Product description The MiniDE-4 Mini Universal Multiviewer from Apantac is designed to display a combination of DVI, HDMI (with HDCP), VGA, YPbPr, and composite video inputs on a single display with help of DVI adapters (not included). Using this multiviewer, you can monitor up to four inputs. This multiviwer has a built-in CAT5/6 extender and comes with an HDMI-SR HDMI short range receiver. Optionally you can use HDMI-1-R long range receiver (available separately) for extending the HDMI signal for up to 115'. -
- Accepts 4 universal inputs; DVI, HDMI - with HDCP, VGA, YPbPr, and composite with help of DVI adapters (not included)
- Windows can be resized
- Supports ASCII protocol for remote control
- IP and RS-232 control
- DVI / HDMI outputs up to 1080p/60
In the Box Apantac MiniDE-4 Mini Universal Multiviewer HDMI-SR HDMI Short Range Receiver Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the Apantac MiniDE-4 Mini Universal Multiviewer in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersApantac MINIDE-4 Specs | Video Inputs | 4 x DVI-I (for DVI-I to VGA adapter, DVI-I to composite adapter, DVI-I to HDMI adapter, and DVI-I to YPbPr Adapter); BNC IEC 61169-8 annex A | | Video Output | 1 x DVI/HDMI | | Total Windows | 4 | | Composite | NTSC (SMPTE-170M), PAL (ITU624-2) | | Signal Level | 1 V nominal | | DC Offset | 0 V, ±0.1 V | | Impedance | 75 ohms | | Return Loss | 40 db up to 5 MHz | | Control | Front panel buttons for quick preset recalls, GPIs, Apantac ASCII Protocol (AXP), and Director (config & control app) | | Output Resolution | 800 x 480 to 1920 x 1080 (1080p) | | Extender | Up to 35.0' (10.6 m) Range can be extended to 115' (35 m) using long range receiver (HDMI-1-R) | | On-Screen Display | Labels and borders | | General Purpose IO | 40 inputs with DB9 connectors | | IP | 100 Base-TX
Supported Protocols: TSL, AXP
Connector: RJ-45 | | EMI/RFI | Complies with FCC Part 15, Class A, CE, EU, EMC, C-tick | | Power | 110 W , 90 to 250 V, 50/60 Hz
Can be powered using optional redundant power supply | | Dimensions | 22 x 12 x 6" (56 x 31 x 15 cm) | | Weight | 15.0 lb (6.8 kg) | | | | Package Weight | 11.5 lb | | Box Dimensions (LxWxH) | 21.6 x 12.1 x 6.2" |
