Product description The Arri 6Kw Dimmer for the ST5 Studio Fresnel offers portability (easy-to-grip-handles) at only 25 lbs (11.4kg). It can be used as it sits next to your ST5 fixture, or wired through your DMX control system. Separate LED displays show selected dimmer level from 0-100%, operating modes and presence of a DMX 512 control signal. This 6Kw dimmer is convection cooled for quiet operation. Its panel accepts stage pin connectors for input and output. The controls and connectors are recessed to avoid damage and uneccessary wear. If the studio power should fail, this unit retains your dimmer level, pre-heat level, operating mode and DMX 512 address. - Precise
-
- Full digital control through microprocessors
- Eight-bit resolution for full 256-step dimming control with exact level repeatability
- Neon indicators show status of line, circuit breaker and output
- Less than 8ms response time
- Solid
-
- High impact plastic top and bottom
- 100% solid state design for reliability
- Part of the extruded aluminum Lex PowerRACK system
- Modular
- Three dimmers can be combined in an optional rolling rack that includes power distribution and feed-through capability
- Safe
-
- Circuit breaker
- UL Rated
- Recessed controls
In the Box ARRI 6Kw Dimmer for ST5 Studio Fresnel (120VAC) One Year Manufacturer's Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the ARRI 6Kw Dimmer for ST5 Studio Fresnel in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersARRI L2.0005114 Specs | Rating | 6Kw Dimmer with DMX, 120VAC, 50-60Hz
DMX 512 address from 001-512
125A, 120VAC SCR pair, optically isolated with 2200A surge capacity | | Control | Integral momentary pushbuttons and digital display
Accepts DMX 512 control signal
Square law dimming curve, response time: < 8ms
360 ms rise time copper wound toroidal choke | | Connectivity | Neutrik 5 pin XLR male and female for DMX 512 input and DMX 512 thru
Panel mount stage pin connectors for input and output | | Circuit Protection | Breaker
Voltage regulation maintains dimmer output within 2% despite fluctuations in input voltage
Convection cooled | | Dimensions | 14 x 8 x 14" (35.6 x 20.3 x 35.6cm) | | Weight | 25 lbs (11.3kg) | | | | Package Weight | 28.4 lb | | Box Dimensions (LxWxH) | 20.1 x 15.7 x 10.6" |
