Product description The KVM-8-E Switch & 8 x UI-200E Extender Kit from Apantac includes one 8-port KVM switch with a built-in CATx extender and 8 universal interface/extender units. The KVM-8-E switch is a dual interface (PS2 / USB) KVM Switch with built-in CATx extender / receiver. It can locate CPUs from up to 650' away, and supports resolutions of up to 2048x1536. The KVM-8-E has an auto-scan feature, and a username/password can be assigned for each port. It features front panel selection buttons, and status LED indicators. No software is required in order to operate this unit properly. This switch is 1RU rackmountable, and multiple units can be cascaded.
The included UI-200E interface/extender units are designed to extend KVM from your PCs/servers to your KVM-8-E switch. These interface units are powered via PS2 or USB, and can extend up to 650' away. Each can be used to cascade two KVM switches together to form larger system. - KVM Switch
-
- Dual interface (PS2 / USB) KVM Switch with built-in CATx extender / receiver
- CPUs can be located up to 650' away when using the included UI-200E
- Auto-scan feature
- Maximum resolution of 2048 x 1536
- User name / password assigned for each port
- Plug and play - no software required
- 19" Rackmountable
- Cascade multiple switches together for additional inputs
- UI-200E
-
- PS2 and USB (with adapter) interface
- Small foot-print to fit on the VGA connector of the PC/server
- No power supply necessary, draws power from PS2 or USB
- Extends up to 650' away
- Can be used to cascade two KVM switches together to form larger system
In the Box Apantac KVM-8-E Switch & 8 x UI-200E Extender Kit - KVM-8-E Switch
- 8 x UI-200E Extender
- Limited 3-Year Warranty
Table of Contents
|
Upload User Manual
Have you got an user manual for the Apantac KVM-8-E Switch & 8 x UI-200E Extender Kit in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersApantac KVM-SET-2 Specs | | | Connectors | 8 x RJ-45 input
1 x 15-pin Sub-D, monitor output
1 x USB type A, keyboard output
1 x USB type A, mouse output
1 x PS2, keyboard output
1 x PS2, mouse output
1 x Power | | Controls and Indicators | 8 x Selection push-button
8 x Connection status LED indicator (green)
8 x Online Status LED indicator (orange) | | Auto Scanning | 1 - 255 sec intervals | | Maximum Resolution | 2048 x 1536 | | Power | 9 VDC, 1500 mA | | Operating Temperature / Humidity | 0 to 122°F (0 to 50°C), 0 - 80% RH | | Dimensions (W x D x H) | 17.24 x 7.09 x 1.73" (43.80 x 18.00 x 4.40 cm) | | Weight | 6.0 lb (2.7 kg) | | | | Connectors | 1 x 15-pin Sub-D male, VGA input
1 x PS2, mouse input
1 x PS2, keyboard input
1 x RJ-45 output | | Power | Powered from the PS2 port | | Dimensions (W x D x H) | 2.8 x 1.4 x 0.7" (7.0 x 3.6 x 1.9 cm) | | | | Package Weight | 8.4 lb | | Box Dimensions (LxWxH) | 22.6 x 11.7 x 3.6" |
