Product description - Key Features
-
- Hybrid inputs
- Mixture of 4-16 auto-detect DVI, VGA, YPbPr, composite, HDMI, SD-SDI/HD-SDI/3G inputs in groups of four
- 16 channels of embedded audio per SDI input
- 4 channels of discrete audio per input (optional)
- Field upgradable to allow discrete audio (AES/AA)
- Multiple outputs in DVI, HDMI or VGA (option)
- Output resolution up to 2048 x 1080 (incl. 1080P)
- Built-in CATx extenders for each output
- Multiple labels per video windows - UMD, OMD, IMD, standalone labels
- Automatic input aspect ratio detection
- Built-in video, audio alarm detections - no audio, audio high/low, no video, video black, video frozen
- Apantac skin technology allows on-screen graphical elements to be designed with any graphics tool
- Front panel headphone jack with volume adjustment for audio monitoring
- Front panel buttons for quick preset recalls
