Product description Improve your tactical advantage in training or success in night hunting with the Orion 5x 1st Generation Night Vision Riflescope from Armasight. With its magnifying power, a wider than average angle of view, and an illuminated red crosshair reticle, this night vision scope will bump-up a couple of notches your ability to hit your targets at night. The Orion combines all the right characteristics to provide optimal performance with a 1st generation intensifier tube: noticeable zoom with 5x magnification; larger than average 10° angular field of view; 33' minimum focusing distance; a large 70mm objective lens for scooping more infrared light; and a powerful detachable infrared illuminator with a flood lens for improved range and observing targets in total darkness. To augment the optical performance, its convenience features follow suit. The scope also has a diopter adjustment and a baffled eyecup.
The aluminum housing is durable and has a contoured rubberized covering. It offers water-resistant protection for the electronics and a tethered rubber lens cap to protect the objective. The precision focus adjustment ring is located on the top of the scope. Note: Export of this device described herein is strictly prohibited without a valid export license issued by the U.S. Department of State office of Defense Trade Controls, as prescribed in the International Traffic in Arms Regulation (ITAR), Title 22, Code of Federal Regulation, Parts 120-130, and/or the U.S. Department of Commerce. For further information contact the Office of Defense Trade Control and/or the U.S. Department of Commerce. - Reticle
-
- Illuminated red crosshair reticle
- Adjustable brightness
- Optical Performance
-
- 5x magnification
- f/1.6, 108mm lens system
- 10° angle of view
- ±5 diopter adjustment range
- Image Intensifier
-
- 1st generation intensifier tube
- 30-40 lp/mm resolution
- Use and Handling
-
- Detachable infrared illuminator with adjustable focus
- Low-profile windage and elevation turrets
- 1/2 MOA impact point correction
- Precision focusing knob is located on the top
- In-view low battery status indicator
- Construction Details
-
- Aluminum housing
- Rubberized armoring
- Mountable on Picatinny/Weaver rails
- Baffled rubber eyecup minimizes green light spill-over
- Tethered objective cover
- Water-resistant
- Shock-resistant
UPC: 818470010517 In the Box Armasight by FLIR Orion 5x 1st Generation Night Vision Riflescope (Red Crosshair Reticle) - IAIR810IR000001 IR810 Infrared Illuminator
- 18650 Rechargeable Battery for IR Illuminator
- Scope Cover
- CR123A Battery
- Lens Cap
- Lens Cloth
- Limited 2-Year Warranty
Table of Contents
|
Upload User Manual
Have you got an user manual for the Armasight by FLIR Orion 5x 1st Generation Night Vision Riflescope in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersArmasight by FLIR NWWORION0511I11 Specs | Intensifier Tube | 1st generation | | Magnification | 5x | | Lens System | f/1.6, 108mm | | Objective Lens Diameter | 70mm | | Angular Field of View | 10° | | Minimum Focus Distance | 33' (10 m) | | Diopter Range | ±5 | | Infrared Illuminator | Yes, detachable | | Battery / Runtime | 1 x CR123A battery / 40 hr | | Operating Temperature | -40 to 122°F (-40 to 50°C) | | Storage Temperature | -58 to 140°F (-50 to 60°C) | | Dimensions | 12.7 x 4.6 x 4.1" (323 x 118 x 104 mm) | | Weight | 60 oz (1.7 kg) | | | | Package Weight | 5.07 lb | | Box Dimensions (LxWxH) | 13.4 x 5.2 x 4.9" |
