Product description The ASUS H110M-E/M.2 LGA 1151 Motherboard features a micro-ATX form factor that fits in small cases, letting you build a compact computer. It sports an LGA 1151 socket and Intel H110 chipset to support dual-channel DDR4 memory and Intel's 6th-generation of processors. The two DIMM slots are capable of handling up to 32GB of DDR4 2133 MHz memory modules. For storage and optical drives, this motherboard offers four SATA III ports as well as a single M.2 slot.
The H110M-E/M.2 delivers up to 4K visuals through the HDMI and VGA ports by utilizing your processor's integrated Intel HD Graphics engine. To render detailed 3D textures, it comes with a PCIe 3.0 x16 slot so you can install a dedicated graphics card. For audio, a Realtek ALC887 processor and three audio jacks are on board. Other notable connections include a Gigabit Ethernet port along with four USB 2.0 and two USB 3.0 ports. Furthermore, the H110M-E/M.2 comes with two PCIe 2.0 x1 slots so you can outfit your system with additional capabilities. - Intel H110 Chipset
- Intel's single-chipset design supports 6th-generation Intel LGA 1151 Core i7, Core i5, Core i3, Pentium, and Celeron processors. It provides improved performance by utilizing serial point-to-point links, allowing increased bandwidth and stability. It natively supports up to four USB 3.0 ports, delivering up to ten times faster transfer speeds than USB 2.0. Moreover, the Intel H110 chipset supports iGPU functions, providing Intel integrated graphics performance.
- Ready for 6th-Generation Intel Processors
- This motherboard supports 6th-generation Intel Core i7, i5, i3, Pentium, and Celeron processors in the LGA1151 package. With graphics, memory, and PCI Express controllers integrated, it supports onboard graphics output with dedicated chipsets, dual-channel (2-DIMM) DDR4 memory, and 16 PCI Express 3.0/2.0 lanes.
- 5X Protection II
- The H110M-E/M.2 is built with an intelligent DIGI+ VRM as well as resettable fuses to provide protection and stability for your build. It comes with a corrosion-resistant stainless steel back I/O panel that is designed to last three times longer than ordinary panels. With an active protective circuit design, it is capable of up to +/- 10kV for air discharge and +/-6kV for contact discharge.
- UEFI BIOS
- The mouse-controlled graphical BIOS comes with EZ and Advanced Modes, which help you quickly find your way and improve the performance of your system. It lets you check Self-Monitoring, Analysis, and Reporting Technology (S.M.A.R.T) logs, control the speed of the fans, and change the settings of your DRAM and processor. You can also update to the latest BIOS version via the Internet within the BIOS. Moreover, it features a My Favorites menu, which stores your most used tuning options and preferred tools.
- Gaming Audio
- ASUS has equipped this motherboard with a Realtek ALC887 8-channel audio processor as well as Japanese audio capacitors to provide a warm, natural, and immersive sound. The audio is shielded with analog/digital separation, which reduces multi-lateral interference. Additionally, the left and right tracks are built on separate layers and illuminated with an LED design.
- Additional Features
-
- Component-free "safe zones" - minimize the risk of damage and short circuits caused by contact
- Q-Slot - is a large winged clip for removing or installing graphics cards
- Q-DIMM - easy installation or removal of memory modules
- Software Bundle
-
- Fan Xpert - helps ensure every fan achieves optimal cooling performance with low-noise levels
- AI Suite 3 - consolidates all ASUS features into one simple-to-use package, allowing you to supervise overclocking, energy consumption, fan speed, voltage, and more
UPC: 889349448595 In the Box ASUS H110M-E/M.2 LGA 1151 Micro-ATX Motherboard I/O Shield 2 x SATA 3 Gb/s Cables M.2 Screw Package Support DVD Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the ASUS H110M-E M.2 LGA 1151 Micro-ATX Motherboard in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersASUS H110M-E Specs | | | Chipset | Intel H110 | | CPU Socket | LGA 1151 | | | | USB | 2 x USB 3.1 Gen 1 Type-A
4 x USB 2.0 Type-A | | Display | 1 x VGA
1 x HDMI | | Audio | 3 x 3.5 mm | | Ethernet / Controller | 1 x Realtek 8111H Gigabit | | PS/2 | 2 x PS/2 | | | | Memory Slots | 2 x 288-Pin | | Memory Support | DDR4 1866, 2133 MHz | | Maximum Capacity | 32 GB | | ECC Support | Non-ECC Unbuffered | | | | SATA | 4 x SATA III | | M.2 | 1 | | U.2 | None | | RAID Support | None | | | | Expansion Slots | 1 x PCIe 3.0 x16
2 x PCIe 2.0 x1 | | USB | 1 x USB 2.0 Header (Supports 2 USB Type-A Ports)
1 x USB 3.1 Gen 1 Header (Supports 2 USB Type-A Ports) | | Multi-GPU Support | None | | Air Cooling | 1 x 4-Pin CPU
1 x 4-Pin System | | Power Connectors | 1 x 24-Pin Mainboard
1 x 4-Pin CPU | | LED Header | None | | Audio | 1 x S/PDIF | | Diagnostics | Clear CMOS | | Legacy | 1 x Serial | | | | I/O Connection Headers | AAFP | | | | Audio Codec | Realtek ALC887 (8-Channel) | | | | Supported Operating Systems | Windows 10 (64-Bit)
Windows 8/8.1 (64-Bit)
Windows 7 (32/64-Bit) | | | | Form Factor | Micro-ATX | | Dimensions | 8.9 x 7.3" / 22.6 x 18.5 cm | | | | Package Weight | 1.6 lb | | Box Dimensions (LxWxH) | 9.95 x 9.0 x 2.1" |
