Product description The Dotz Panel 2.4 2 x 4 COB Tri-LED High Output Wash/Blinder Fixture from American DJ is a high performance, DMX intelligent, LED fixture that uses COB 9W tri-LED for smooth RGB color mixing with rich palettes of color. It offers 5 DMX channel modes (3, 6, 8, 24, or 29) and can be controlled via a DMX controller. The Dotz Panel 2.4 Fixture can be used as a standalone unit or in a master/slave configuration. It features active cooling, built-in preset colors and programs, LED pulse and strobe effects, flicker-free operation, and IEC AC in/out to daisy chain power. This fixture is suitable for retail stores, displays, mood lighting, architectures, interior and exterior decoration, and clubs. - 2 x 4 COB 9W Tri-LED high output wash/blinder
- COB Technology (Chip On Board) produces powerful, smooth RGB color mixing with rich palettes of color
- Use as a wash/blinder or pixel-mapped matrix for stunning visual effects
- Suitable for stage lighting, band performances, or nightclubs
- 5 DMX Channel Modes: 3, 6, 8, 24, or 29 channel modes
- Individual pixels controllable in 24- or 29-channel DMX mode
- 4 pixel flip options change pixel orientation
- 4 Operating Modes: Auto Run, Sound Active, Built-In Programs, and DMX Controlled
- RDM (Remote Device Management) compliant
- Built-in preset colors and programs
- Flicker-free operation (no flickering on camera)
- LED pulse and strobe effects
- 0 to 100% electronic dimming
- 5 Selectable Dim Curves: Standard, Stage, TV, Architectural, and Theater
- 3-Pin XLR chassis mount connectors for DMX linking
- IEC AC in/out to daisy chain power (up to 8 Dotz Panel 2.4s @ 120V and 17 Dotz Panel 2.4s @ 230V)
- DMX LCD display with 4 buttons
- 106W total power consumption with all LEDs at full brightness
- Dual yoke allows the fixture to be hung or set on the ground
- Auto sensing power supply: 100 to 240 VAC, 50/60 Hz
UPC: 819730011008 In the Box American DJ Dotz Panel 2.4 2 x 4 COB Tri-LED High Output Wash/Blinder Fixture Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the American DJ Dotz Panel 2.4 2 x 4 COB Tri-LED High Output Wash Blinder Fixture in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAmerican DJ Dotz Panel 2.4 Specs | LED | 2 x 4 9 W COB tri-LEDs | | Colors | RGB color mixing | | Dimming | Electronic: 0 to 100%
Dim Curves: Standard, Stage, TV, Architectural, and Theater (selectable) | | Microphone | Built-in for sound activated mode | | DMX | Protocol: DMX-512
Channels: 3, 6, 8, 24, or 29 channel modes
Linking: 1 x 3-pin XLR male and 1 x 3-pin XLR female | | Operating Modes | Auto run, Sound Active, Built-In Programs, and DMX Controlled | | Beam Angle | 25° | | Field Angle | 30° | | Programs | Built-In: 14 programs | | Fuse | 2 A | | Power Cord Daisy Chain | Maximum 8 fixtures (120 V); maximum 17 fixtures (230 V) | | Cooling | Fan | | Compliance | RDM (Remote Device Management) | | Power Consumption | 106 W total with all LEDs at full brightness | | Dimensions (LxWxH) | 13.5 x 6.5 x 9.0" (34.3 x 16.5 x 22.9 cm) | | Weight | 14.0 lb (6.4 kg) |
