-to-Noise Ratio | -88dBu | | Total Harmonic Distortion (THD) | 0.004% | | Power Supply | 100-240V 47-63Hz 40W Max | | Dimensions (WxHxD) | 36.6 x 5.07 x 22.1" (930 x 129 x 465mm) | | Weight | 40 lb (18 kg) | | | | Package Weight | 62.0 lb | | Box Dimensions (LxWxH) | 42.0 x 22.0 x 10.8" |
