User Manual for ATEN CE350 PS 2 KVM Extender Click to enlarge the picture
Contents of the user manual for the ATEN CE350 PS 2 KVM Extender
- Product category: Mice Accessories ATEN
- Brand: ATEN
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ATEN Mice Accessories
|
User manual for the ATEN CE350 PS 2 KVM Extender contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ATEN product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ATEN user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ATEN product will considerably shorten its lifespan!
|
Product description The Aten CE350 PS/2 KVM Extender is a PS/2 based KVM Extender with automatic signal compensation and RS-232 serial functionality, allowing access to a computer system from a remote PS/2 console (PS/2 keyboard, monitor, and PS/2 mouse). Because it allows access to a computer system from a remote console, the CE350 is geared towards use in any type of installation where you need to place the console where it is conveniently accessible, but you want the system equipment to reside in a safe location - away from the dust and dirt of a factory floor, or the harsh environmental influence of a construction site, for example. This allows you to deploy system equipment over distances up to 500'. - Local and Remote Units connect at distances up to 500 feet using Cat 5e cable
- Adjustable gain control - manually adjust signal strength to compensate for distance
- Dual console operation - control your system from both the local and remote PS/2 keyboard, mouse and monitor consoles
- Built-in ASIC for greater reliability and compatibility
- Auto Signal Compensation (ASC) and storage of settings
- RS-232 serial ports - connect to a serial terminal, or serial devices such as touchscreens and barcode scanners (Baud rate 115200 bps)
- Audio Enabled - supports stereo speakers and microphone
- Pushbutton operating mode selection (Local Unit only) - select between Local and Auto operating modes, with the press of a single button
- Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV) and 2KV surge protection
- Superior video quality - 1920 x 1200 @ 60Hz 100', 1600 x 1200 @ 60Hz 500'
- No loss in audio quality at 500 feet
- Supports Wide Screen formats Note: The EDID data for a widescreen is sent from the local video output port. For widescreen modes and displays connect the monitor to the local video output port or use an optional EDID emulator.
- Supports VGA, SVGA, SXGA (1280 x 1024), UXGA (1600 x 1200), WUXGA (1920 x 1200) and multisync monitors; local monitor supports DDC; DDC2; DDC2B
- no software required - connecting cables to the devices is all it takes
UPC: 672792002410 In the Box ATEN CE350 PS/2 KVM Extender 6' Custom PS/2 KVM Cable Set 2 x Power Adapter Rack Mount Kit 2 x Grounding Wires Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the ATEN CE350 PS 2 KVM Extender in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersATEN CE350 Specs Supported Operating Systems | Windows: 2000, 2003, 2008, XP, Vista, 7 Linux: Redhat 9.0 and up; SuSE 10, 11.1 and up; Debian 3.1, 4.0; Ubuntu 7.04, 7.10 UNIX: FreeBSD 5.5, 6.1, 6.2 Novell: Netware 6.0 and up | Housing Material | Metal | Console Connectors | Mouse: 1 x 6-pin Mini-DIN female on both local and remote Keyboard: 1 x 6-pin Mini-DIN female on both local and remote Monitor: 1 x VGA female on both local and remote | CPU Connectors | Keyboard, mouse, and monitor: 1 x SPHD-17 female on local Audio: 1 x 3.5 mm mini stereo jack Microphone: 1 x 3.5 mm mini stereo jack | Connectors | RS-232: 1 x D89 on both local and remote | Cable Connection | Input: 1 x RJ45 (remote) Output: 1 x RJ45 (Local) | LED Indicator | 1 x on both local and remote | Switches | Port selection: 1 x pushbutton Picture compensation: 1 x pushbutton | Power | Voltage: 5.3VDC (local and remote) Amps: 700mA local, 1.3A remote | Power Consumption (max) | Local: 3.38W - 11.5 BTU Remote: 6.43W - 22 BTU | Operating Temperature & Humidity | 32 - 122°F (0 - 50°C), RH 0 - 80% non-condensing | Storage Temperature | -4 - 140°F (-20 - 60°C) | Dimensions (W x H x D) | Local: 7.8 x 1.0 x 3.2" (19.8 x 2.5 x 8.1 cm) Remote: 7.8 x 1.0 x 3.2" (19.8 x 2.5 x 8.1 cm) | Weight | Transmitter: 17.28 oz (0.49 kg) Receiver: 16.93 oz (0.48 kg) | | Package Weight | 4.25 lb | Box Dimensions (LxWxH) | 12.9 x 8.4 x 3.8" |
