User Manual for Altman Phoenix 250W RGBA LED Profile 50° Spot Light Click to enlarge the picture
Contents of the user manual for the Altman Phoenix 250W RGBA LED Profile
- Product category: Stage & Studio Altman
- Brand: Altman
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Altman Stage & Studio
|
User manual for the Altman Phoenix 250W RGBA LED Profile contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Altman product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Altman user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Altman product will considerably shorten its lifespan!
|
Product description This white Phoenix 250W RGBA LED Profile 50° Spot Light from Altman is a fixed focus luminaire. It is designed and engineered with a number of innovative details and features, enhancing versatility and efficiency without sacrificing performance. Fully locking shutters, and a 360° barrel help keep your fixture's focus intact and easy to attain. This model features a RGBA LED array with a 50° lens for a variety of different colored lighting effects with the red, green, blue, and amber LEDs.
With virtually no light leak from the fixture itself you won't have to worry about any extra light illuminating unwanted parts of the ceiling. The aesthetic appearance and ergonomically designed function controls only add to the appeal. All of these options are what makes the Phoenix ideal for theaters, special events, television studios, or wherever energy efficient lighting performance is required. -
- 360 degree rotating barrel
- Locking shutter
- Completely enclosed accessory holder
- Heat resistant plano-convex lensing
- Die cast aluminum and sheet metal fabrication
- Color frame and spring clip safety cable included
- Tool-free interchangeable barrels
- ETL, cETL and CE listed
In the Box Altman Phoenix 250W RGBA LED Profile 50° Spot Light (White) Spring Clip Safety Cable Color Frame 3' PowerCON Power Cable C-Clamp Lens Tube Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Altman Phoenix 250W RGBA LED Profile 50° Spot Light in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAltman Phoenix PHX LED Specs | Housing | Die-cast aluminum construction | | Yoke | Rigid flat steel with dual locking dog tilt handles, two mounting positions, indexed tilt angle markings | | Light Engine | RGBA 50,000 hour LED life | | Cooling | Quiet fan | | Lenses | Color coded crown glass (white plate) lenses provided with anti-reflective coating | | Rating | 100-240 V 50/60 Hz universal power input | | Color Range | RGBA | | Electrical | PowerCON in and out connections
5-pin DMX in and out
Requires power from non-dim source | | Shutter | Four .037" (0.9 mm) stainless steel shutters
Fully adjustable and lockable
Constructed with oversized heat resistant handles | | Dimensions | Light without Yoke: 24.00 x 6.75 x 10.75" (61.0 x 17.1 x 27.3 cm)
With Yoke: 25.75 x 10.75 x 10.75" (65.4 x 27.3 x 27.3 cm) | | Weight | 26.5 lb (12 kg) |
Rating90% users recommend this product to others. And what about you?
This product has already been rated by 26 owners. Add your rating and experience with the product.
