Product description The HDBaseT HDMI over CATx HDBT-1-EAPv Extender & HDBT-1-RAP Receiver Set from Apantac features two single port units: an extender and a receiver. This set can extend HDMI and DVI signals up to 330' away. The HDBaseT technology allows you to transmit uncompressed high definition digital video, 3D video, and audio, as well as various control signals such as RS-232, IR, GPI, and assignable POE, over a single CATx cable. This set has switchable VGA/HDMI input. The extender draws its power from a single power supply (included), connected at either the transmitter or the receiver end. - Single port HDBaseT extender and receiver set
- Extends HDMI signals up to 330' away
- Supports HDMI and DVI formats; 1080p, HD, 3D
- InfraRed, RS-232, GPI, POE control
- Transmission over a single CATx cable
- Switchable VGA/HDMI input
In the Box Apantac HDBaseT HDMI over CATx HDBT-1-EAPv Extender & HDBT-1-RAP Receiver Set Power Supply Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Apantac HDBaseT HDMI over CATx HDBT-1-EAPv Extender & HDBT-1-RAP Receiver Set in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersApantac HDBT-SET-5 Specs | | | Input Connectors | Extender:
1 x HDMI, video
1 x VGA
1 x 15-pin Sub-D female, RS-232 control
1 x 3.5 mm phone jack, IR
1 x Terminal block for GPI
Receiver:
1 x RJ-45, link
1 x Direct IR receiver
1 x 3.5 mm phone jack, extended IR receiver | | Output Connectors | Extender:
1 x RJ-45, link
1 x HDMI, video bypass
1 x 3.5 mm phone jack, IR
Receiver:
1 x HDMI, video
1 x 15-pin Sub-D, RS-232 control
1 x Terminal block for GPI | | LED Indicators | Each Unit:
1 x HDCP
1 x Link
1 x Power | | Maximum Resolution | 4k x 2k/1920 x 1200 (including 1080p and 3D) | | Distance | Up to 330' (100 m) | | Power | 12 VDC, 2.5 A | | Dimensions (W x D x H) | Each Unit: 6.0 x 3.1 x 1.4" (15.3 x 7.8 x 3.6 cm) | | Weight | Both Units: 6.0 lb (2.7 kg) |
