User Manual for Assimilate SCRATCH Click to enlarge the picture
Contents of the user manual for the Assimilate SCRATCH
- Product category: Video Editing Assimilate
- Brand: Assimilate
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Assimilate Video Editing
|
User manual for the Assimilate SCRATCH contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Assimilate product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Assimilate user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Assimilate product will considerably shorten its lifespan!
|
Product description The Assimilate SCRATCH Single Site License with 1-Year Support provides an unlimited number of licenses of SCRATCH for Mac or Windows for a single location. One year of upgrades and phone/email technical support is included.
SCRATCH is a comprehensive DI finishing software capable of flexible acquisition, on-set dailies primary level color correction, conform, and full-finish post production, including high-resolution grading and 3D compositing.
SCRATCH combines grading and compositing with a powerful data management engine. An SQL database organizes metadata from virtually any source and makes it available to any other tool in the workflow at any time. An open data pipeline enables SCRATCH to be automated and extended via XML to build efficient pipelines, and full HTML support offers the flexibility of remote client reviews. Plug-in support architecture allows further enhancing SCRATCH with plug-ins like Furnace and Sapphire. Stereo 3D is not an add-on but rather built from the ground up. Image pairs are automatically linked for versioning and real-time playback to a wide variety of stereoscopic delivery systems.
The key components to run SCRATCH at its best are graphics, RAM, and disk bandwidth. The program is compatible with many desktop control panels, including the relatively affordable Tangent Devices Element panels. - Color Correction & 3D Compositing
- SCRATCH seamlessly blends color correction with deep 3D compositing in one unified, real-time system. You won't have to interrupt your DI session because you have to send beauty shots out to VFX. Does your shot need a quick object replaced? Need to add a Sapphire Lens Flare? SCRATCH handles all these routine VFX fixes right in the DI session without stopping.
- Optimized for Real-Time, Client-Attended Interactivity
- SCRATCH delivers the raw performance that inspires collaboration with your clients. Play and review multi-resolution shots side-by-side and in real-time. Experience incredibly fluid, responsive grading and finishing sessions.
- Digital Tools for the Entire Post-Production Workflow
- SCRATCH delivers real-time data management, to dailies playback and review, extremely flexible conform, advanced color grading, unlimited versioning, titling, compositing, finishing, and mastering to a variety of formats.
- Unmatched Flexibility
- SCRATCH seamlessly integrates via XML with other tools in your workflow such as Nuke, Shotgun, Avid, and Final Cut Pro. Extend dailies sessions for remote review and comment or create the kind of automated workflows and client tools that, until now, only the biggest facilities could afford.
- Pay-As-You-Use Upgrades
- SCRATCH lets you add new subscription options with volume purchasing and pay-as-you-use choices, so you can match your costs with your revenues.
- Real-Time Full Resolution Native Playback of Popular Formats
-
- Fully ACES compliant
- REDCODE RAW.r3d including monochrome footage
- Support for multiple RED Rocket cards with DRX control
- ARRI RAW including new Assimilate custom ARRI fast Debayer -- built for significant speed while still preserving color accuracy
- Sony F5, F55, F65, including 6K and 8K
- Sony MPEG-2 .MP4, .MOV, and XAVC HD/4K .MXF
- Phantom
- SI2K
- Panasonic P2/MXF and AVCHD
- Canon C500, C300, 5D, 7D
- Blackmagic Design Cinema DNG
- Aaton Penelope
- Ikonoscop
- GoPro
- QuickTime
- DPX
- Over 50 additional formats
- Powerful Finishing Tools
-
- Shot versioning: SCRATCH CONstruct manages multiple versions of the same 2D or 3D shots within the same timeline for easy comparison
- Vector paint
- Subtitling support
- Apply OFX plug-ins to create a wide range of visual effects
- Direct output: real-time tools for frame-rate conversion, image-resolution scaling, and frame accuracy to monitors, projectors, and tape decks using both DVI and SDI interfaces
- Multiple deliverables: create alternate versions in different resolutions, image formats, and framing, all from a single source
- Highly Interactive Color Grading
-
- Real-time, non-destructive primary and secondary color grading
- Heads-up color grading interface and support for Avid Artist Color panel series or all Tangent panels, including the Element
- Source-side adjustments for mixed color space workflows
- Match and auto grading
- 2D and shape tracking
- Keying based on Vector, Chroma, or Luminance
- Controls for finessing keys
- Integrated Histogram, Waveform, Vectorscope, and Color Curve views
- Group shots, copy/paste color grades and reference libraries
- Key frames and animation curves
- Import and save 1D and 3D LUTs based on primary color grades
- Enhanced DI Compositing Tools
-
- An enhanced compositing toolset, with a new 3D camera model featuring an improved OFX plug-in environment and plug-in workflow, allows full peer interactivity between all SCRATCH features and critical VFX plug-ins, such as Sapphire, Neat Video, ReelSmart Motion Blur, and Beauty Box
- Ability to nest layers and apply color grades to groups of layers
- New rendering features, including directional and motion blur, multi-sampling, and bit-map filtering
- Planar tracking data import from Imagineer System's mocha Pro v3. New support and process for Scratch users to import mocha's planar tracking data for transform, scale, rotation, and corner pin perspective. With the new mocha Pro to Scratch workflow, artists can seamlessly tackle the most difficult motion tracking shots for screen inserts, match moves, set extensions, and image stabilization
- Entirely New, Flexible Viewing Model
-
- Create dual views of any image in a project by quickly and easily selecting a version, a reference, a clip from any video track, or a color buffer
- Compare them using one of two methods: a difference method or an overlay method with opacity controls and a 360 degree wipe
- One of the dual views can be designated as an output view (showing the final result of a shot), while the other is a fully functional working canvas with access to even the deepest elements of a shot, including a complex composite or color grade
- Intuitively manipulate any element of the working view and instantly see its resulting effect updated to the output view at full resolution and in real time
- High-Speed Conform and Confidence Checking
-
- No other software offers the range of tools for quickly conforming and checking against a reference clip
- Mix-and-match RED.r3d files with ARRI RAW or Phantom (or any other media format recognized by SCRATCH), even Canon DSLR, within the same resolution-independent timeline
- Dual-View, Half-Mix, and Side-by-Side comparison options
- Quick Keys for moving through a timeline and edit tools for shot manipulation
- AAF import and MXF integration
- Import and export ALE
- Final Cut Pro XML import
- Shot log metadata import
- Metadata search
- Stereoscopic 3D versioning
- CDL support
- Output to multiple file formats such as DNxHD, DPX, ProRes, Tiff, JPG, QuickTime, MXF, and more
- Export with timecode and metadata
- Multilayer timeline
- Advanced Audio Sync
-
- Broadcast wave support
- Automatically sync to timecode or clapper
- Interactive waveform for sync
- Interactive audio scrub
- Stereo 3D Workflow Support
-
- Consistent, intuitive feedback during the conform, color grading, and finishing process
- Stereo image pairs are automatically linked for versioning and real-time playback to a wide variety of stereoscopic delivery systems
- Check and adjust stereo with dedicated link and convergence controls
- Bicubic controls for fixing 3D stereo images
- Position elements relative to the screen plane
- Immediately review decisions in stereo
- Panasonic 3D stereo camera support with automatic stream de-muxing
- Flexibility and Extensibility
- Future-proof support for OFX plug-ins an advanced and scriptable XML backend that allows you to:
- Extend SCRATCH with powerful OFX plug-ins such as Sapphire, BeautyBox, NeatVideo, and many more
- Seamlessly integrate SCRATCH with Avid Interplay and Isis via the ProductionLink plug-in from DiaQuest
- Automate SCRATCH with scripts to maximize productivity
- Integrate SCRATCH via XML with other tools in your workflow such as Nuke, Shotgun, or After Effects
Table of Contents
|
Upload User Manual
Have you got an user manual for the Assimilate SCRATCH in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAssimilate AI-PROSITE-SINGLE Specs | | | Operating System | Max OS X 10.6.7 or higher | | Processor | MacPro5,1 -- two 2.4 GHz Quad-Core Intel Xeon "Westmere" processors
A powerful Mac Pro will be required if you have video clips in a raw digital camera format, or for working with projects in HD, 2K, and 4K. | | Graphics | SCRATCH is fully accelerated by GPU technology. The following GPU cards are supported by the Mac version of SCRATCH:
NVIDIA Quadro 4000
AMD Radeon HD 5770 and 5870 cards (requires Lion or better)
Always check on the Assimilate Support Website for which driver to install for your card as not all drivers are tested. | | RAM | Minimum of 12 GB | | Storage | Whether Direct Attached or SAN storage, bandwidth is a key factor in getting real-time playback performance. For example, if you wish to maintain 2K stereo real-time playback, you will need to sustain 1000MB/sec. Assimilate recommends a 10 bay internal or external RAID storage for media files. | | Monitoring | NVIDIA Quadro cards offer dual DVI outputs, and SCRATCH allows you to configure the second as a full-screen output that will not have the user interface overlaid on it and can be used as a clean feed for projection, client monitoring or output to a tape deck.
Dual monitor resolutions up to HD:
Mac dual monitor requirements are a passive converter Display Port to DVI converter then DVI to DVI that only supports HD resolution.
Dual monitor resolutions up to 2560 x 1600:
An active Dual Link DisplayPort to DVI adapter is needed to get full 2560px, since the NVIDIA Fermi series only has one DVI port and 2 display ports. | | SDI Output | SCRATCH supports SDI output (with embedded audio) for SDI monitoring and SDI playout on Mac OS X via:
1) The AJA Kona 3 and 3G cards
2) Bluefish444 Epoch | 2K Ultra card | | Drivers | The current graphics drivers you need are both the CUDA driver 3.2.17 for Mac OS X and the NVIDIA retail 256.01 driver (you need them both). | | Additional Considerations | If you plan on using a RED Rocket card you will need a PCIe x16 slot. | | | | Operating System | Optimized for Windows 7, 64-bit | | Processor | Single Xeon i5 or i7 minimum; dual recommended | | Graphics | SCRATCH is fully accelerated by GPU technology. The following GPU cards are supported by the Windows version of SCRATCH:
NVIDIA Quadro 6000
AMD FirePro W8000 and V7900
Always check on the Assimilate Support Website for which driver to install for your card as not all drivers are tested. | | RAM | Minimum of 12 GB | | Storage | Whether Direct Attached or SAN storage, bandwidth is a key factor in getting real-time playback performance. For example, if you wish to maintain 2K stereo real-time playback, you will need to sustain 1000MB/sec. Assimilate recommends a 10 bay internal or external RAID storage for media files. | | Monitoring | NVIDIA Quadro cards offer dual DVI outputs, and SCRATCH allows you to configure the second as a full-screen output that will not have the user interface overlaid on it and can be used as a clean feed for projection, client monitoring or output to a tape deck. | | SDI Output | SCRATCH supports SDI output (with embedded audio) for SDI monitoring and SDI playout on Windows via:
1) Quadro SDI output daughter card for NVIDIA Quadro 6000
2) AMD V7900 with an AJA Kona 3 or 3G card
3) Bluefish444 Epoch | 2K Ultra card
4) Bluefish444 Epoch | 4K Supernova card | | PCI-Express | To add additional cards for SDI, audio, and RED Rocket cards, aim for as many x16 sized PCI-E slots as you can. | | Audio | Stereo monitoring is available via the on-board audio (speaker) output. For "advanced" monitoring, including multi-channel audio, and playout to tape, a professional audio card like the Lynx AES16e, or a combination SDI/audio card like the BlueFish444 can be used. If you have purchased the NVIDIA SDI daughter card, there is no need for an additional audio card, as the SDI option also gives you embedded audio. | | Additional Considerations | RED r3d Decoding:
SCRATCH can perform RED r3d decoding at various resolutions and de-bayer qualities to match the real-time performance of your computer hardware. If one or two RED Rocket cards are installed, full resolution and premium de-bayer quality can be achieved (in stereo with two cards).
Grading Panel:
SCRATCH can be driven from the Avid Artist Color panel series or all Tangent panels including the Element, CP200, and Wave panels. |
