Product description The X99-E-10G WS LGA 2011-v3 CEB Motherboard from ASUS is designed to fit in cases that support the CEB form factor. It supports Intel Core i7 and Core i7-X processors in the LGA 2011-v3 package, as well as Xeon E5-1600 v3, E5-2600 v3, E5-1600 v4, and E5-2600 product families that support the Intel X99 chipset. This motherboard supports Windows 10, 8.1 (64-bit), and 7 (64-bit), has been designed for workstation, gaming, professional, and home server use, and is equipped with dual 10 Gigabit Ethernet LAN ports.
The CEB form factor of the X99-E-10G has 8 x DIMM slots that can support up to 128GB of non-ECC and unbuffered DDR4 RAM at speeds of 3333 (OC), 3200 (OC), 3000 (OC), 2800 (OC), 2666 (OC), 2400 (OC), and 2133 MHz. Additionally, up to 128GB of unbuffered ECC DDR4 RAM and registered ECC DDR4 RAM are supported at speeds of 2400 and 2133 MHz. This motherboard also supports quad-channel memory architecture and Intel Extreme Memory Profile (XMP).
The X99-E-10G has a total of 10 x SATA III 6 Gb/s ports, 1 x M.2 x4 Socket 3 port, and 1 x U.2 port. Internal expansion is accomplished using 7 x PCIe 3.0/2.0 x16 slots running single x16, dual x16/x16, triple x16/x16/x16, quad x16/x16/x16/x16, or seven x16/x8/x8/x8/x8/x8/x8. USB connectivity is achieved using 1 x USB 3.1 Type-C port (back panel), 1 x USB 3.1 Type-A port (back panel), 8 x USB 3.0/2.0 ports (4 on the back panel, 4 at mid-board), and 4 x USB 2.0/1.1 ports (4 at mid-board). There is also one COM port. Using the Realtek ALC1150 codec, it can support 8-channel HD audio using its eight audio jacks or one optical S/PDIF jack.
The X99-E-10G does not contain integrated graphics, meaning that the user will need to purchase a dedicated GPU of their choice. Also supported is NVIDIA and AMD CrossFireX 2/3-Way configurations. Included with this motherboard is an I/O Shield, 1 x COM port cable, 10 x SATA III 6 Gb/s cables, 1 x Supporting DVD, 1 x 3-Way SLI bridge, 1 x 4-Way SLI bridge, 1 x SLI bridge, 1 x Q-connector (2-in-1), 1 x 2-port USB 2.0 module, and 1 x RGB Strip Extension cable. General Features Built for Workstations - Four PCI Express 3.0 x16 Slots Enable Extreme Graphics Power
- The X99-E-10G WS can carry up to four dual-slot graphics cards. It supports 4-Way NVIDIA GeForce SLI and AMD CrossFireX x16 Link, making it an excellent choice for graphics professionals who depend on powerful graphics in areas such as design and modeling and medical research, plus processing-intensive simulations and rendering applications. In addition to graphics cards, extensive X99-E-10G WS expandability offers ample room for RAID cards, PCI Express-based solid state storage drives, video capture cards, and other components.
- Dual 10GbE LAN
- With built in dual Intel 10G Base-T networking (X550-AT2), the workstation board increases data throughput and improves efficiency. This supports high-density, high-bandwidth, and low-latency access-layer networks needed for extremely demanding applications, such as graphics or video production.
Performance - ASUS OC Socket
- Designed to improve performance, ASUS OC Socket utilizes extra pins to connect a proprietary circuit to contacts found on the land grid array (LGA). Combined with their customized UEFI, this feature enables higher DDR4 memory frequencies, lower latencies, and enhanced stability while overclocking, extending all the way to extreme overclocking conditions, such as liquid nitrogen (LN2). ASUS' OC Socket is 100% compatible with virtually all LGA 2011-v3 CPUs, ensuring a combination of overclocking performance and compatibility.
- Make Your Memory Go Faster
- Drive your memory frequencies to 3333 MHz and beyond. ASUS-exclusive T-Topology circuit design plus OC Socket provides memory-overclocking capabilities to unleash the full power of DDR4 by minimizing coupling noise and signal reflection. With equidistant memory channels, it delivers balanced control and powerful overclocking compatibility. ASUS works with almost every DDR4 memory vendor to ensure compatibility.
- 5-Way Optimization - One Click Overclock and Cooling
- One click takes care of all that complex tuning. Your PC is smart with ASUS 5-Way Optimization. It dynamically optimizes essential aspects of your system based on real-time use, so you get superb CPU performance, everyday energy savings, stable digital power, cool and quiet fans, and now even networking and audio settings that are tailored for the apps that you are using. In short, 5-Way Optimization ensures that your PC is ready for gaming, entertainment, productivity or just about anything else.
- TurboV Processing Unit (TPU) - CPU Performance Boost
- Unleash your PC's performance with a simple two-phase onboard switch or the ASUS AI Suite 3 utility. The TurboV Processing Unit (TPU) offers precise voltage control and advanced monitoring for the CPU and the graphics card, enabling freedom to adjust CPU frequencies and ratios for optimized performance and to exploit the potential out of your graphics card.
- Energy Processing Unit (EPU) - Energy Efficiency
- With the Energy Processing Unit (EPU), you'll enjoy real-time, system-wide power savings. EPU detects and adjusts power consumption according to the PC's needs - automatically. It can also reduce CPU wattage to a set level and deliver even more savings with Away Mode. This creates an extreme energy-saving scenario by shutting down unused extra I/O controllers and reduces the graphics cards' power level while you're away, so the PC consumes only the energy it needs.
- Flexible Cooling Controls for Air and Liquid
- ASUS X99 motherboards features advanced cooling capabilities that are controllable from both Fan Xpert 4 and UEFI.
- 3/4-pin fan auto detection
- Water pump header
- High amp (3A) fan header
- Smart fan IC protection
- Support for Extreme Quiet Mode
- DIGI+ Power Control
- Power control is an essential motherboard design. Intelligent CPU-power-draw detection with ASUS DIGI+ Power Control is a technology that fully complies with Intel VRD12.5 specifications, increasing overclocking potential, enhancing system stability, and improving power efficiency with superior flexibility and accurate control.
- Turbo App
- Intel's processors feature per-core tuning, and the ASUS Core app lets you exploit this feature by prioritizing specific applications so that their processing demands are met in the order you want, optimizing performance in the ways you need.
- UEFI BIOS
- This mouse-controlled graphical BIOS has been improved to make it more user-friendly. Whether you're a novice PC or a seasoned overclocker, the EZ and Advanced modes help you find your way, quickly and easily.
EZ Flash 3
Update the BIO via the Internet, and from within the BIOS.
S.M.A.R.T
Check up your storage devices' Self-Monitoring, Analysis, and Reporting Technology (S.M.A.R.T) logs to gauge reliability, and even determine if they're about to fail.
EZ Tuning Wizard - OC and RAID
Select your hardware and apply different scenarios to tune system performance, or streamline your RAID configuration for faster data retrieval and backups.
My Favorites
Quickly find tuning options and add preferred tools to the list - EZ Mode
- Intuitive Graphical Fan Control
Fine-tune individual fans simply by dragging a curve with the mouse.
EZ XMP
Improve your DRAM performance with a click.
SATA Information
View SATA port details for easy device recognition.
Fast Clock Adjustment
Use mouse controls to change the time and date. - Advanced Mode
- GPU POST
Recommendation for multi-VGA configuration and detailed information for selected ASUS graphics cards.
Secure Erase
Restore your SSDs to factory-fresh condition.
Last Modified Log
Track last change and save preferred profiles onto a USB drive.
SATA Port Renaming
Rename SATA ports for easy identification.
Aura (LED Control)
Customize your favorite RGB LED style direct from the BIOS. For Gamers and Professionals - 32 Gb/s U.2 & M.2 Onboard
- The workstation board fits 2.5" NVM Express SSDs with an on-board U.2 and M.2 (up to 2280) interface. This technology exploits the maximum PCI Express 3.0 x4 bandwidth of 32 Gb/s for SSD transfer speeds that are up to 5.3x faster than traditional SSDs.
- 10 Gb/s USB 3.1
- This workstation board has USB 3.1 connectivity built in with Type-A and Type-C ports for fast USB data transfers up to 10 Gb/s, or twice as fast USB 3.0. Type-C is the reversible socket for any-way-up convenience.
- SafeSlot
- SafeSlot is the PCIe slot reinvented by ASUS and engineered to provide greater retention and shearing resistance. Manufactured in a single step using an insert-molding process that integrates the slot with the fortifying metal for an inherently stronger slot, it is then firmly anchored to the PCB through additional solder points.
- Multi-GPU Support
- With support for both NVIDIA SLI and AMD CrossFireX 2/3-WAY configurations, this X99 motherboard enables multi-GPU setups so you can drive games at 4K and beyond.
- Crystal Sound 3
- Noise Isolation
There are separate layers for left and right tracks so that both channels deliver consistent and equal quality.
Audio Shielding
Ensures precision analog/digital separation and reduced multi-lateral interference
Clean Power
A power pre-regulator reduces power-input noise for more consistent performance.
Audio Enjoyment
An audio amplifier produces high quality sound for headphones and speakers. A de-pop circuit reduces start-up popping noises to audio outputs, and Japanese-made audio capacitors provide warm, natural, and immersive sound with clarity and fidelity. Home Server - ASUS HomeCloud
- ASUS HomeCloud lets you access your PC remotely, stream multimedia content to wherever you want, and manage all your stuff from anywhere - no matter where it's stored. It even turns your hard drive into private cloud storage, removing worries about storage limits. With HomeCloud, your PC becomes the gateway to your world.
- Digital PC Hub & Media Streamer
- Enjoy your PC's multimedia content from almost anywhere. Pipe music from your PC while sipping coffee in a café or sit back with friends and stream a favorite movie to a smart TV. With ASUS Media Streamer, your entertainment goes wherever you go.
Intel CPU and Chipset Features - Intel Core i7 X-Series/i7 Processor LGA2011-v3 Ready
- This motherboard supports Intel Core i7 X-Series/i7 processors in the LGA 2011-v3 package, with memory and PCI Express controllers integrated to support 4-channel (8 DIMM) DDR4 memory and 40/28 PCI Express 3.0/2.0 lanes.
- Intel X99 Express Chipset
- The Intel X99 Express Chipset is a single-chipset design that supports socket LGA 2011-v3 Intel Core i7 X-Series/i7 processors. It provides improved performance by utilizing serial point-to-point links, allowing increased bandwidth and stability. Additionally, X99 provides a maximum of 6 x USB 3.0 ports, 10 x SATA III 6 Gb/s ports, and 32 Gb/s M.2 support for faster data retrieval.
UPC: 889349405383 In the Box ASUS X99-E-10G WS LGA 2011-v3 CEB Motherboard I/O Shield 1 x COM Port Cable 10 x SATA III 6 Gb/s Cables 1 x 3-Way SLI Bridge 1 x 4-Way SLI Bridge 1 x SLI Bridge 1 x Q-Connector (2-in-1) 1 x 2-Port USB 2.0 Module 1 x Extension Cable for RGB Strips (31.5" / 80.0 cm) 1 x Supporting DVD Limited 3-Year Warranty More info from ASUS Table of Contents
|
Upload User Manual
Have you got an user manual for the ASUS X99-E-10G WS LGA 2011-v3 CEB Motherboard in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersASUS X99-E Specs | CPU | - Built for Intel Socket 2011-v3 Core i7 and Core i7 X-Series processors
- Supports Intel 14 nm CPUs
- Supports Intel Turbo Boost Max Technology 3.0
- Intel Socket 2011-v3 for Intel Xeon processor E5-1600 v3 product family
- Intel Socket 2011-v3 for Intel Xeon processor E5-2600 v3 product family
- Intel Socket 2011-v3 for Intel Xeon processor E5-1600 v4 product family
- Intel Socket 2011-v3 for Intel Xeon processor E5-2600 v4 product family | | Chipset | Intel X99 | | Memory | - 8 x DIMM, max. 128 GB DDR4 3333 (O.C.), 3200 (O.C.), 3000 (O.C.), 2800 (O.C.), 2666 (O.C.), 2400 (O.C.), 2400 (O.C.), and 2133 MHz non-ECC, unbuffered memory
- 8 x DIMM, max. 128 GB DDR4 2400/2133 MHz ECC, unbuffered memory
- 8 x DIMM, max. 128 GB DDR4 2400/2133 MHz ECC, Registered memory
- Quad Channel Memory Architecture
- Supports Intel Extreme Memory Profile (XMP)
* Hyper DIMM support is subject to the physical characteristics of individual CPUs | | Multi-GPU Support | Supports NVIDIA 4-Way SLI Technology
Supports AMD 4-Way CrossFireX Technology | | Expansion Slots | 7 x PCIe 3.0/2.0 x16 (single x16, dual x16/x16, triple x16/x16/x16, quad x16/x16/x16/x16, or seven x16/x8/x8/x8/x8/x8/x8) | | Storage | Intel X99 Chipset
1 x U.2 connector
1 x M.2 x4 Socket 3, with M Key, type 2260/2280 storage devices support (PCIe mode)
10 x SATA III 6 Gb/s ports
Intel Rapid Storage Technology support | | LAN | 2 x Intel X550-AT2 10 Gigabit LAN ports | | Audio | Realtek ALC1150 8-Channel High Definition Audio CODEC featuring Crystal Sound 3
- Supports Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- High quality 112 dB SNR stereo playback output (Line-out at rear) and 104 dB SNR stereo playback input (Line-in) | | USB Ports | Intel X99 Chipset
4 x USB 3.0/2.0 ports (four at the back panel)
2 x USB 3.0 connectors (two at mid-board, supports an additional four USB 3.0 ports, 19-pin)
2 x USB 2.0/1.1 connectors (two at mid-board, supports an additional four USB 2.0 ports)
ASMedia USB 3.1 Controller
2 x USB 3.1 ports (two at the back panel, Type-A & Type-C) | | Back I/O Ports | 1 x Optical S/PDIF out
8 x Audio jacks | | Internal I/O Ports | 1 x RGB Header
1 x TPM connector
1 x CPU Fan connector (1 x 4-pin)
1 x CPU OPT Fan connector (1 x 4-pin)
2 x Chassis Fan connectors (4-pin)
1 x S/PDIF out header
2 x 8-pin EATX 12 V Power connectors
1 x 6-pin EATX 12 V_1 Power connector
1 x 24-pin EATX Power connector
1 x EZ XMP switch
1 x Front panel connector
1 x System panel (Q-Connector)
1 x DRCT header
1 x MemOK! button
1 x CPU OV
1 x Power-on button
1 x Reset button
1 x Clear CMOS button
1 x SLI/CFX switch (2/3-WAY adjustments)
1 x USB BIOS Flashback button
1 x Water Pump header (4-pin)
1 x 3-pin CHASSIS (Chassis intrusion) connector
1 x COM port header
1 x High AMP Fan Header
1 x T_Sensor Connector | | BIOS | 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM BIOS 2.7, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information | | Manageability | WfM 2.0, DMI 2.7, WOL by PME, PXE | | Support Disc | Drivers
ASUS Utilities
EZ Update
Anti-virus software (OEM version) | | Operating System | Windows 10, 8.1 (64-bit), 7 (64-bit) | | Environment | Operating Temperature: 50 to 95°F / 10 to 35°C
Non-Operating Temperature: -40 to 158°F / -40 to 70°C
Non-Operating Humidity: 20 ~ 90% (non-condensing) | | Form Factor | CEB Form Factor
12.0 x 10.5" / 30.5 x 26.7 cm | | | | Package Weight | 5.7 lb | | Box Dimensions (LxWxH) | 13.2 x 11.6 x 3.2" |
