User Manual for ASUS ProArt PA24AC 24" 16:10 Adaptive-Sync HDR IPS Monitor Click to enlarge the picture
Contents of the user manual for the ASUS ProArt PA24AC 24" 16:10 Adaptive-Sync
- Product category: Computer Monitors ASUS
- Brand: ASUS
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ASUS Computer Monitors
 |
User manual for the ASUS ProArt PA24AC 24" 16:10 Adaptive-Sync contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ASUS product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ASUS user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ASUS product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More The ProArt PA24AC 24" 16:10 Adaptive-Sync HDR IPS Monitor from Asus is designed for professionals handling color-sensitive work and users who require high color accuracy. Specs-wise, it's built on an IPS (In-Plane Switching) panel that features a 1920 x 1200 WUXGA resolution, a 1000:1 static contrast ratio that can reach up to 8000:1 with HDR, a typical brightness rating of 350 cd/m², and support for up to 16.7 million colors. With these and HDR10 support combined, the ProArt PA24AC provides you with clear details and vivid colors. Once connected to your system via HDMI, DisplayPort, or even USB Type-C, it can be freely adjusted to best fit your viewing preference. For your convenience, this monitor also has a built-in USB 3.0 hub for quickly and easily connecting USB peripherals and device - Color Quality
- The ProArt PA24AC covers 100% of the sRGB color gamut, supports 8-bit color graphics for up to 16.7 million colors, uses a 14-bit internal lookup table, and supports gamma values of 2.6, 2.4, 2.2, 2.0, and 1.8 for smoother transitions between hues.
- HDR Support
- Supporting HDR-10 high dynamic range technology and VESA DisplayHDR 400 certified, the ProArt PA24AC has a maximum brightness rating of 400 cd/m² for brighter whites and darker blacks.
- ProArt Calibration Technology
- The is monitor is factory calibrated with a color accuracy rating of a delta E value of less than two as well as a 95% uniformity compensation. Moreover, it's built with ProArt Calibration Technology to offer you color and uniformity adjustments whenever you need it.
- USB Type-C
- Aside from standard uses, the USB Type-C port on this display also supports DisplayPort video as well as 60W of power delivery, so you can use it as a one-cable solution with your mobile device.
- PIP & PBP
- Use its Picture-in-Picture (PIP) and Picture-by-Picture (PBP) functions to view content from multiple sources and multitask efficiently. You can also select which audio source to play from.
- QuickFit Virtual Scale
- Asus QuickFit Virtual Scale provides you with an onscreen grid overlay of paper sizes, rulers, and more, so you can align and preview documents in their actual size before printing.
- Asus Eye Care Technology
- Asus Eye Care Technology includes blue light filtering and flicker reduction to reduce eyestrain and fatigue over extended viewing sessions.
UPC: 192876088111 In the Box ASUS ProArt PA24AC 24" 16:10 Adaptive-Sync HDR IPS Monitor Power Cable DisplayPort Cable HDMI Cable USB Type-C Cable USB Type-C to Type-A Cable Limited 3-Year Warranty User Manual PDF 3.7mb More info from ASUS Table of Contents
|
Upload User Manual
Have you got an user manual for the ASUS ProArt PA24AC 24" 16:10 Adaptive-Sync HDR IPS Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersASUS ProArt Specs | | | Size | 24.1" | | Screen Area | 20.41 x 12.76" / 518.4 x 324 mm | | Panel Type | IPS-Type LCD | | Touchscreen | No | | Resolution | 1920 x 1200 | | Aspect Ratio | 16:10 | | Pixels Per Inch (ppi) | 94 ppi | | Maximum Brightness | 350 cd/m2 | | Contrast Ratio | 1000:1 | | Dynamic Contrast Ratio | 100,000,000:1 | | Adaptive Sync Technology | Adaptive-Sync | | Horizontal Frequency | 30 to 85 kHz | | Vertical Frequency | 48 to 70 Hz | | Bit Depth / Color Support | 8-Bit (16.7 Million Colors) | | Look-Up Table | 14-Bit | | HDR Compatibility | HDR10 | | Color Gamut | 100% sRGB | | Response Time | 5 ms (GtG) | | Viewing Angle | Horizontal: 178°
Vertical: 178° | | | | Connectivity | 2 x HDMI 2.0a
1 x DisplayPort 1.2
1 x USB Type-C (USB 3.1 Gen 1)
4 x USB Type-A (USB 3.1 Gen 1)
1 x 3.5 mm Output | | HDCP Support | Yes, Version 2.2 | | Built-In Speakers | Yes, 2 x 2 W | | | | Power Consumption | 21 W (Typical)
0.5 W (Standby) | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz | | USB Power Delivery | 60 W | | | | Certifications | BSMI, CCC, CE, FCC, Kcc, Microsoft WHQL, RoHS, TUV, UL, VCCI, WEEE, cUL, as per Manufacturer | | | | Height Adjustment | 4.33" / 110 mm | | Rotation Adjustment | 180° (-90 to 90°) | | Swivel Adjustment | 90° (-45 to 45°) | | Tilt Adjustment | -5 to 23° | | Mounting-Hole Pattern | 100 x 100 mm | | Lock Slot | Yes, Kensington | | Dimensions (W x H x D) | 21.0 x 19.2 x 8.0" / 533.4 x 487.7 x 203.2 mm (With Stand)
21.0 x 13.7 x 2.2" / 533.4 x 348.0 x 55.9 mm (Without Stand) | | Weight | 14.3 lb / 6.49 kg (With Stand)
9.4 lb / 4.26 kg (Without Stand) | | | | Package Weight | 19.8 lb | | Box Dimensions (LxWxH) | 25.5 x 16.5 x 10.0" |
