Product description - Introducing Orion32 HD
- Antelope Orion 32HD - Gearslutz @ Winter NAMM 2017
The Orion32 HD from Antelope is a versatile audio interface compatible with Pro Tools | HDX systems or any DAW with an HDX or UBS 3.0 port. Well suited for use in production facilities or live recording setups, it offers 64 channels of 24-bit/192 kHz I/O streaming, with pristine AD/DA conversion and additional connectivity via MADI, ADAT, S/PDIF, and eight D-Sub 25 connectors for analog audio. The Orion32 HD is powered with the company's 64-bit Acoustically Focused Clocking (AFC) technology which provides precise clocking for low jitter, resulting in a natural and detailed sound. The unit's FPGA-based DSP engine enables you to process zero-latency mixers with custom effects, opening a variety of creative options such as monitor-mixing with reverb, tracking through modeled vintage EQ & compression, and routing to external gear, in near real-time. The interface is fully controllable via an intuitive OS X- and Windows-compatible desktop app, and can be accessed from multiple computers on the same network. For quiet operation, the Orion32 HD is housed in a single-space rack with a "green" design that doesn't require a fan or machine room. - 64 Channels I/O
-
- Simultaneous streaming of 24-bit/192 kHz audio via HDX or USB 3.0, and additional connectivity on MADI, ADAT, S/PDIF, and 8x D-Sub 25 for analog audio
- Accurate Clocking
-
- Powered by Antelope’s 64-bit Acoustically Focused Clocking (AFC) jitter-management technology
- Two Word Clock or Loopsync outs
- Word Clock, LoopSync, and Antelope 10M/10MX atomic clock inputs
- Mastering-Grade Monitor Outs
-
- Included High-Monitoring D/A uses chips from Antelope's Pure2 Mastering Converter
- Powerful FPGA DSP Engine
-
- Process zero-latency mixers with custom effects for monitor-mixing with reverb, tracking through modeled vintage EQ & compression, and routing to external gear, in near real-time
- Maintains multiple mixers with real-time effects processing – with only two samples of inaudible latency
- Software Control
-
- Fully controllable routing, mixing, real-time effects processing via intuitive OS X- and Windows-compatible desktop app
- Interface can be accessed from multiple computers on the same network
- Freely movable and resizable panels let you maximize your computer monitor space, perfect when working on large projects, scoring to picture, and on multiple-screen set ups
- Quiet Operation
-
- Housed in an efficient “green” design with no fan inside – no need for machine room or iso rack
UPC: 853744004427 In the Box Antelope Orion32 HD 64-Channel HDX and USB 3.1 Gen 1 Audio Interface Limited 1-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Antelope Orion32 HD 64-Channel HDX and USB 3.1 Gen 1 Audio Interface in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAntelope ORION 32 HD Specs | | | Analog Inputs | 4 x D-Sub 25 (32 channels total), +24 dBu max | | Analog Outputs | 4 x D-Sub 25 (32 channels total), +24 dBu max
2 x monitor outs on TRS 1/4 jacks, +24 dBu max | | D/A Monitor Converter | Dynamic Range: 129 dB
THD + N: -108 dB | | A/D Converter | Dynamic Range: 120 dB
THD + N: -110 dB | | D/A Converters | Dynamic Range: 120 dB
THD + N: -107 dB | | | | Digital Inputs | 1 x fiber optic MADI (up to 64 channels)
2 x ADAT (up to 16 channels)
1 x S/PDIF | | Digital Outputs | 1 x fiber optic MADI (up to 64 channels)
2 x ADAT (up to 16 channels)
1 x S/PDIF | | USB 3.0 I/O | 64 channels I/O, up to 192 kHz
USB 3.0 Type-B connector | | HDX Connectivity | 2 x mini HDX connectors for direct Pro Tools connection
32 Channels I/O each (total of 64 channels) | | | | Word Clock Input | 1 x BNC at 75 Ohms 3 Vp-p, 32 - 192 kHz | | Atomic Clock Input | 1 x 10 M BNC input at 75 Ohms 1 Vp-p | | Word Clock Outputs | 2 x BNC at 75 Ohms 3 Vp-p, 32 - 192 kHz | | Clocking System | 4th-generation Acoustically Focused Clocking (AFC)
64-bit DDS
Oven-controlled crystal oscillator | | Clock Stability | <+/-0.02 ppm, oven controlled at 148.1° F / 64.5° C | | Clock Aging | < 1 ppm per year | | Clock Calibration | < +/-0.001 ppm | | Sample Rates | 32, 44.1, 48, 88.2, 96, 176.4, 192 kHz | | | | Connectivity | Internet connection required for product activation | | Mac System Requirements | OS X: 10.9, 10.10, 10.11, 10.12 (El Capitan 10.11.6 recommended)
Disk Space: Minimum 512 MB available disk space
USB: 1 x USB 3.0 port
RAM: 4 GB (minimum), 8 GB or more (recommended)
CPU: Intel Core 2 Duo (minimum), Intel Core i3 or higher (recommended) | | Windows System Requirements | OS: Windows 7, 8, 8.1, 10
Disk Space: Minimum 512 MB available disk space
USB: 1 x USB 3.0 port
CPU: Intel or AMD equivalent CPU with at least 2 GHz operating frequency
RAM: 4 GB (minimum), 8 GB or more (recommended) | | | | Operating Temperature | 32 to 122° F / 0 to 50° C | | Power Consumption | 30 W (maximum) | | Dimensions (W x H x D) | 19.00 x 1.75 x 10.63" / 483.00 x 44.00 x 270.00 mm (approximately) | | Weight | 8.0 lb / 3.6 kg | | | | Package Weight | 12.0 lb | | Box Dimensions (LxWxH) | 25.2 x 13.6 x 4.6" |
