Product description

• Base Plate for Sony a7S II The Base Plate for Sony a7S II from ARRI is a lightweight yet robust camera plate. Suited for handheld configurations, the plate is also compatible with ARRI studio bridge plates like the BP-8 and BP-9. This plate's integrated front rod holder supports a pair of lightweight 15mm rods (not included), enabling you to flesh out your camera rig with rod-mounted accessories.

  Features

  • Integrated 15mm rod support at the front of the plate
  • Lightweight design is suited for handheld configurations
  • Compatible with studio bridge plates like the ARRI BP-8 and BP-9
  • Enables the addition of 15mm rod-mounted accessories to your Sony Alpha a7S II
• LAS-1 Lens Adapter Support The LAS-1 Lens Adapter Support from ARRI provides sturdy support for many third-party, pillar-style lens mount adapters. The LAS-1 Support is compatible with PL, EF, and other lens adapters, as well as certain optical adapters like the Metabones Speed Boosters. The two pieces of this support are connected via a thumbscrew coupling, enabling quick removal from your baseplate when desired.
  • Provides additional support for many third-party, pillar-style PL, EF, and other lens mount adapters
  • Also compatible with some optical lens adapters, such as Metabones Speed Boosters
  • Two-piece design with a thumbscrew coupling for quick removal from your baseplate
• Left Side Bracket for Sony a7S II The ARRI Left Side Bracket for Sony a7S II works with the a7S II baseplate and a top handle to cradle and protect the camera, providing 3/8"-16 and 1/4"-20 threads for mounting accessories (plate and handle available separately). An integrated shoe-style adapter enables the mounting of a third-party viewfinder bracket.

  Features

  • Adds 3/8"-16 and 1/4"-20 accessory mounting points to the Sony Alpha a7S II
  • Integrated shoe-type adapter for mounting a third-party viewfinder bracket
  • Works with the separately available ARRI a7S II baseplate and a top handle
• Right Side Bracket for Sony a7S II The ARRI Right Side Bracket for Sony a7S II works with the a7S II baseplate and a top handle to cradle and protect the camera, providing 3/8"-16 threads for mounting accessories (plate and handle available separately). An integrated shoe-style adapter enables the mounting of a third-party viewfinder bracket. The integrated wooden grip provides a comfortable surface for grasping the camera rig.

  Features

  • Adds 3/8"-16 accessory mounting points to the Sony Alpha a7S II
  • Integrated shoe-type adapter for mounting a third-party viewfinder bracket
  • Works with the separately available ARRI a7S II baseplate and a top handle
  • Includes a wooden grip for comfortably grasping the camera rig
• HDMI Cable Clamp for Sony a7S II Spare your a7S II's micro-HDMI connector from repetitive-use stress, and prevent accidental cable disconnects, by using this ARRI Cable Clamp. The clamp's micro-to-full size HDMI adapter extends from the camera connector to a securely fastened base. The offset base screws into the side of an ARRI a7S II baseplate and hooks into an a7S II left-side bracket (plate and bracket available separately). The clamp's full-size HDMI female connector provides a reliable output to an external recorder, viewfinder, or monitor.
  • Provides a secure HDMI connection, reducing stress on the camera's connector and minimizing the chance of a cable disconnect
  • Micro-HDMI to full-size HDMI adapter supplies a reliable HDMI output to a monitor, EVF, or external recorder
  • Securely fastens to the ARRI a7S II left-side bracket and baseplate (available separately)
• CTH-1 Cage Top Handle Expand your options for mounting HD camera accessories like monitors, transmitters, mic holders, French flags, etc., on your ARRI camera rig by using the ARRI CTH-1 Cage Top Handle. This sturdy carrying handle screws onto any single 3/8"-16 thread on the ARRI Cage System, and features multiple 3/8"-16 and 1/4"-20 threaded holes for attaching accessories. Designed for use with the ARRI Cage System, it will also work with many ARRI accessory-equipped third-party cameras.

  Features

  • Sturdy carrying handle attaches to any single 3/8"-16 thread on the ARRI Cage System to provide accessory mounts
  • Adds multiple 3/8"-16 threaded mounting points to an ARRI Cage System, or third-party cameras using ARRI support systems
• 15mm Lightweight Support Rods (Pair, 9") This pair of 9" ARRI Lightweight Support Rods feature lightweight stainless steel construction and are designed to reduce your rig's weight. Use them with any 15mm-based accessory or bridgeplate.
  • Hollow, lightweight stainless steel construction with non-threaded ends
  • Compatible with any 15mm-based accessory or bridgeplate
• BPS-2 Bridge Plate Sled The BPS-2 Bridge Plate Sled from ARRI works with a bottom plate to balance your camera as the weight of the rig is changed (plate not included). The BPS-2 offers a lightweight alternative to a studio bridge plate when support rods are not needed.This sled is compatible with ARRI MBP-3, MBP-1 Pro BP, Canon C100/300/500, Canon 1DX-1DC, Sony FS5/F55, and RED Epic/Scarlet adapter plates. The BPS-2 plate includes 3/8"-16 threaded studs for mounting to a camera.
  • Use as a lighter weight alternative to a studio bridge plate when rod support is not needed
  • Lever-locking plate is compatible with ARRI MBP-3, MBP-1 Pro BP, Canon C100/300/500, Canon 1DX-1DC, Sony FS5/F55, and RED Epic/Scarlet adapter plates
  • Includes 3/8"-16 camera-mounting screws
• Bottom Dovetail Plate (12") This 12" Bottom Dovetail Plate from ARRI is used with a sliding bridge plate or sled to balance your camera rig. To prevent the bridge plate or sled from sliding off, the Dovetail Plate features a spring-loaded post on one end and a stationary stop on the other. The bottom of the plate incorporates 3/8"-16 threaded holes for mounting the dovetail to a tripod quick release plate or other support.
  • Use with a sliding bridge plate or sled to balance your camera rig (plate or sled not included)
  • Includes a spring-loaded post on one end, and a stationary stop on the other to prevent the bridge plate or sled from sliding off
  • Bottom of dovetail includes 3/8"-16 threaded holes for mounting to a tripod quick release plate or other support
• Viewfinder Cross Pipe The ARRI Viewfinder Cross Pipe is compatible with the MVB-1 viewfinder mounting bracket. Use it with ARRI EVF brackets to attach an ARRI or third-party viewfinder.

• Mounting Bolt

• Limited 1-Year Warranty

• Mounting Screws

• Limited 1-Year Warranty

• Limited 1-Year Warranty

• Limited 1-Year Warranty

• Limited 1-Year Warranty

• Limited 1-Year Warranty

• Limited 1-Year Warranty

• 3/8"-16 Camera-Mounting Screws

• Limited 1-Year Warranty

• Limited 1-Year Warranty

• Limited 1-Year Warranty

Also Includes

• BPA-4 Bridge Plate Adapter
• RMB-3 Rod-Mounting Bracket

Upload User Manual

Please enter here the link to the user manual of this product: OR Enter here the file with the user manual of this product from your computer/phone: (60MB max; Permitted formats: PDF) 0%

Technical parameters

• Base Plate for Sony a7S II

  Dimensions	2.4 x 4.7 x 4.7" (60 x 120 x 120 mm)
  Weight	8.1 oz (229 g)

  Box Dimensions (LxWxH)	6.3 x 5.5 x 3.3"

• LAS-1 Lens Adapter Support

  Dimensions (WxHxD)	2 x 2.8 x 1.6" (50 x 70 x 40 mm)
  Weight	1.1 oz (30 g)

  Box Dimensions (LxWxH)	3.6 x 3.5 x 0.6"

• Left Side Bracket for Sony a7S II

  Accessory Mounting	3/8"-16 and 1/4"-20 threads 1 x Shoe adapter
  Dimensions	3.1 x 5.1 x 2" (80 x 130 x 50 mm)
  Weight	3.6 oz (101 g)

  Box Dimensions (LxWxH)	5.0 x 4.5 x 1.0"

• Right Side Bracket for Sony a7S II

  Accessory Mounting	3/8"-16 threads 1 x Shoe adapter
  Dimensions	5.5 x 4.7 x 2" (140 x 120 x 50 mm)
  Weight	11 oz (313 g)

  Box Dimensions (LxWxH)	5.7 x 4.4 x 2.0"

• HDMI Cable Clamp for Sony a7S II

  Dimensions	3.1 x 1.6 x 1.2" (8.0 x 4.0 x 3.0 cm)
  Weight	2 oz (56 g)

  Box Dimensions (LxWxH)	3.7 x 3.0 x 0.8"

• CTH-1 Cage Top Handle

  Dimensions	2.8 x 6.1 x 1.2" (7.0 x 15.5 x 3.0 cm)
  Weight	8.3 oz (235 g)

  Box Dimensions (LxWxH)	5.9 x 2.4 x 1.2"

• 15mm Lightweight Support Rods (Pair, 9")

  Material of Construction	Stainless Steel
  Rod Diameter	15 mm
  Rod Length	9.4" / 23.9 cm
  Weight	5.2 oz / 148 g

  Box Dimensions (LxWxH)	9.5 x 1.2 x 0.5"

• BPS-2 Bridge Plate Sled

  Dimensions	Not specified by manufacturer
  Weight	8.7 oz (246 g)

  Box Dimensions (LxWxH)	5.2 x 4.2 x 1.1"

• Bottom Dovetail Plate (12")

  Dimensions (WxLxD)	3.9 x 11.8 x 1" (100 x 300 x 25 mm)
  Weight	1.3 lb (578 g)

  Box Dimensions (LxWxH)	11.9 x 4.2 x 1.6"

• Viewfinder Cross Pipe

  Dimensions	4.7 x 6.3 x 2.4" (12.0 x 16.0 x 6.0 cm)
  Weight	6.2 oz (177 g)
