Product description The American DJ Dotz Matrix Wash / Blinder Fixture with COB (Chip On Board) LED technology allows for a powerful LED engine to be placed in a small amount of space. The result is a super-charged, high-output wash fixture with smooth color mixing, powered by sixteen 30W TRI COB LEDs. Dotz Matrix also has pixel mapping capabilities for enhanced visual effects and a powerful 430W with a 60° beam angle.The fixture has many pro features such as 0 to 100% electronic dimming, strobe / pulse effect, built-in shows and colors macros, a 4-button DMX LCD display, PowerCon AC In / Out, 5 selectable dim curves for stage lighting, 4-pixel flipping options, and 5 DMX channel modes. The Dotz Matrix can run in its standalone mode from built-in programs, sound activation, or from a DMX controller. - 4 x 4 COB LED high-output wash / blinder matrix panel
- COB (Chip On Board) technology produces powerful, smooth RGB color mixing with rich palettes of color
- Can be used as wash / blinder or pixel-mapped matrix for a stunning visual effect
- Suitable for stage lighting, bands, or night clubs
- Individual pixel controllable in 48- & 52-channel DMX modes
- 4x pixel flip options change pixel orientation
- RDM (Remote Device Management) compliant
- Built-in preset colors and programs
- Flicker-free operation (no flickering on camera)
- LED pulse and strobe effect
- 3- & 5-pin XLR chassis mount connectors for DMX linking
- Single yoke allows fixture to be mounted
UPC: 819730010773 In the Box American DJ Dotz Matrix Wash / Blinder Fixture Limited 1-Year Warranty on Parts & Labor Table of Contents
|
Upload User Manual
Have you got an user manual for the American DJ Dotz Matrix Wash Blinder Fixture in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAmerican DJ Dotz Matrix Specs | Modes | Operational Modes: Auto, Sound Active, Manual RGB Dimmer, Static Color, and DMX-512
DMX Channel: 5 | | DMX Channels | 3, 6, 7, 48, and 52 | | Dimming | Electronic: 0 to 100%
Dim Curves: 5 Selectable: Standard, Stage, TV, Architectural, and Theater | | Beam Angle | 60° | | Connectors | 3 & 5-pin XLR chassis mount connectors for DMX linking
PowerCon AC In / Out to daisy chain power (up to 5 Dotz Matrix's @ 120 V and 9 Dotz Matrix's @ 230 V on one 20 A circuit) | | Power Draw | 430 W total (all LED's @ full) | | Light Source | 16x 30 W COB TRI LEDs (RGB: 3 in 1) | | Power Supply | Auto Sensing: 100 to 240 VAC, 50/60 Hz | | Dimensions (L x W x H) | 13.75 x 6.75 x 14.75" (34.93 x 17.15 x 37.47 cm) | | Weight | 18.0 lb (7.8 kg) | | | | Package Weight | 23.95 lb | | Box Dimensions (LxWxH) | 17.8 x 17.3 x 7.7" |
