Product description The American DJ DP-DMX20L 4-Channel DMX Dimmer Pack features independently assignable dimming or switching channels and is easily mounted on a truss lighting rig. The DJ DP-DMX20L features 8 Edison sockets (2 per channel) and includes 16 built-in chases with speed and intensity settings as an added bonus. The DP-DMX20L is at home as a stand-alone unit connected to 8 par can or effects lights, or may be used in conjunction with a DMX controller. - 4 channel DMX dimmer pack
- Digital display - used to set starting DMX address channels and set all other menu options
- Selectable 1, 2, or 4 channel operation
- Adjustable master dim level
- Two three prong Edison sockets per channel
- 3-pin XLR DMX input & output
- Four LED's display channel activity
- External channel fuses for quick and easy replacement
- Sleek reversible mounting panel on the rear
- Zero crossing circuitry for protection of transformer loads when switching
- 16 built in chases when in chase mode with adjustable speed setting
- Use in conjunction with Elation; DMX Operator Pro, Stage Setter-8, Scene
- Reversible mounting brackets
- Setter, Scene Setter-48, Stage Desk-16 or any universal DMX controller
UPC: 819730012166 In the Box American DJ DP-DMX20L 4-Channel DMX Dimmer Pack 1 Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the American DJ DP-DMX20L 4-Channel DMX Dimmer Pack in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAmerican DJ DP-DMX-20L Specs | Power Input | 120 VAC 50/60 Hz | | Output | Channel output: 5 A per channel, total 15 A max. | | DMX Interface | In: 3-pin XLR
Out: 3-pin XLR | | Fuse | External load: F10 A 250 V 5x20 mm
Internal main: F0.315 A 250 V 5x20 mm | | Dimensions (LxWxH) | 8.35 x 7.4 x 2.8" (212 x 188 x 71 mm) | | Weight | 5.29 lb (2.4 kg) | | | | Package Weight | 7.25 lb | | Box Dimensions (LxWxH) | 13.543 x 10.315 x 5.118" |
