User Manual for Altman Sky Cyc Borderlight, 1 Section - 1K-1.5K Click to enlarge the picture
Contents of the user manual for the Altman Sky Cyc Borderlight, 1 Section
- Product category: Stage & Studio Altman
- Brand: Altman
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Altman Stage & Studio
|
User manual for the Altman Sky Cyc Borderlight, 1 Section contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Altman product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Altman user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Altman product will considerably shorten its lifespan!
|
Product description The Altman Sky Cyc Borderlight is a lightweight, wide spread, quartz-halogen light fixture designed to provide an even wash of light on cycloramas. A 4-light sky cyc, when mounted 8 feet from the cyc, 12 feet on center, will typically provide better than 1.3 to 1 uniformity between fixtures with a minimum of 176 footcandles at the bottom of a 20' cyc. Available in many configurations, the Sky-Cyc is ideally suited for use in theatres and television studios as a compact, lightweight means of lighting large cycloramas from above.This is a 1 section, 1500 watt maximum hanging fixture that includes an iron pipe clamp, 3' power cable, and safety cable. It does not include a bulb. - Die-cast and sheet aluminum construction with baked black epoxy finish.
- Broad, even light distribution.
- Multiple mounting configurations available -- 2 Vertical, 2 Horizontal, 3, and 4 section fixtures available.
In the Box Altman Sky Cyc Borderlight, 1 Section - 1K-1.5K Malleable Iron Pipe Clamp xxvrazqwtdcyccudwcffst Steel Safety Cable (36", Black) 1 Year Manufacturer's Warranty Note: Bulb and plug not included Table of Contents
|
Upload User Manual
Have you got an user manual for the Altman Sky Cyc Borderlight, 1 Section - 1K-1.5K in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAltman Sky Cyc Specs | Rating | 1000, 1500 watts per section, 1500 watts maximum | | Socket (Lampholder) | Double ended | | Lens (Condenser) | Not applicable | | Reflector (Mirror) | Peened specular aluminum | | Mounting | Pipe clamp | | Yoke | Extruded aluminum, 4 handles | | Cable | 3' in black fiberglass sleeving, 1 set of leads per section | | Focusing | Not applicable | | Weight | 12 lbs (5.4 kg) | | Dimensions | 20 x 19.6 x 9.75" (51 x 50 x 25 cm) @ 45° tilt | | | | Package Weight | 19.8 lb | | Box Dimensions (LxWxH) | 28.5 x 24.0 x 14.0" |
