Product description

• FF-4 Basic Follow Focus Unit (Black Edition) The sleek, black-finished ARRI FF-4 Basic Follow Focus Unit consists of a single-sided follow focus with one standard knob. This robust, economical unit slides onto a pair of lightweight 15mm rods (rods not included). The FF-4 is designed with a 1:2 knob-to-gear ratio for smooth, accurate focus pulls on a variety of lenses. A required focus gear is not included with this unit. The FF-4 features a modular design that is compatible with most ARRI follow focus accessories such as whips, speed cranks, and knob accessories (available separately). One flat marking disk is included with the FF-4 Basic Unit. Note: A BA-2/3 adapter is required for use with a studio bridge plate

  Features

  • Slide-on design for 15mm lightweight support rods; requires BA-2 or BA-3 adapter for use with studio bridge plates
  • Single-style left (operator) side unit includes one standard knob
  • A 1:2 gear ratio suits a variety of lenses
  • Compatible with most ARRI follow focus accessories such as whips, speed cranks, and other style knobs
• BA-2 FF-4 Adapter for Bridge Plate (19mm Studio Rods) The ARRI BA-2 FF-4 Follow Focus Adapter is used with an ARRI FF-4 or FF-3 base component. Use this adapter to snap the FF-4/FF-3 onto a pair of bridge plate-supported 19mm studio rods (not included). The adapter fastens onto a pair of rods using a single thumbscrew. Mounting and detaching the BA-2 Adapter from the FF-4/FF-3 can be done in the field by the user and does not require shop service.
  • Works with both the HD and Cine versions of the FF-4 follow focus, and the FF-3
  • Thumbscrew-locking adapter snaps onto a pair of 19mm rods (rods not included)
  • Fastens onto both rods using a single thumbscrew
  • Can be mounted and removed in the field by the user
• Follow Focus Gear (0.8 Mod, 35 Teeth) This ARRI Follow Focus Gear can be used with all ARRI follow focus systems. The 35-tooth, 0.8 mod gear is designed for use with prime lenses and smaller zoom lenses that have 32 pitch gear rings. Its medium-width gear face measures 10mm.
  • Follow focus gear meshes with a lens ring to enable focus adjustments
  • 0.8 mod, 35-tooth, 32 pitch gear with a face width of 10mm
  • For prime lenses and smaller zoom lenses with standard 32-pitch gear rings
• Follow Focus Speed Crank The ARRI Speed Crank fits into the socket of any ARRI follow focus knob. Designed for quick or extended focus pulls, this L-shaped handle enables a camera assistant to rotate the lens focus barrel further than possible when grasping the focus knob itself. The crank's round knob and right-angle configuration enable rotating the focus knob 360° or more, for those shots requiring extreme shifts in focus.
  • Attaches to the socket on any ARRI follow focus knob
  • Enables speedy or extended focus pulls with 360° or more of focus knob rotation
  • L-shaped handle with knob head for comfortable handling
• Flat Marking Disk for WCU-3 & Standard/2-Speed FF Knob This ARRI Flat Marking Disk is compatible with standard and two-speed follow focus knobs, and the WCU-3 hand unit knob. Use a non-permanent marker to apply temporary focus marks to its surface. This round plastic unit may be used as a replacement or additional marking disk.

• Case for FF-3/FF-4 Follow Focus

• Mini Follow Focus MFF-2 Cine Base

• Standard Focus Knob (Left Side)

• Limited 1-Year Warranty

• Limited 1-Year Warranty

• Limited 1-Year Warranty

• Limited 1-Year Warranty

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• FF-4 Basic Follow Focus Unit (Black Edition)

  Included Drive Gear	0.8 MOD
  Rod Compatibility	15 mm LWS
  Number of Sides	Single-Sided
  Built-In Hardstops	None
  Marking Disk	Yes
  Switchable Handwheel Speed	No
  Dimensions	11.8 x 3.9 x 3.9" / 300 x 100 x 100 mm
  Weight	1.5 lb / 670 g

  Box Dimensions (LxWxH)	7.8 x 4.5 x 2.9"

• BA-2 FF-4 Adapter for Bridge Plate (19mm Studio Rods)

  Dimensions	3.9 x 6.3 x 1.2" (100 x 160 x 30 mm)
  Weight	5.8 oz (165 g)

  Box Dimensions (LxWxH)	6.1 x 2.3 x 1.3"

• Follow Focus Gear (0.8 Mod, 35 Teeth)

  Number of Gear Teeth	35
  Face Width	0.4" (10 mm)
  Dimensions	1.2 x 1.2 x 0.6" (30 x 30 x 15 mm)
  Weight	0.5 oz (13 g)

  Box Dimensions (LxWxH)	4.0 x 2.5 x 0.7"

• Follow Focus Speed Crank

  Dimensions (WxHxD)	2.2 x 4.3 x 0.8" (5.5 x 11.0 x 2.0 cm)
  Weight	1.6 oz (44 g)

  Box Dimensions (LxWxH)	5.0 x 4.0 x 1.0"

• Flat Marking Disk for WCU-3 & Standard/2-Speed FF Knob

  Dimensions	Not specified by manufacturer
  Weight	Not specified by manufacturer

  Box Dimensions (LxWxH)	4.0 x 4.0 x 0.4"
