Product description Powered exclusively by 9th Generation Intel processors, the Prime H310M-C R2.0/CSM LGA 1151 Micro-ATX Motherboard from ASUS provides enhanced features to smooth your IT operations, including system protection, 24/7 stability and reliability, and an improved management suite for easier customization. This motherboard also features ASUS Corporate Stable model, which offers complimentary advance replacement and a long lifecycle, plus ASUS Shield, which helps keep hardware and data protected with a self-recovering BIOS and anti-moisture coating. Fixed-position and color-coded connections allow for the identification and assembly to optimize production line installation, while an LPC debug header streamlines troubleshooting.
ASUS' Prime H310M-C R2.0/CSM features a micro-ATX form factor, the H310 chipset, LGA 1151 socket, and supports Windows 10 (64-bit). It supports up to 32GB of 2666, 2400, or 2133 MHz non-ECC, unbuffered memory over two 288-pin DIMM slots. Add storage using the four SATA III ports and one M.2 Socket 3, which supports M.2 2260 and 2280 SATA and PCIe x2 drives, and expand your system with add-in cards via one PCIe 3.0/2.0 x16 slot, two PCIe 2.0 x1 slots, and one PCI slot. Audio is driven by the Realtek ALC887 8-channel HD audio codec and network connectivity is achieved using the Realtek 8111H Gigabit LAN controller. Included are two SATA III 6 Gb/s cables, an I/O shield, and an M.2 screw package. General Features - Business Motherboard
- ASUS' lineup of business motherboards provide enhanced features to smooth your IT operations, including comprehensive system protection, 24/7 stability and reliability, and an improved management suite for easier customization. Combined with their after-sales service and guaranteed long-term availability to maximize your investment over the product lifecycle, ASUS business motherboards provide a high-quality, TCO-optimized solution for your business computing needs.
- ASUS Corporate Stable Model
- ASUS Corporate Stable Model (CSM) is a commercial program designed to provide stable and reliable motherboards. It offers up to 36-month product lifecycle support and 6-month end-of-life notice to allow sufficient lead times for your organization to get ready for product transitions. Each purchase of an ASUS CSM motherboard comes with ASUS Control Center, a server-grade IT management software.
- Internationally Certified Business Motherboard
- ASUS business motherboards are enterprise proven and certified by multiple international safety and environmental organizations, including UL and Blue Angel. ASUS business motherboards provide a safe, secure, and sustainable solution, making them a good choice for your business.
ASUS Shield - ASUS Shield
- ASUS Shield enhances system security.
- ASUS Self-Recovering BIOS
- ASUS-exclusive BIOS protection technology automatically recovers the system BIOS with a verified backup in the event of an update failure, preventing the need to replace or reinstall hardware.
- ASUS Secure Boot
- Checks the firmware and signature of each piece of boot software.
- Trusted Platform Module (TPM)
- Hardware-based security offers better data protection, enhances network security, protects digital identities, and ensures platform integrity.
- Certified NIST SP 800-147
- Certified by the national computer security standards.
- ASUS Self-Recovering BIOS
- With ASUS Self-Recovering BIOS, the user simply needs one step to restore the latest BIOS update. It ensures safe BIOS updates, reduces maintenance frequency and costs, requires no extra software, and provides automatic update failure detection and recovery. To reinstall a BIOS update, users need to prepare a USB drive or hard drive, save required files to that drive, reset, and restart the BIOS update.
ASUS Reliant - ASUS Reliant
- ASUS Reliant helps ensure consistent performance with strong components and rigorous reliability testing.
- ASUS Trouble Shooting Solution
- ASUS Debug Header is a 10-1 pin low pin count (LPC) header for connecting to debug cards for faster, more efficient motherboard troubleshooting. When connected to an ASUS Debug Card, administrators can view error and debugging codes on the integrated LCD display, and get better idea of initialization and recovery processes. ASUS business motherboards provide a complete troubleshooting solution, making mass production faster and more cost effective.
- 24/7 Reliability Test
- Optimized for 24/7 operations, the motherboard is tested under temperature up to 113°F / 45°C and relative humidity up to 80% to ensure it can handle diverse temperature and humidity ranges of different location.
- Anti-Moisture Coating
- A moisture-resistant coating protects the motherboard in humid environments, such as factories, libraries, data centers, and internet cafes. It also minimizes internal corrosion by preventing adhesion and migration of moisture, prolonging the life of the motherboard.
- Anti-Sulfur Resistors
- Considering long-term reliability of commercial product, this motherboard is equipped with anti-sulfur resistors. The resistors provide excellent resistance to sulfuration by construction in a high-grade ceramic body (aluminum oxide). With anti-sulfur resistors, this motherboard can be operated in harsh environments.
- LANGuard
- ASUS LANGuard is hardware-level networking protection that employs signal-coupling technology and anti-EMI surface-mounted capacitors ensuring a more reliable connection and better throughput, plus electrostatically guarded and surge-protected components for greater tolerance to static electricity and improved protection against surges.
- Overvoltage Protection
- A circuit design with built-in voltage regulators to protect your chipset, connectivity ports, and audio codecs from damage caused by unexpected high-level voltages from unstable or inferior power supplies.
- Stainless-Steel Back I/O
- Corrosion-resistant stainless steel back I/O panels bonded with chromium oxide have a lifespan that's up to three times longer than ordinary panels.
- ESD Guards
- ASUS ESD Guards help prevent damage from electrostatic discharge, up to ±10kV for air discharge and ±15kV for contact discharge, arranged in an active-protective-circuit design that prolongs the life of components.
ASUS Management Suite - ASUS Management Suite
- The ASUS Management Suite makes customization and management more efficient.
- Event Log
- A built-in event log enables easier troubleshooting by capturing useful system information.
BIOS Updates
Update status, latest version, and update time.
AC Power Loss
Abnormal power loss events.
RTC Reset
Time of real-time-clock (RTC) reset.
Chassis Intrusion
Record of when the chassis is opened.
Hardware Changes
Modifications to the CPU, memory, or hard drives.
Hardware Status
USB over current, CPU over temperature, and CPU over voltage events. ASUS Control Center - ASUS Control Center
- The ASUS Control Center is centralized IT management software designed to provide a convenient, effective, secure, and cost-saving solution for enterprises, small- and medium-sized businesses, and data centers in any type of industry. With the help of ASUS Control Center, your organization will be equipped to achieve success in even the most challenging modern IT environments.
- Optimize IT Endpoint Management
- Designed to assist IT staff in monitoring and controlling devices within their corporate networks, and facilitate inventory checking in multiple locations remotely.
- Automate IT Maintenance
- Allows IT staff to schedule automatic updates of the latest BIOS, software, and utilities to specific or all devices at off-peak times, enhancing system stability and IT operational flexibility.
- Securely Manage Endpoints
- Securely manage endpoint configuration, portable storage access, and PC software applications by enabling them to create grouping rules on individual devices.
ASUS Commercial BIOS Kit - BIOS Value Edit Tool
- Customize the BIOS options.
- BIOS Boot Logo Tool
- Brand your builds with a customized boot logo.
- OEM Activation (OA) Tools
- Add or remove the OEM Activation key.
- Desktop Management Interface (DMI)
- Easily add customer information, such as company name, to the BIOS.
- Intel Management Engine (Intel ME) Driver
- Update the Management Engine without flashing the whole BIOS.
User-Friendly Assembly - Box Headers
- All USB 3.1 Gen 1 and 2.0 headers are box style, enabling fast connector installation and preventing pin damage.
- Fixed-Position Connectors
- Connector positions on ASUS business motherboards remain consistent across product generations, protecting training, manufacturing, and investments in supporting hardware.
- Color-Coded Connectors
- Color-coded connectors enable easy identification and cable-matching, speeding up the production line.
- Q-Slot
- The large winged clip is easy to reach and easy to operate. Just press the Q-Slot clip lightly, and graphics card just pop out. Installing or removing even the biggest graphics cards is not a problem.
- Q-DIMM
- Even if you work with a smaller case, just push down on the one-sided clip and push or pull RAM modules in or out. Removing memory is that simple.
Intel CPU & Chipset - Intel H310 Chipset
- The Intel H310 is a single-chipset design that supports 8th Generation Intel Core LGA 1151 processors. It provides improved performance by utilizing serial point-to-point links, allowing increased bandwidth and stability. Additionally, the H310 chipset provides a maximum of four USB 3.1 Gen 1 ports, four SATA III 6 Gb/s ports, and 10 Gb/s M.2 and PCIe 2.0 lane speed support for faster data retrieval. Intel H310 also supports integrated-graphics, so you'll enjoy the very latest in graphics performance.
- Ready for 8th Generation Intel LGA 1151 Core Processors
- This motherboard supports 8th Generation Intel Core processors in the LGA 1151 package, with integrated graphics, memory, and PCI Express controllers to support onboard graphics output with dedicated chipsets, dual-channel (2-DIMM) DDR4 memory, and 16 PCI Express 3.0/2.0 lanes for great performance.
UPC: 192876124604 In the Box ASUS Prime H310M-C R2.0/CSM LGA 1151 Micro-ATX Motherboard 2 x SATA III 6 Gb/s Cables I/O Shield M.2 Screw Package Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the ASUS Prime H310M-C R2.0 CSM LGA 1151 Micro-ATX Motherboard in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersASUS PRIME H310M-C R2.0/CSM Specs | | | Chipset | Intel H310 | | CPU Socket | LGA 1151 | | | | USB | 2 x USB 3.1 Gen 1 Type-A
4 x USB 2.0 Type-A | | Thunderbolt | None | | Display | 1 x DVI-D
1 x VGA | | Audio | 3 x 3.5 mm | | Ethernet / Controller | 1 x Realtek 8111H Gigabit | | PS/2 | 2 x PS/2 | | Legacy | 1 x Serial | | | | Memory Slots | 2 x 288-Pin | | Memory Support | DDR4 2133, 2400, 2666 MHz | | Maximum Capacity | 32 GB | | Channel Architecture | Dual Channel | | ECC Support | Non-ECC Unbuffered | | | | SATA | 4 x SATA III | | M.2 | 1 x M Key 2260, 2280 (PCIe (Unspecified), SATA (Unspecified)) | | U.2 | None | | RAID Support | None | | | | Expansion Slots | 1 x PCIe 3.0 x16
2 x PCIe 2.0 x1
1 x PCI | | USB | 1 x USB 3.1 Gen 1 Header (Supports 2 USB Type-A Ports)
1 x USB 2.0 Header (Supports 2 USB Type-A Ports) | | Multi-GPU Support | None | | Air Cooling | 1 x 4-Pin CPU
1 x 4-Pin System | | Power Connectors | 1 x 24-Pin Mainboard
1 x 4-Pin CPU | | Security | Chassis Intrusion, TPM Module | | Audio | 1 x Speaker | | Diagnostics | Clear CMOS | | Legacy | 1 x Serial
1 x Parallel | | | | I/O Connection Headers | AAFP | | | | Audio Codec | Realtek ALC887 (8-Channel) | | | | Supported Operating Systems | Windows 10 (64-Bit) | | | | Form Factor | Micro-ATX | | Dimensions | 9.6 x 7.6" / 24.38 x 19.30 cm | | | | Package Weight | 1.775 lb | | Box Dimensions (LxWxH) | 10.7 x 10.4 x 2.1" |
