Product description Provided by third party: The VM7104 4-Port VGA input board offers an easy way to route 4 VGA video and audio sources. The VM7104 supports RGBHV / RGBS/ Y CbCr/ YPbPr input signals; stereo audio that can be embedded into HDMI audio output. The board is built with a hot-swappable design that is compatible with the VM1600, so that the unit doesn't need to be powered off when the board is changed.
- Key Features
-
- Connects VGA or component inputs
- Supports RGBHV / RGBS/ YCbCr/ YPbPr input signals
- Hot-swappable design for easy integration of I / O boards
- Compatible with the VM1600 and can be mixed with any modular output boards for optimum flexibility
Table of Contents
|
Upload User Manual
Have you got an user manual for the ATEN 4-Port VGA Input Board for VM1600 Modular Matrix Switch in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersATEN VM7104 Specs | | | Device Type | Video/audio extender | | Form Factor | Plug-in module | | | | Ports Qty | 4 | | Connectivity Technology | Wired | | Max Resolution | 1920 x 1200 | | Max Video Bandwidth | 300 MHz | | Features | HDBaseT technology, metal housing | | | | Interfaces | 4 x VGA (input) - HD-15 female
4 x audio (input) female
1 x serial - DB-9
1 x Ethernet
1 x RS-232/422/485 | | | | Power Device | Internal power supply | | Power Consumption Operational | 7.1 Watt | | | | Width | 9.4 in | | Depth | 13.9 in | | Height | 0.9 in | | Weight | 19.75 oz | | | | Min Operating Temperature | 32
