User Manual for ATEN UC4852 2-Port USB to Serial RS-422 485 Hub Click to enlarge the picture
Contents of the user manual for the ATEN UC4852 2-Port USB to Serial
- Product category: Serial RS-422/RS-232 Cards ATEN
- Brand: ATEN
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ATEN Serial RS-422/RS-232 Cards
|
User manual for the ATEN UC4852 2-Port USB to Serial contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ATEN product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ATEN user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ATEN product will considerably shorten its lifespan!
|
Product description The UC4852 2-Port USB to Serial RS-422/485 Hub from ATEN provides an external plug-and-play RS-422 and RS-485 serial connection for connecting handheld computing devices to computers, laptops, and notebooks. The hub is designed to offer a cost-effective solution for quickly and simply adding RS-422 and RS-485 serial ports with data transfer rates of up to 115.2 kb/s for each serial port. As the hub is hot-swappable, no IRQ, DMA, or I/O address resources are needed and each port can independently switch between RS-422 and RS-485. - Supports automatic handshake mode
- Up to 115.2 kb/s data transfer rate for each serial port
- Dual data buffers for each upstream and downstream data transfer
- Supports hot-swapping and plug-and-play
- Built-in 16KV ESD protection
- Supports both bus power and external power
UPC: 672792123580 In the Box ATEN UC4852 2-Port USB to Serial RS-422/485 Hub USB Cable Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the ATEN UC4852 2-Port USB to Serial RS-422 485 Hub in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersATEN UC4852 Specs | Number of Device Connections | 2 | | Connectors | 1 x USB Type B female (white)
2 x DB-9 male (black)
1 x DC jack | | LEDs | Port Status: 2 (green)
Power: 1 (orange) | | Max Data Transfer Rate | 115.2 kb/s | | FIFO | 16-byte | | USB Specification | USB 1.1 compliant, USB 2.0 compatible | | RS-232 Pin Configuration | TXD+/-, RxD+/-, RTS+/-, CTS+/-,GND | | Data Bits | 5, 6, 7, 8 | | Stop Bits | 1, 1.5, 2 | | Power Mode | Bus powered, use of power adapter is optional | | Power Consumption | 0.9 W | | Temperature & Humidity | Operating Temp: 32 to 122°F / 0 to 50°C
Storage Temp: -4 to 140°F / -20 to 60°C
Humidity: 0 to 80% RH, non-condensing | | OS Support | Microsoft 2000/2003/XP/NT | | Dimensions (LxWxH) | 4.9 x 3.1 x 1.0" / 12.5 x 8.0 x 2.5 cm | | Weight | 0.66 lb / 0.30 kg | | | | Package Weight | 1.35 lb | | Box Dimensions (LxWxH) | 9.5 x 6.3 x 2.4" |
