User Manual for ASUS Republic of Gamers Swift PG278QR 27" 16:9 165 Hz G-SYNC Eye Care Gaming Monitor Click to enlarge the picture
Contents of the user manual for the ASUS Republic of Gamers Swift PG278QR
- Product category: Computer Monitors ASUS
- Brand: ASUS
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ASUS Computer Monitors
 |
User manual for the ASUS Republic of Gamers Swift PG278QR contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ASUS product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ASUS user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ASUS product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More With four times the resolution of a standard 720p display, the Republic of Gamers Swift PG278QR 27" 16:9 165 Hz G-Sync Eye Care Gaming Monitor from ASUS offers a QHD resolution of 2560 x 1440 and up to 77% more onscreen display space over standard Full HD. With 108 pixels per inch, you can see your movies, games, videos, and other multimedia content with enhanced clarity, while the fast 1 ms (GtG) response time provides reduced lag and blur for those fast moving game sequences.
Adding to the enhanced gaming experience, the response rate of 144 Hz, 165 Hz when overclocked, and 120 Hz in 3D mode helps to virtually eliminate motion blur, making it possible to see even the finest in game details regardless of how fast paced the game is. For on-the-fly changes to the refresh rate and other on screen configurations this ASUS monitor also features a 5-way directional OSD joystick and a refresh rate turbo key.
With HDMI 1.4, DisplayPort 1.2, and USB 3.0 ports located on the side of the display and an integrated cable management system, cables plugged into this ASUS monitor remain neat and organized. With VESA mount compatibility you can even mount this display to the wall, allowing you to take full advantage of the 170° horizontal and 160° vertical viewing angles. - Lifelike Gaming Visuals
- The ROG Swift PG278QR features a WQHD 2560 x 1440 panel that delivers four times the resolution of 720p and 109 pixels per inch. You get to enjoy greater image detail and up to 77% more onscreen desktop space than standard Full HD (1920 x 1080) displays.
- Smooth Graphics for Seamless Gameplay
- The ROG Swift PG278QR's gaming monitor 144 Hz refresh rate that can be overclocked to 165 Hz to reduce lag and motion blur giving you the upper hand in first person shooters, racers, real-time strategy, and sports titles.
- NVIDIA G-Sync Technology
- The ROG Swift PG278QR incorporates NVIDIA G-SYNC display technology to deliver smooth and fast. G-SYNC synchronizes the monitor's refresh rate to the GPU in your GeForce GTX-powered PC, eliminating screen tearing and minimizing display stutter and input lag. It lets you enjoy seamlessly-smooth and lag-free gameplay when playing the latest fast-paced first-person shooters, sports, and action-adventure titles.
- Gamer-Centric Technologies
- ASUS GameVisual Technology has six pre-set display modes (scenery, racing, cinema, RTS/RPG, FPS, sRGB) to optimize visuals for different types of content. This unique feature can be easily accessed through a hotkey or the On Screen Display (OSD) settings menu.
- Multi-Display Gaming
- The ROG Swift PG278QR's slim profile and super-narrow 6mm bezel makes it great for almost seamless multi-display setups so your eyes move swiftly from one monitor to another. It can also be VESA wall-mounted - an even easier way to have a multi-display gaming setup.
- Robust Connectivity
- The ROG Swift PG278QR monitor gives you flexible connectivity options for WQHD (2560 x 1440) input via its DisplayPort1.2 and HDMI ports. It also has two USB 3.0 ports for your mouse and keyboard, and can charge your mobile devices while gaming.
- Ultra-Low Blue Light Technology
- The ROG Swift PG278QR comes with the ASUS Ultra Low Blue Light filters to protect you from harmful blue light. You can easily access and select four different filter settings onscreen through a handy five-way joystick to easily jump through the On-screen display (OSD) menus to fulfill your different scenarios.
- Flicker Free Technology
- Flicker-Free technology reduces flicker to give you a comfortable gaming experience. This minimizes instances of eyestrain and other damaging effects when you're embroiled in long, drawn-out gaming sessions.
- Ergonomic Tilt, Swivel, Pivot, and Height Adjustable Stand
- The ROG Swift PG278QR is specially designed for marathon gaming sessions. It has an ergonomically-designed stand with tilt, swivel, pivot, and height adjustment so you can always find that ideal viewing position whether you're on the couch or sitting on your bed.
- Smart Vent Design
- The ROG Swift PG278QR employs a custom heatsink that's double the size to make sure the monitor stays cool during marathon gaming sessions. Cooling is also aided by a Smart Air Venting Design that uses convective currents to generate airflow. This passive setup works entirely without fans, making it completely silent and maintenance-free.
UPC: 889349470992 In the Box ASUS Republic of Gamers Swift PG278QR 27" 16:9 165 Hz G-SYNC Eye Care Gaming Monitor HDMI Cable DisplayPort Cable USB 3.0 Cable Power Adapter Power Cord Limited 3-Year Warranty User Manual PDF 4.6mb More info from ASUS Table of Contents
|
Upload User Manual
Have you got an user manual for the ASUS Republic of Gamers Swift PG278QR 27" 16:9 165 Hz G-SYNC Eye Care Gaming Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersASUS PG278QR Specs | | | Size | 27" | | Screen Area | 23.5 x 13.2" / 59.7 x 33.6 cm | | Panel Type | TFT LCD | | Touchscreen | No | | Resolution | 2560 x 1440 | | Aspect Ratio | 16:9 | | Pixels Per Inch (ppi) | 108 ppi | | Finish | Matte | | Maximum Brightness | 350 cd/m2 | | Contrast Ratio | 1000:1 | | Refresh Rate | 165 Hz | | Adaptive Sync Technology | G-Sync | | Horizontal Frequency | 30 to 140 kHz (HDMI)
34 to 222 kHz (DisplayPort) | | Vertical Frequency | 24 to 60 Hz (HDMI)
30 to 144 Hz (DisplayPort) | | Bit Depth / Color Support | 8-Bit (16.7 Million Colors) | | Response Time | 1 ms (GtG) | | Viewing Angle | Horizontal: 170°
Vertical: 160° | | Dot Pitch | 0.233 x 0.233 mm | | | | Connectivity | 1 x DisplayPort 1.2 Input
1 x HDMI 1.4 Input
2 x USB Type-A (USB 3.1 Gen 1) Output
1 x USB Type-B (USB 3.1 Gen 1) Input
1 x 3.5 mm Output | | HDCP Support | Yes | | Supported Languages | Croatian
Czech
Dutch
English
French
German
Hungarian
Indonesian
Italian
Japanese
Korean
Persian
Polish
Portuguese
Romanian
Russian
Simplified Chinese
Spanish
Thai
Traditional Chinese
Turkish | | | | Power Consumption | 0.5 W (Standby)
90 W (Typical) | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz | | Power Adapter Type | External | | DC Input Power | 19 VDC at 4.74 A | | | | Operating Temperature | 32 to 104°F / 0 to 40°C | | Storage Temperature | -4 to 140°F / -20 to 60°C | | Certifications | BSMI, C-Tick, CB, CCC, CE, ErP Lot 6, FCC, Kcc, Microsoft WHQL, PSE, RoHS, TUV, UL, VCCI, WEEE, cUL, as per Manufacturer | | | | Height Adjustment | 4.72" / 120 mm | | Rotation Adjustment | 90° (0 to 90°) | | Swivel Adjustment | 120° (-60 to 60°) | | Tilt Adjustment | -5 to 20° | | Mounting-Hole Pattern | 100 x 100 mm | | Lock Slot | Yes, Kensington | | Dimensions (W x H x D) | 24.4 x 21.8 x 9.4" / 620.0 x 553.0 x 238.0 mm (With Stand)
24.4 x 14.3 x 2.6" / 620.0 x 363.0 x 66.0 mm (Without Stand) | | Weight | 15.4 lb / 7 kg | | | | Package Weight | 22.5 lb | | Box Dimensions (LxWxH) | 29.5 x 18.0 x 12.0" |
