User Manual for ASUS Republic of Gamers Swift PG258Q 24.5" 16:9 240 Hz G-Sync LCD Gaming Monitor Click to enlarge the picture
Contents of the user manual for the ASUS Republic of Gamers Swift PG258Q
- Product category: Computer Monitors ASUS
- Brand: ASUS
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ASUS Computer Monitors
 |
User manual for the ASUS Republic of Gamers Swift PG258Q contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ASUS product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ASUS user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ASUS product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More With a 240 Hz native refresh rate, the Republic of Gamers Swift PG258Q 24.5" 16:9 240 Hz G-Sync LCD Gaming Monitor from ASUS offers reduced lag and blur even when playing fast paced racing and first person shooter games. In addition to the enhanced refresh rate this Republic of Gamers monitor also features an ultra-fast 1 ms response time and support for NVIDIA G-Sync technology, which syncs the monitors refresh rate to the graphics card refresh rate essentially eliminating all ghosting and blur within the game. The TN (Twisted Nematic) panel also features a Full HD 1920 x 1080 resolution, a 1,000:1 static contrast ratio, and support for up to 16.7 million colors.
If a 1ms response time, 240 Hz refresh rate, and G-Sync technology aren't enough, this monitor also comes with ASUS GamePlus technology, which includes a variety of gaming modes to suit the type of game you're playing. This along with other display technologies can be configured using the built-in 5-way OSD joystick found on the back of the display.
Setup and configuration of the ASUS ROG PG258Q is simple as it comes equipped with both DisplayPort and HDMI inputs as well as USB 3.0 connectivity and a built-in headphone jack. The stand even features smart cable management to hide annoying cables right within the back of the monitor. Once configured this high-performance gaming monitor comes equipped with eye care technologies including Ultra-Low Blue Light and Flicker-Free support to ensure your eyes remain fresh during marathon gaming sessions. The stand can also be pivoted, tilted, and the height can be adjusted to ensure maximum viewing comfort. - 240 Hz Refresh Rate
- The ROG Swift PG258Q offers an enhanced 240 Hz native refresh rate, which makes it twice as fast as conventional 120 Hz monitors.
- NVIDIA G-Sync Technology with Ultra Low Motion Blur
- Coupling ROG Swift PG258Q's 240 Hz refresh rate with NVIDIA G-SYNC technology results in a smooth gaming experience. G-SYNC synchronizes the monitors refresh rate to the GeForce GTX graphics card in your PC or laptop to eliminate screen tearing and to minimize display stutter. There's also the Ultra Low Motion Blur (ULMB) technology to make objects in motion look sharper, so gameplay is more fluid and responsive.
- 1 ms Rapid Response Time
- The ROG Swift PG258Q features a 1 ms response time to eliminate smearing and motion blur. It's especially useful in fast-paced games.
- Customizable Light Signature
- Light Signature lets you create and customize ROG Swift PG258Q's light projection effects. It includes two ROG logo covers, and three blank covers that you can customize with a marker to create your own unique light projections, to add ambience to your gaming set up.
- GamePlus Technology
- The ASUS-exclusive GamePlus hotkey provides in-game enhancements like a crosshair overlay, an onscreen timer, a frames per second counter, and a display alignment function.
- GameVisual Technology
- ASUS GameVisual Technology offers six display mode presets to optimize visuals for different types of content.
• RTS / RPG
• FPS
• sRGB
• Scenery
• Racing
• Cinema - OSD Navigation Joystick
- A 5-way navigation joystick and four hotkeys on the right-rear of the monitor keep display settings and advanced gaming features within easy reach.
- NVIDIA 3D Vision-Ready
- The ROG Swift PG258Q is compatible with the NVIDIA 3D Vision 2 kit to open a world of 3D gaming. All you need is a NVIDIA GeForce graphics card and 3D glasses for a more immersive gaming and movie-watching experience. Additionaly, with the latest NVIDIA 3D LightBoost Technology, you'll enjoy brighter 3D visuals without an increase in energy consumption.
- Multi-Display Setups
- The PG258Q features a frameless design, which is nearly seamless for multi-display setups for an even greater degree of immersion.
- Robust Cable Connectivity and Cable Management
- ROG Swift PG258Q has a wide selection of connectivity options including DisplayPort 1.2 and HDMI. There are also two USB 3.0 ports for your mouse and keyboard.
- Ultra-Low Blue Light Technology
- ROG Swift PG258Q comes with the ASUS Ultra-Low Blue Light filters to protect you from harmful blue light. You can easily access and select four different filter settings onscreen through the 5-way joystick.
- Flicker-Free Technology
- Flicker-free technology helps reduce onscreen flicker, giving you a more comfortable, marathon-ready gaming environment. It is designed to minimize eyestrain, headaches and eye fatigue when you're embroiled in long, drawn-out gaming sessions.
- Ergonomic Adjustable Stand
- The ROG Swift PG258Q is specially designed for marathon gaming sessions. It has an ergonomically-designed stand with tilt, pivot, and height adjustment so you can always find that ideal viewing position whether you're on the couch or sitting on your bed.
- Smart Air Vent Design
- The ROG Swift PG258Q features a custom heatsink that's twice the size of those found in other monitors to ensure it stays cool during marathon gaming sessions. Cooling is also aided by a Smart Air Vent design that uses convection currents to generate airflow within the monitor. This fanless cooling system ensures that ROG Swift PG258Q operates silently and stays maintenance-free.
UPC: 889349589892 In the Box ASUS Republic of Gamers Swift PG258Q 24.5" 16:9 240 Hz G-Sync LCD Gaming Monitor Power Cord Power Adapter DisplayPort Cable USB 3.0 Cable Acrylic LED Light Covers HDMI Cable Limited 3-Year Warranty User Manual PDF 4.7mb More info from ASUS Table of Contents
|
Upload User Manual
Have you got an user manual for the ASUS Republic of Gamers Swift PG258Q 24.5" 16:9 240 Hz G-Sync LCD Gaming Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersASUS PG258Q Specs | | | Size | 24.5" | | Panel Type | TN LCD | | Touchscreen | No | | Resolution | 1920 x 1080 | | Aspect Ratio | 16:9 | | Finish | Matte | | Maximum Brightness | 400 cd/m2 | | Contrast Ratio | 1000:1 | | Refresh Rate | 240 Hz | | Adaptive Sync Technology | G-Sync | | Horizontal Frequency | 67 to 255 kHz (DisplayPort)
30 to 90 kHz (HDMI) | | Vertical Frequency | 24 to 60 Hz (HDMI)
30 to 240 Hz (DisplayPort) | | Bit Depth / Color Support | 8-Bit (16.7 Million Colors) | | Response Time | 1 ms (GtG) | | Viewing Angle | Horizontal: 170°
Vertical: 160° | | | | Connectivity | 2 x USB Type-A (USB 3.1 Gen 1)
1 x DisplayPort Input
1 x HDMI | | HDCP Support | Yes | | | | Power Consumption | 0.5 W (Standby)
65 W (Typical) | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz | | | | Certifications | RoHS, WEEE, as per Manufacturer | | | | Height Adjustment | 4.7" / 11.9 cm | | Rotation Adjustment | 90° | | Swivel Adjustment | 100° (-50 to 50°) | | Tilt Adjustment | -5 to 20° | | Mounting-Hole Pattern | 100 x 100 mm | | Lock Slot | Yes | | Dimensions (W x H x D) | 22.2 x 15.1 x 10.0" / 56.4 x 38.3 x 25.4 mm (With Stand)
22.2 x 13.0 x 2.9" / 56.4 x 33.1 x 7.3 mm (Without Stand) | | Weight | 12.3 lb / 5.6 kg (With Stand)
6.9 lb / 3.1 kg (Without Stand) | | | | Package Weight | 19.5 lb | | Box Dimensions (LxWxH) | 25.9 x 17.5 x 9.4" |
Rating74% users recommend this product to others. And what about you?
This product has already been rated by 84 owners. Add your rating and experience with the product.
