User Manual for ARRI LoCaster 2 Plus LED Panel with Stirrup Click to enlarge the picture
Contents of the user manual for the ARRI LoCaster 2 Plus LED Panel
- Product category: LED Lights ARRI
- Brand: ARRI
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ARRI LED Lights
|
User manual for the ARRI LoCaster 2 Plus LED Panel contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ARRI product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ARRI user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ARRI product will considerably shorten its lifespan!
|
Product description Building on the foundation of the original LoCaster, ARRI's LoCaster 2 Plus LED Panel with Stirrup features 35% greater brightness, adjustable color temperature, light weight, full dimming and the AC and battery options sought after by location shooters. ARRI uses a 8.58 x 3.77 x 2.75", 35W LED array with a prismatic homogenizing lens to produce a 63-degree beam angle that performs like a single source luminaire without the multiple shadows that plague some other fixtures.The LoCaster 2 Plus offers a substantial amount of control as compared to other lights and adjustments are executed with simple knobs on its back panel. Color temperature is variable from 2800 to 6500K, and you can tweak the full minus and full plus green as well, taking care of most of your filtration preferences without taping a single gel to the unit. Dimming from 0-100% is just as easy using another knob. The LEDs are virtually heat-free, eliminating worries about the comfort of the talent, while the panel's rated 50,000 lamp life makes the LoCaster practically maintenance-free too.The LoCaster runs on a 100-250 VAC power supply for worldwide use or on a Caster battery pack when mains power is unavailable. The power supply, battery and charger are all purchased separately. The LoCaster 2 Plus comes with a stirrup that acts as a yoke, allows tilting adjustment, and has a built-in holder for the optional battery pack. - LoCaster 2 Plus LED Panel This LoCaster 2 Plus LED Panel from ARRI has approximately 35% more light output than its predecessor, while still maintaining the same form factor, appearance, low power draw, and compatibility with all existing Caster Series power and mounting accessories. The LoCaster 2 Plus features an easy to use onboard controller with color temperature variable from 2800 to 6500K with full plus or minus green correction and continuous dimming from 0-100% ARRI's exclusive LED technology ensures natural light characteristics, single shadow rendering, consistent light output and color stability with a CRI of 94. The LoCaster 2 Plus is powered by an optional multi-voltage AC power supply or DC source.
- Attributes
-
- Tunable white light from tungsten to daylight
- 35% Brighter than LoCaster 2
- High intensity
- Low power consumption
- Single shadow rendering
- CRI of 90
- Onboard control elements: dimming, color temperature, green/magenta adjustment
- Stable color temperature and output
- Easy handling and portability
- Optional battery power
- Stirrup for LED BroadCaster/LoCaster/Battery The Arri Stirrup provides a convenient mount for both BroadCaster and LoCaster LED Panels as well as the LoCaster Battery Pack. The panels, which mount to the stirrup via their 3/8" (9.5 mm) female thread, gain the advantage of swiveling movement and a 5/8" (16mm) receiver in a yoke-like construction for stand mounting.T-pins are built into the stirrup which snap into channels in the NiMH Battery Pack for quick mounting. The battery is released by pulling the knob on top of it.
In the Box Bundle Items LoCaster 2 Plus LED Panel dfccxyfwvqrvcwue Stirrup for LED BroadCaster/LoCaster/Battery
Also Includes User Manual PDF 109.6kb Table of Contents
|
Upload User Manual
Have you got an user manual for the ARRI LoCaster 2 Plus LED Panel with Stirrup in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parameters - LoCaster 2 Plus LED Panel
| | | Beam Angle | 63° | | Color Temperature | 2800 to 6500K ± 100K (with 200K Shift over Lifetime) | | Color Accuracy Standard | CRI 94 | | Cooling System | None | | Dimming | Yes, 0 to 100% | | Display | None | | Expected Lamp Life | 50,000 Hours | | Fixture Dimensions | 8.6 x 3.8 x 2.8" / 218.0 x 96.0 x 70.0 mm | | Fixture Weight | 2.1 lb / 0.95 kg | | | | Power Input Connector | 4-Pin XLR | | | | Fixture Mount | 3/8"-16 Female Thread | | Accessory Mount | None | | | | AC Input Power | 100 to 250 VAC, 50 / 60 Hz | | DC Input Power | 11 to 36 VDC | | Power Source | AC Adapter, External Battery | | Max Power Consumption | 35 W | | | | IP Rating | IP20 | | Operating Temperature | -4 to 95°F / -20 to 35°C | | | | Box Dimensions (LxWxH) | 9.2 x 4.6 x 3.1" | - Stirrup for LED BroadCaster/LoCaster/Battery
| Dimensions | 2.5 x 3.9 x 2.1" (6.5 x 10 x 5.5 cm) | | Weight | Not Specified by Manufacturer | | | | Box Dimensions (LxWxH) | 8.3 x 6.2 x 1.6" |
