Product description The ATEN UE350A USB 3.0 Extender Cable is an audio/video signal extension device compatible with ATEN Cat 5 Audio/Video splitters. It extends the audio/video transmission range an extra 500' (150 m) over Cat 5e (or higher) cables. The use of an additional repeater means the audio/video signals can be transmitted over even longer distances, up to 1470 feet (450m). Furthermore, for longer distance installations where video signals may degrade, the VB552 has adjustable video gain and compensation controls to provide sharpest video quality. An IR remote control provides picture control at the remote site. It is rack-mountable, with two RS-232 channels on the unit for selection, and support for high video resolutions, the VB552 is suitable to extend the range of your A/V and serial transmissions in any installation environment requiring VESA FDMI mount standards. -
- Uses Cat 5e cable to extend audio/video signal
- Extends the transmission range an extra 150m
- High-quality video - up to 1920x1200@60Hz at 100 feet (30m), 1600x1200@60Hz at 500 feet (150m), 1280x1024@60Hz at 650 feet (200m)
- Audio and serial enabled
- Two gain control modes for sharpest picture quality
- Video gain and compensation adjustable via OSD
- IR receiver for quick and easy video quality adjustment
- IR remote control for screen on/off and video adjustment at remote site
- Provides two RS-232 channels for selection
- Follows VESA FDMI mount standard
- Supports DDC for the local monitor
- Supports VGA, SVGA, XGA, SXGA, UXGA and multisync monitors
- For use in combination with VS1504/VS1508 Audio/ Video splitter
UPC: 672792100925 In the Box ATEN VB552 VGA/Audio Cat5e/6 Repeater with Dual Outputs Limited 2-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the ATEN VB552 VGA Audio Cat5e 6 Repeater with Dual Outputs in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersATEN VB552 Specs | Connectors | Video Output: 2 x HDB-15 Female (Blue)
Audio Output: 1 x Mini Stereo Jack Female (Green)
RS-232: 2 x DB-9 Male (Black)
Power: 1 x DC Jack
Link: 2 x RJ-45 Female
| | Switches | Picture Compensation: 2 x pushbutton | | LEDs | Power On: 1x orange
On Line: 1x green
| | Video Resolution | 1920 x 1200 @ 60Hz at 100' / 33 m 1600x1200@60Hz at 500' / 165 m | | Cable Distance | 500' / 165 m | | Power | Voltage: 5.3 VDC
Amps: 900 mA
Power consumption: 4.77 W -- 16.3 BTU/Hr
Power Adaptor Part# for North America: 0AD8-0605-24EG | | Environment | Operation Temperature: 32 to 122°F (0 to 40°C)
Storage Temperature: -4 to 140°F (-20 to 60°C)
Humidity: 0 to 80% RH, Non-condensing
| | Material | Plastic housing | | Dimensions | 5.5 x 1.1 x 3.2" / 13.9 x 2.7 x 8.1 cm | | Weight | 2.3 lb / 1 kg |
