User Manual for Apantac Single-Port HDMI RS-232 IR Transmitter & Receiver Kit over Ethernet Click to enlarge the picture
Contents of the user manual for the Apantac Single-Port HDMI RS-232 IR Transmitter
- Product category: Video Extenders & Repeaters Apantac
- Brand: Apantac
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Apantac Video Extenders & Repeaters
 |
User manual for the Apantac Single-Port HDMI RS-232 IR Transmitter contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Apantac product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Apantac user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Apantac product will considerably shorten its lifespan!
|
Product description This Apantac Kit consists of a Single-Port HDMI/RS-232/IR Transmitter and a Single-Port HDMI/RS-232/IR Receiver. It enables you to extend HDMI, RS-232, and IR signals over Ethernet up to a distance of 328 ft. - Single-Port HDMI/RS232/IR over Ethernet Transmitter (Up to 328')
- Key Features
-
- HDMI extender over Gigabit Ethernet network
- Supports IR and RS-232 extension
- Built-in HDMI loop through to eliminate the need for a splitter
- Supports UDP IP protocol and multicast
- HDMI and HDCP compliant
- Built-in web server for system setup
- Supports HDMI resolutions
- Single-Port HDMI/RS232/IR over Ethernet Receiver (Up to 328')
- Key Features
-
- HDMI extender over Gigabit Ethernet network
- Supports IR and RS-232 extension
- Built-in HDMI loop-through to eliminate the need for a splitter
- Transports HDMI via H.264 baseline profile
- Supports UDP IP protocol and Multicast
- HDMI and HDCP compliant
- Built-in web server for system setup
- Supports HDMI resolutions up to 1920 x 1200/1080p
In the Box Bundle Items Single-Port HDMI/RS232/IR over Ethernet Transmitter (Up to 328') Single-Port HDMI/RS232/IR over Ethernet Receiver (Up to 328')
Also Includes Table of Contents
|
Upload User Manual
Have you got an user manual for the Apantac Single-Port HDMI RS-232 IR Transmitter & Receiver Kit over Ethernet in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - Single-Port HDMI/RS232/IR over Ethernet Transmitter (Up to 328')
| | | Device Type | Video/audio extender | | Form Factor | External | | | | Connectivity Technology | Wired | | Data Link Protocol | GigE, HDMI | | Max Resolution | 1080p @ 60 Hz | | Max Transfer Distance | 328 ft | | Status Indicators | Power | | Features | Web server, HDCP compliant, built-in DIP switch | | | | Interfaces | 1 x HDMI (input) - 19 pin HDMI Type A female
1 x HDMI (output) - 19 pin HDMI Type A female
1 x Ethernet 1000 - RJ-45 female
1 x IrDA - mini jack female
1 x RS-232 - DB-9 female | | | | Width | 4.7 in | | Depth | 1.3 in | | Height | 3 in | | Weight | 11.92 oz | - Single-Port HDMI/RS232/IR over Ethernet Receiver (Up to 328')
| | | Device Type | Video/audio/infrared/serial extender | | Form Factor | External | | | | Connectivity Technology | Wired | | Data Link Protocol | HDMI | | Max Resolution | 1920 x 1200 / 1080p @ 60 Hz | | Max Transfer Distance | 328 ft | | Status Indicators | Power | | Features | Web server, HDCP compliant, built-in DIP switch | | | | Interfaces | 1 x HDMI (output) - 19 pin HDMI Type A female
1 x Ethernet 1000 - RJ-45 female
1 x IrDA - mini jack female
1 x RS-232 - DB-9 female | | | | Width | 4.7 in | | Depth | 3 in | | Height | 1.3 in | | Weight | 11.92 oz |
