Product description

Armasight's CO-XLR-LRF 3rd Gen MG Night Vision Long-Range Clip-On allows you to expand your operations to nighttime by adding a night vision capability to your day riflescope. At the core of the device is a 3rd generation intensifier tube with a Gallium Arsenide photocathode and Manual Gain control (MG). The Armasight's Filmless Autogated (FLAG) designation indicates that the tube has a filmless microchannel plate with an autogated power supply. While the filmless microchannel plate minimizes halo effects and improves a signal-to-noise ratio, the autogated power supply improves performance in bright light and extends the tube's life. To extend the life of this device and protect it from an accidental burnout from bright light, this NVD is equipped the bright light cut-off function. The 1x optical system has an f/1.8 F-number and a focal length of 145mm, providing a wide aperture that collects more infrared light to improve visibility. The XLR classification of this clip-on stands for Extended Long Range and allows it to be used with day optics of up to 16x magnification. Enabling you to make operations in total darkness, this night vision device includes a XLR-IR850 infrared illuminator that can cast additional infrared light of your targets.

To withstand the rigors of harsh environments and demanding situations, the device is outfitted with a housing that is durable, waterproof, and resistant to extreme temperatures. Its design allows you to mount the clip-on directly to the objective bell of your day riflescope or on a Picatinny rail.
    Intensifier Tube and Illuminator
    • 3rd gen FLAG
    • MG - Manual Gain
    • Gallium Arsenide photocathode
    • Resolution of 64-72 lp/mm
    • XLR-IR850 detachable infrared Illuminator included
    • FLAG designation indicates filmless microchannel plate and autogated power supply
    Optical Performance
    • Magnification: 1x
    • Recommended day optics: Up to 16x
    • Lens system: 145mm, f/1.8
    • Field of view: 7°
    • Close focus: 27 yd
    Use and Handling
    • Bright light cut-off function
    • Wireless remote control
    • Bright light indicator
    • Low battery indicator
    • Compatible with optional AMRF2200 Advanced Modular Range Finder
    Construction Details
    • Compatible with Picatinny rails
    • Top-mounted Picatinny accessory rail
    • Withstands extreme temperatures
    • Tethered objective cover
    • Lockable quick release mount
    • Waterproof and impact-resistant
UPC: 849815006537 In the Box Armasight by FLIR CO-XLR-LRF 3rd Gen MG Extended Long-Range NV Clip-On (FLAG, Matte Black)
  • XLR-IR850 X-Long Range Illuminator (Dovetail to Weaver Adapter #21) tefettvw
  • Soft Carrying Case
  • CR-123 Lithium-Ion Battery
  • QR Picatinny Mount
  • Battery Adapter for CR-123A/AA
  • Wireless Remote Control
  • Picatinny Adaptor Wireless Remote Control
  • Light-Suppressor
  • Adjustment-Control-Device
  • Special Wrench
  • Limited 2-Year Warranty
