User Manual for Alto Professional ZMX862 Zephyr Series 6-Channel Compact Sound Reinforcement Mixer Click to enlarge the picture
Contents of the user manual for the Alto Professional ZMX862 Zephyr Series 6-Channel
- Product category: Analog Recording Mixers Alto Professional
- Brand: Alto Professional
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Alto Professional Analog Recording Mixers
 |
User manual for the Alto Professional ZMX862 Zephyr Series 6-Channel contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Alto Professional product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Alto Professional user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Alto Professional product will considerably shorten its lifespan!
|
Product description The ZMX862 six-channel, two-bus mixer from Alto features a compact and portable design, and is ideal for live sound reinforcement applications for bands or speakers, in small to medium venues. Versatile inputs include two low-noise discrete microphone preamps with switchable phantom power, two stereo input channels with balanced 1/4" TRS jacks for keyboards and drum machines, and a stereo RCA aux input to plug in your MP3/CD players. Each channel is equipped with a three-band EQ, an FX send for external effects, and a Monitor send to create monitor mixes. They also feature a high-headroom circuitry which preserves your mix's full dynamic range.The LED metering provides precise visual feedback for hands-on mixing, while the color-coded sections and knobs help you identify and quickly reach for controls in dimly lit environments. - Six-channel live reinforcement mixer with 12 total inputs
- Two low-noise discrete microphone preamps with switchable phantom power (on Channels 1 & 2)
- High-headroom circuitry offers extended dynamic range
- Two aux sends per channel for external effects and monitor mix
- Three-band EQ on each channel
- Two stereo input channels with balanced 1/4" TRS jacks for keyboards and drum machines
- One stereo RCA aux input for MP3/CD players
- Color-coded sections & knobs for improved visibility in dimly lit environments
UPC: 816311010160 In the Box Alto Professional ZMX862 Zephyr Series 6-Channel Compact Sound Reinforcement Mixer Power Adapter Limited 1-Year Warranty Quick-Start Guide PDF 3.5mbyvusqvqvzbuebvb Table of Contents
|
Upload User Manual
Have you got an user manual for the Alto Professional ZMX862 Zephyr Series 6-Channel Compact Sound Reinforcement Mixer in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAlto Professional ZMX862 Specs | Frequency Response | All Inputs: 20 Hz to 22 kHz (±1 dB) | | THD + N | All Inputs: ≤ 0.005% (4 dBu, 1 kHz) | | Gain Range | Mic inputs (Channels 1-2): 0 to 50 dB
Line inputs (Channels 1-2): 15 to 35 dBu
Line inputs (Channels 3-6): -20 to +20 dBu | | Voltage Gain | Mic Input to Main Mix Output: 70 dB
Mic Input to Control Room / Phones Output: 80 dB
Mic Input to Aux Send: 60 dB | | SNR | All Inputs: ≥ 110 dBu | | Phantom Power | +45 to +49 V with switch control (Mic Pin 2 / Pin 3 and Pin 1) | | Impedance | Mic Inputs: 3.9 kOhms
All Other Inputs: ≥ 10 kOhms
Aux Outputs: 1 kOhms
All Outputs: 120 kOhms | | Equalization | High: ±15 dB at 12 kHz
Mid: ±15 dB at 2.5 kHz
Low: ±15 dB at 80 Hz | | Crosstalk | Adjacent Inputs: ≤ -80 dB at 1 kHz
Inputs to Outputs: ≤ -75 dB at 1 kHz (stereo L/R, Channels 1-2, panned hard left or right) | | Main Mix | Aux Output, Phones Output: 0 dBu, unbalanced, 1/4" jacks
Maximum Output: +22 dBu, unbalanced, 1/4" jacks
Bus Noise: ≤ -90 dB at 20 Hz to 22 kHz (Channel and Main Mix levels at 0 dB, others at minimum) | | Power Supply | 18 V, 1000 mA | | Power Consumption | 18 W | | Dimensions (W x D x H) | 8.0 x 9.8 x 2.3" / 202.0 x 250.0 x 58.0 mm | | Weight | 3.8 lb / 1.7 kg | | | | Package Weight | 4.55 lb | | Box Dimensions (LxWxH) | 14.9 x 10.6 x 4.9" |
