User Manual for ARRI ALEXA SXT Camera Upgrade 13 14 Click to enlarge the picture
Contents of the user manual for the ARRI ALEXA SXT Camera Upgrade 13
- Product category: Camcorder Boards & Software Upgrades ARRI
- Brand: ARRI
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ARRI Camcorder Boards & Software Upgrades
|
User manual for the ARRI ALEXA SXT Camera Upgrade 13 contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ARRI product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ARRI user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ARRI product will considerably shorten its lifespan!
|
Product description The Studio ALEXA SXT Camera Upgrade 13/14 from ARRI is an upgrade from an ALEXA XT Studio camera body to an ALEXA SXT Studio camera body. It replaces internal electronics boards, the XR module on the camera left side, and the Plus right-side electronics cover. It includes all ALEXA SXT Studio features, nameplate, and future upgrade potential. The new electronics allow for in-camera recording of ProRes 4K, improved image quality, ASC CDL, 3D LUTs, and three independent HD-SDI outputs. The new SXR module allows the recording of ARRIRAW or ProRes onto SXR or XR capture drives. It also allows for the recording of ProRes onto CFast 2.0 cards, SxS PRO+ cards, or SxS PRO cards. Included with this upgrade are an SXR adapter, an XR adapter, ACOM3, APIC2, and ALOG2 boards, an SXR module, and an SXT cover. - SXR adapter is included for use with SXR capture drives (available separately)
- XR adapter is included for use with the XR capture drive (available separately)
- SXR module has new left-side cover with media slot and 'ALEXA SXT' nameplate
- SXT cover has new Plus right-side electronics cover with 'ALEXA SXT Studio' nameplate
- Each medium needs its own adapter
In the Box ARRI ALEXA SXT Camera Upgrade 13/14 (Studio) SXR Adapter XR Adapter ACOM3 Board APIC2 Board ALOG2 Board SXR Module SXT Cover Limited 1-Year Warranty on Mechanical Parts Table of Contents
|
