User Manual for Astro Design Inc WM-3215 15" Dual Link HD SD Portable Waveform & Vector Scope LCD Monitor Click to enlarge the picture
Contents of the user manual for the Astro Design Inc WM-3215 15" Dual
- Product category: Waveform Monitors & Scopes Astro Design Inc
- Brand: Astro Design Inc
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Astro Design Inc Waveform Monitors & Scopes
|
User manual for the Astro Design Inc WM-3215 15" Dual contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Astro Design Inc product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Astro Design Inc user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Astro Design Inc product will considerably shorten its lifespan!
|
Product description The WM-3215 15" Dual Link HD/SD Portable Waveform & Vector Scope LCD Monitor from Astro Design is a measurement tool that offers functions such as image confirmation monitoring, waveform monitoring, and vector scoping. It accepts full HDTV and SDTV (525i and 625i) input signals and it can be powered off camera batteries. This solution is well suited for monitoring signals during relay, work at location sites, or studio applications, among other possible uses. - Measurement Tool
- Use this unit for functions such as image confirmation monitoring, waveform monitoring, and vector scoping.
- HDTV & SDTV Compatible
- The monitor accepts HDTV and SDTV (525i and 625i) input signals.
In the Box Astro Design Inc WM-3215 15" Dual Link HD/SD Portable Waveform & Vector Scope LCD Monitor Monitor One-Year Warranty Against Defects in Material & Workmanship Table of Contents
|
Upload User Manual
Have you got an user manual for the Astro Design Inc WM-3215 15" Dual Link HD SD Portable Waveform & Vector Scope LCD Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAstro Design Inc WM-3215 Specs Input | (2) HD-SDI/D1-SDI inputs, SMPTE 372M, SMPTE-292M, BTA-S004B; D1-SDI: SMPTE-259M | Output | (1) output for SDI confirmation | Formats | 1920 x 1080 (60i/59.94i) 1920 x 1035 (60i/59.94i) 1920 x 1080 (50i) 1920 x 1080 (30p/29.97p) 1920 x 1080 (25p) 1920 x 1080 (24p/23.98p) 1920 x 1080 (30sF/29.94sF) 1920 x 1080 (25sF) 1920 x 1080 (24sF/23.98sF) 1280 x 720 (60p/59.94p) 1280 x 720 (50p) 1280 x 720 (30p/29.97p) 1280 x 720 (25p) 1280 x 720 (24p/23.98p) 720 x 487 (59.94i) 720 x 487 (50i) *field frequency of 1/1.001 is automatically supported | Display | 15" LCD a-Si TFT Liquid Crystal | Power | Power voltage: 12VDC (10 to 18V) (Canon connector/camera battery) Power consumption: approximately 35W | Dimensions | 11 x 13.77 x 2.75" (280 x 350 x 70) | Weight | 11 lbs (5kg) |
