Product description Angenieux Cinema Lens Lineup Now in Stock at B&H Read More Built specifically for use with the Angenieux EZ-1 and EZ-2 lenses, the MSU-1A Single-Motor Cine Zoom Servo from Angenieux is a removable lens drive unit that provides servo zoom control to EZ-1 and EZ-2 cinema-style lenses. The zoom lens drive gear is positioned to interface with your lens, and is 0.8 MOD to match the cine-style gearing. The servo incorporates a run/stop button, return video, quick zoom, and a traditional zoom rocker.
Further compatibility is ensured by the inclusion of Hirose and LEMO connectors. Those who wish to may use the servo to control with either Canon or Fujinon standard ENG lens pan handles. - Mounting
- The MSU-1A is self-aligning, mounting with three screws and a guide pin
- Compatibility
- Compatible with Canon and Fujinon standard ENG lens pan handles:
- 20-pin Hirose - analog and remote Control
- 12-pin Hirose - direct to lens port on camera
- 6-pin LEMO - MBUS port
- Zoom Demand and Compatibility
- Via a 20-pin adapter cable (not included):
- Speed and Sensitivity
- The motor has been optimized to provide high-speed motor drive while maintaining sensitivity and precision operation
- ENG Style Operation
-
- Q-Z switch
- VTR switch
- Return switch
- Zoom operation rocker
In the Box Angenieux MSU-1A Single-Motor Cine Zoom Servo for EZ-1 and EZ-2 Lenses D-Tap Power Cable Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Angenieux MSU-1A Single-Motor Cine Zoom Servo for EZ-1 and EZ-2 Lenses in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAngenieux MSU-1A Specs | Drive Gear | 0.8 MOD gear | | Material of Construction | Housing: Magnesium alloy with Teflon coating
Hand Strap: Nylon with leather pad
Strap Latch: Nylon buckle | | Power Consumption | Standby: Approximately 1.5 W (15 V, 0.1 A)
Max: 35 W | | Temperature | Operating: -4 to 131°F / -20 to 55°C
Storage: -22 to 158°F / -30 to 70°C | | Dimensions | Approximate: 5.75 x 3.75 x 4.1" / 14.61 x 9.53 x 10.41 cm | | Weight | 15.9 oz / 450 g | | | | Package Weight | 1.6 lb | | Box Dimensions (LxWxH) | 6.0 x 5.0 x 4.0" |
