User Manual for Atdec Telehook TH-WH-PJ-FM Flush Projector Ceiling Mount Click to enlarge the picture
Contents of the user manual for the Atdec Telehook TH-WH-PJ-FM Flush Projector Ceiling
- Product category: Projector Mounts Atdec
- Brand: Atdec
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for Atdec Projector Mounts
|
User manual for the Atdec Telehook TH-WH-PJ-FM Flush Projector Ceiling contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any Atdec product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official Atdec user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a Atdec product will considerably shorten its lifespan!
|
Product description The white Telehook TH-WH-PJ-FM Flush Projector Ceiling Mount from Atdec is a low-profile ceiling mounting solution for low to medium weight projectors. It features a 2-piece construction for easy installation and offers extensive angle and positional adjustment. A movable set of arms provide universal mounting hole compatibility, while the good quality finish is designed to suit both home and office environments.
This mount comes with a mounting plate that attaches directly to the ceiling along with a bracket that attaches to the projector using the hardware included in the pack. The projector is lifted and slotted into place with a locking pin to prevent unauthorized removal. The projector bracket includes a gimbal mechanism that provides pitch, roll, yaw, and horizontal position adjustment to enable easy and precise screen alignment. Note: If you want to install this mount in a commercial or office environment, you may have to purchase a Ceiling Tile Insert (sold separately). Depending on the matrix configuration, these may be slotted in directly or sit above a tile to provide a secure attachment point with a neat and flexible finish. - Flexible mounting hole pattern suits a wide range of projectors
- Distance from Ceiling: 5" (127mm)
- 360° degree projector rotation
- Quick attachment/quick release mechanism
- All mounting hardware included
- Quick attachment / release mounting head (with security pin)
UPC: 881493002340 In the Box Atdec Telehook TH-WH-PJ-FM Flush Projector Ceiling Mount (White) 2 x 2" Extension Bracket 2 x 3" Extension Bracket 2 x 4" Extension Bracket 2 x 5.88" Extension Bracket Projector Mounting Screws & Washers 4 x Nylon Anchor Plug 4 x 14 Gauge Coach Screw 4 x 20mm Washer Limited 10-Year Warranty Brochure PDF 947.6kbrawqrccxvdftwavurqxysct Table of Contents
|
Upload User Manual
Have you got an user manual for the Atdec Telehook TH-WH-PJ-FM Flush Projector Ceiling Mount in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersAtdec TH-WH-PJ-FM Specs | Maximum Load Capacity | Accommodates a projector weighing up to 33 lb (15 kg) | | Material | Steel | | Mounting Reach | Hole: 5.13 to 15.75" (130.00 to 400.00 mm) | | Rotation | Around Pole: 360° | | Pitch Adjustment | ±40° | | Roll Adjustment | ±20° | | Adjustments | Positional: 3.0" (76.2 mm) | | Ceiling Offset | 5" (127 mm) | | Number of Studs Required | 1 | | | | Package Weight | 4.3 lb | | Box Dimensions (LxWxH) | 6.6 x 5.5 x 5.2" |
Rating100% users recommend this product to others. And what about you?
This product has already been rated by 35 owners. Add your rating and experience with the product.
