User Manual for ART C2 Cardioid FET Condenser Microphone with Pad & Roll-Off Switch Click to enlarge the picture
Contents of the user manual for the ART C2 Cardioid FET Condenser Microphone
- Product category: Large Diaphragm Condenser ART
- Brand: ART
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ART Large Diaphragm Condenser
 |
User manual for the ART C2 Cardioid FET Condenser Microphone contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ART product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ART user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ART product will considerably shorten its lifespan!
|
Product description The C1 Cardioid FET Condenser Microphone with Pad & Roll-Off Switch from ART is for capturing audio in live-sound and remote-recording applications. It features 48V phantom power, a low-mass diaphragm, and a high-quality 34mm capsule that delivers a clear tone with accurate sonic details.The cardioid polar pattern offers excellent feedback rejection and is suitable for most vocal applications, solo instruments, background brass, woodwinds, acoustic stringed instruments, drums and percussion instruments, and more. It offers a full-frequency response at the front of the microphone with a very controlled and predictable proximity effect.Additionally, controls on the microphone include a -6 and -12 dB pad switch, allowing for distortion-free reproduction of extremely loud at-source signals, and a two-position -12 dB/octave low-frequency roll-off switch at 100 & 200 Hz that reduces unnecessary low-end 'boominess' and low-frequency interference.Furthermore, it is built with a precision-tooled microphone body and a dent-resistant, stainless-steel wire-mesh windscreen, which ensures long-term reliability. The C1 comes equipped with a custom shockmount. An aluminum carry case is also included. UPC: 840402040491 In the Box ART C2 Cardioid FET Condenser Microphone with Pad & Roll-Off Switch Shockmount Aluminum Carry Case Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the ART C2 Cardioid FET Condenser Microphone with Pad & Roll-Off Switch in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersART C2 Specs | | | Sound Field | Mono | | Operating Principle | Pressure Gradient | | Transducer | Condenser | | Diaphragm | 1.34" / 34 mm | | Polar Pattern | Cardioid | | Frequency Range | 20 Hz to 20 kHz | | Signal to Noise Ratio | 78 dB | | Equivalent Noise Level | 16 dB A-Weighted | | Maximum SPL | 132 dB SPL RMS | | Pad | -6 dB
-12 dB | | Impedance | 150 Ohms | | Load Impedance | 1000 Ohms | | Sensitivity | -37 dB | | Low-Cut Filter | 12 dB/Octave @ 100 Hz
12 dB/Octave @ 200 Hz | | | | Output Connectors | 1 x 3-Pin XLR | | Operating Voltage | 48 V | | Length | 6.6" / 167.64 mm | | Diameter | 2.2" / 55.88 mm | | | | Package Weight | 3.85 lb | | Box Dimensions (LxWxH) | 12.0 x 10.0 x 4.2" |
Rating50% users recommend this product to others. And what about you?
This product has already been rated by 10 owners. Add your rating and experience with the product.
