User Manual for ASUS VB199T-P 19" 5:4 IPS Monitor Click to enlarge the picture
Contents of the user manual for the ASUS VB199T-P 19" 5:4 IPS Monitor
- Product category: Computer Monitors ASUS
- Brand: ASUS
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ASUS Computer Monitors
 |
User manual for the ASUS VB199T-P 19" 5:4 IPS Monitor contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ASUS product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ASUS user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ASUS product will considerably shorten its lifespan!
|
Product description 10 Factors to Consider When Selecting A Monitor for Video Editing Read More The VB199T-P 19" 5:4 IPS Monitor from Asus features an HD 1280 x 1024 resolution as well as an enhanced 5 ms response time, which helps to prevent lag while watching movies and videos. The mercury-free wide viewing angle LED-backlit panel with a 5:4 aspect ratio provides a standard picture quality with a 50,000,000:1 contrast ratio for improved image quality and sharp text. It saves energy with low power consumption, and hence reduces environmental pollution.
The VB199T-P comes with a variety of video features including six SPLENDID Video preset modes, three Skin-Tone Selections, and four Color Temperature Selections. You also benefit from two 1W stereo speakers eliminating the need for additional speakers when watching videos or listening to music. - Enhanced Video Performance
- The monitor has a 178° wide viewing angle LED panel to minimize the color shift from any viewing angle. With 5 ms (GtG) response time and 16.7 million display colors, the monitor delivers smooth video display. It also supports dual inputs of D-sub and DVI-D with HDCP.
- 50,000,000:1 ASUS Smart Contrast Ratio
- It also features ASUS Smart Contrast Ratio (ASCR) Technology to provide contrast ratio of 50,000,000:1, which can dynamically adjust contrast between black and white, and to create sharp and bright images, especially during video and movies.
- Splendid Video Intelligence Technology
- The Splendid Video Intelligence Technology optimizes video performance and image fidelity by enhancing color, brightness, contrast, and sharpness. Six preset video modes (scenery, theater, game, night view, sRGB, and standard) can be selected, via a hotkey.
- User-Friendly Design
- Built-in stereo speakers
Multi-language OSD
Convenient key controls
25° tilting angle
VESA Wall mount Standard (100 x 100mm)
Removable base
Kensington security lock
Compatibility with VGA cards - Eco-Friendly Design
- It features a mercury-free LED-backlit panel, and Eco mode further reduces energy consumption to 55%.
UPC: 886227759088 In the Box ASUS VB199T-P 19" 5:4 IPS Monitor DVI Cable VGA Cable Audio Cable Power Cord Limited 3-Year Warranty User Manual PDF 1.5mb Table of Contents
|
Upload User Manual
Have you got an user manual for the ASUS VB199T-P 19" 5:4 IPS Monitor in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersASUS VB199T-P Specs | | | Size | 19" | | Panel Type | IPS-Type LCD | | Touchscreen | No | | Resolution | 1280 x 1024 | | Aspect Ratio | 5:4 | | Maximum Brightness | 250 cd/m2 | | Dynamic Contrast Ratio | 50,000,000:1 | | Adaptive Sync Technology | None | | Horizontal Frequency | 53 to 80 kHz | | Vertical Frequency | 50 to 76 Hz | | Color Gamut | 72% NTSC | | Response Time | 5 ms (GtG) | | Viewing Angle | Horizontal: 178°
Vertical: 178° | | Dot Pitch | 0.293 x 0.293 mm | | | | Connectivity | 1 x DVI-D
1 x VGA | | Built-In Speakers | Yes, 2 x 1 W | | | | Power Consumption | 17.1 W (Typical)
0.3 W (Standby) | | AC Input Power | 100 to 240 VAC, 50 / 60 Hz | | | | Tilt Adjustment | -5 to 20° | | Mounting-Hole Pattern | 100 x 100 mm | | Lock Slot | Yes | | Dimensions (W x H x D) | 16.2 x 15.9 x 8.1" / 41.2 x 40.4 x 20.6 mm (With Stand)
16.3 x 13.5 x 2.6" / 41.3 x 34.2 x 6.5 mm (Without Stand) | | Weight | 7 lb / 3.2 kg | | | | Package Weight | 11.6 lb | | Box Dimensions (LxWxH) | 19.0 x 18.0 x 5.6" |
Rating90% users recommend this product to others. And what about you?
This product has already been rated by 56 owners. Add your rating and experience with the product.
