Product description The 12-Port DisplayPort Video Wall Media Player from ATEN is a PC-based media player that provides a suitable solution for multi-display applications such as digital signage, video walls, projection screens, and digital board installations. It supports video wall configurations with up to 12 displays and allows you to design creative video walls in various asymmetric layouts. Custom widgets allow you to add banners, video playback, flash media, images, and real-time clock displays over the screens. The advanced video wall features allow you to resize, layer (including picture in picture), span across multiple screens, and even rotate pictures and videos at 90° intervals.Multimedia files are uploaded and the system is set up from a computer connected across a network. With a built-in web interface and intuitive GUI (graphical user interface), access and configuration is simple and does not require extra software. The media player also features a scheduling function that helps you create detailed playlists days, weeks, or even months ahead.The VS1912 media player is equipped with an HDMI input port for routing an additional HDMI source, and USB 3.0 and USB 2.0 ports for importing profile settings and schedules. Bi-directional RS-232 serial ports will be enabled by a future firmware update, providing high-end system control, Together with these features, the media has the flexibility to meet the needs of various environments, including trade shows, lobbies, conference halls, shopping malls, and any other public space requiring video displays. - PC-based player for digital signage and video wall applications
- Allows a video wall with up to 12 displays
- Supports creative, asymmetric layouts (asymmetric layouts can be formed using displays at right angles only, i.e. portrait and landscape orientations)
- Advanced Video Wall - Pictures and videos can be resized, layered (including picture in picture), spanned across multiple screens, and rotated at 90° intervals.
- Upload system configuration and playback files easily through an intuitive web GUI, no additional software needed (Google Chrome required)
- Widgets display video, image, flash media, webpage, text, banner, clock, RSS, or RTSP (Real Time Streaming Protocol) over the screens
- Flexible scheduling and profiles for easy management of connections
- Two bi-directional RS-232 serial ports for high-end system control 1
Please Note: This feature will be enabled through a future firmware update. Please see the manufacturer's website for more information. close - 64GB storage capacity and 8GB DDR3 system memory
- 1 HDMI input port for more flexible media sourcing
- USB 3.0 and USB 2.0 ports for importing profile settings and schedules
- Locking mechanism included in DisplayPort cables and DVI adapter
- ESD protection for DisplayPorts
In the Box ATEN 12-Port DisplayPort Video Wall Media Player 12 x DisplayPort to DVI Adapter Power Cord Mounting Kit Limited 3-Year Warranty Guides & Manuals csydxsrwzxvteytasssres Table of Contents
|
Upload User Manual
Have you got an user manual for the ATEN 12-Port DisplayPort Video Wall Media Player in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Download User ManualThe user manual for the ATEN 12-Port DisplayPort Video Wall Media Player can be downloaded in PDF format at the link stated below.
Technical parametersATEN VS1912 Specs | Video Input | 1 x HDMI Type A female | | Video Output | 12 x DisplayPort 1.1 female | | Video | Maximum Data Rate: 8.64 Gb/s (2.7 Gb/s per lane)
Maximum Pixel Clock: 340 MHz (with DP to DVI active adapter)
Compliance: HDMI (3D, Deep Color)
DisplayPort 1.1 | | Audio | Output: 1 x 3.5 mm stereo jack female | | Control | RS-232
Connector: 2 x DB-9 Female (black)
Baud Rate: 38400 to 19200
Hardware and software flow control
Ethernet: 2 x RJ-45 female | | USB | 2 x USB 3.0 female
4 x USB 2.0 female | | Power | Connectors: 1 x 3-prong AC socket
Maximum Input Power Rating: 100 to 240 VAC, 50/60 Hz, 3 A
Consumption: 120 VAC: 400 W
230 VAC: 400 W | | Fan | Airflow: 28.8 cfm (maximum in free air)
Operating voltage: 6 to 12 VDC
Operating temp: 14 to 149°F (-10 to 65°C) | | Storage Capacity | 64 GB mSATA | | System Memory | 8 GB DDR3 | | Operating Temperature | 32 to 104°F (0 to 40°C) | | Storage Temperature | -4 to 140°F (-20 to 60°C) | | Humidity | 0 to 80% RH, non-condensing | | Housing | Metal | | Dimensions (L x W x H) | 16.93 x 10.63 x 1.73" (43 x 27 x 4.4 cm) | | Weight | 9.3 lb (4.22 kg) |
