Product description The ROG Strix B350-F Gaming AM4 ATX Motherboard from ASUS comes built with an AMD AM4 socket and an AMD B350 chipset to support AMD's Ryzen, 7th-gen. A-series, and 7th-gen. Athlon processors. The motherboard provides four DDR4 DIMM slots, which allow you to install up to 64GB memory modules. For drive support, six SATA III connectors are on board along with one M.2 slot, which supports SATA- and PCIe-based M.2 SSDs. There's also a set of LEDs built into the motherboard to deliver a multi-colored glow inside your case.
The ROG Strix B350-F Gaming motherboard is outfitted with two PCIe 3.0 x16 slots as well as one PCIe 2.0 x16 slot to support AMD 3-way CrossFire X technology. With an APU installed, the motherboard delivers detailed visuals through its HDMI and DisplayPort outputs. To complete the multimedia experience, SupremeFX S1220A audio technology delivers 8-channel sounds through the motherboard's six audio jack.
Aside from sights and sounds, the motherboard has two USB 3.1, four USB 3.0, and two USB 2.0 ports to access your printers, external storage drives, and other useful USB devices. To provide a reliable and fast Internet experience, a Gigabit Ethernet port is available. In addition, the motherboard has three internal USB headers and three PCIe 2.0 x1 slots for adding additional ports. - AMD AM4 Socket
- This motherboard supports AMD Ryzen processors, 7th Generation A-series accelerated processing units (APUs), and Athlon CPUs. The Ryzen processor supports up to eight cores and is based on the Zen core architecture. The 7th Generation A-series APUs feature integrated AMD Radeon R-series graphics. AMD AM4-socket processors feature dual-channel DDR4 memory, native 5 Gb/s USB 3.0, and 16 PCI Express 3.0/2.0 lanes for enhanced performance.
- AMD B350 Chipset
- The AMD B350 chipset delivers overclocking capabilities for AMD AM4-socket Ryzen processors, 7th Generation A-series APUs, and Athlon APUs. It also provides two 10 Gb/s USB 3.1 ports and six 6 Gb/s SATA ports for fast data retrieval.
- Aura Lighting Control
- You can illuminate the insides of your case with built-in RGB LEDs and attach sold-separately RGB strips using the two onboard 4-pin headers. The LEDs are synchronized under different effect modes, including Static, Breathing, Strobing, Color Cycle, Music, CPU Temp., Rainbow, Comet, Flash & Dash, Wave, Glowing Yo Yo, and Starry Night. The RGB-strip header is compatible with 5050 RGB LED strips with a maximum power rating of 2A (12V). Additionally, an LED extension cable is included.
- Gaming Audio
- SupremeFX audio technology delivers 113dB signal-to-noise ratio on the line-in connection for high-quality recording. It includes a low-dropout regulator for clean power delivery to the SupremeFX S1220 codec along with a Texas Instruments RC4580 and OPA1688 op-amps for high gain with low distortion.
- One-Click Overclock and Cooling
- 5-Way Optimization sorts all the complex settings with a click, for instant controllable performance boosts. ROG technology dynamically optimizes essential aspects of your system, based on real-time use - so you can achieve improved CPU performance, everyday energy savings, ultra-stable digital power, cool and quiet fans, and networking settings, which are tailored for the apps that you are using.
- Games run swiftly and smoothly with high-performance and prioritized bandwidth
- Fans stay quiet for everyday computing and ensure cooling efficiency when gaming
- Stutter for smooth-running apps, even under heavy loads
- Energy waste is reduced
- Additional Features
-
- ASUS T-Topology circuit design provides memory-overclocking capability while minimizing coupling noise and signal reflection
- ASUS TurboV Processing Unit (TPU) provides enhance voltage and base-clock overclocking control
- Energy Processing Unit (EPU) automatically detects and adjusts power consumption according to your rig's needs
- Onboard thermal sensors and hardware-level 4-pin/3-pin PWM/DC mode detection for a balance of cooling performance and low noise
- Intel Ethernet controller I211-AT reduces CPU overhead and high TCP and UDP throughputs
- ASUS LANGuard features signal-coupling technology and ESD guards
- M.2 slot supports PCIe 3.0 x4 lanes to offer 32 Gb/s bandwidths
- USB 3.1 ports with 10 Gb/s speeds
- SafeSlot is a PCIe slot with fortifying metal and additional solder points to hold heavy graphics cards
- Q-LEDS indicate power status and problem with the processor, memory, graphics card, or boot device
- Resettable fuse protects connection ports and DRAM against overcurrent and short-circuit damage
- Q-Shield guards your hands from nicks and cuts
- Q-Slot helps you swap or secure a graphics card
- Q-DIMM is a one-sided clip for handling memory modules
- Customize your motherboard's appearance and improve system performance with printable parts
- VR ready
- Supports AMD 3-Way CrossFire X technology
- Software Features
-
- Sonic Studio III audio effects station has a routing feature that ports audio streams to different outputs, giving you full control over who hears what
- Sonic Radar III helps ensure you're aware of what's going on around you and provides an onscreen arrow to pinpoint the enemy position instantly
- ASUS Turbo app overclocks your CPU and prioritizes game data across your network
- RAMCache II effectively caches an entire storage device, so games and apps launch quickly
- UEFI BIOS is a mouse-controlled graphical BIOS that helps you adjust settings within the BIOS with EZ and Advanced modes
- GameFirst IV optimizes network traffic for faster, lag-free online gaming
- Overwolf is an unobtrusive overlay that keeps you in the game and allows you to browse the Web, email, IM, stream, or record while you play
- ROG Clone Drive quickly and efficiently replicates hard drives or SSDs
UPC: 889349747124 In the Box ASUS ROG Strix B350-F Gaming AM4 ATX Motherboard I/O Shield 4 x SATA 6 Gb/s Cables Package of M.2 Screws Support DVD Set of ROG Strix Stickers 10-in-1 ROG Cable Label Pack of Cable Ties 31.5" (80cm) RGB Extension Cable ROG Coaster Limited 3-Year Warranty User Manual PDF 5.7mb Table of Contents
|
Upload User Manual
Have you got an user manual for the ASUS ROG Strix B350-F Gaming AM4 ATX Motherboard in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersASUS B350-F Specs | | | Chipset | AMD B350 | | CPU Socket | AM4 | | | | USB | 2 x USB 3.1 Gen 2 Type-A
4 x USB 3.1 Gen 1 Type-A
2 x USB 2.0 Type-A | | Display | 1 x HDMI 1.4b
1 x DisplayPort 1.2 | | Audio | 5 x 3.5 mm
1 x S/PDIF | | Ethernet / Controller | 1 x Intel 1211AT Gigabit | | | | Memory Slots | 4 x 288-Pin | | Memory Support | DDR4 2133, 2400, 2666, 2933, 3200 MHz | | Maximum Capacity | 64 GB | | Channel Architecture | Dual Channel | | ECC Support | Non-ECC, ECC Unbuffered | | | | SATA | 6 x SATA III | | M.2 | 1 x M Key 2242, 2260, 2280, 22110 (PCIe 3.0 x4, SATA III) | | U.2 | None | | RAID Support | RAID 0, 1, 10 | | | | Expansion Slots | 2 x PCIe 3.0 x16
1 x PCIe 2.0 x16 (x4 mode)
3 x PCIe 2.0 x1 | | USB | 1 x USB 3.1 Gen 1 Header (Supports 2 USB Type-A Ports)
2 x USB 2.0 Header (Supports 4 USB Type-A Ports) | | Multi-GPU Support | 3-Way AMD CrossFireX | | Air Cooling | 2 x 4-Pin CPU
3 x 4-Pin System
1 x Thermal Sensor | | Liquid Cooling | 1 x 4-Pin Pump | | Power Connectors | 1 x 24-Pin Mainboard
1 x 8-Pin CPU | | Security | TPM Module | | LED Header | 2 x RGB | | Diagnostics | Clear CMOS | | Legacy | 1 x Serial | | | | I/O Connection Headers | AAFP | | | | Audio Codec | SupremeFX S1220A (8-Channel) | | | | Supported Operating Systems | Windows 10 | | | | Form Factor | ATX | | Dimensions | 12.0 x 9.6" / 30.5 x 24.4 cm | | | | Package Weight | 3.3 lb | | Box Dimensions (LxWxH) | 12.9 x 10.4 x 2.7" |
