User Manual for ATEN VC182 VGA to HDMI Converter with Scaler Click to enlarge the picture
Contents of the user manual for the ATEN VC182 VGA to HDMI Converter
- Product category: Signal Converters ATEN
- Brand: ATEN
- Description and content of package
- Technical information and basic settings
- Frequently asked questions – FAQ
- Troubleshooting (does not switch on, does not respond, error message, what do I do if...)
- Authorized service for ATEN Signal Converters
|
User manual for the ATEN VC182 VGA to HDMI Converter contain basic instructions
that need to be followed during installation and operation.
Before starting your appliance, the user manual should be read through carefully.
Follow all the safety instructions and warnings, and be guided by the given recommendations.
User manual is an integral part of any ATEN product,
and if it is sold or transferred, they should be handed over jointly with the product.
Following the instructions for use is an essential prerequisite for protecting
health and property during use, as well as recognition of liability on the part of the manufacturer
for possible defects should you make a warranty claim. Download an official ATEN user manual in which you will find instructions on how to install, use, maintain and service your product.
And do not forget – unsuitable use of a ATEN product will considerably shorten its lifespan!
|
Product description The VC182 VGA to HDMI Converter with Scaler from ATEN offers an easy and convenient way of converting VGA input signals into digital video (HDMI). It carries a scaling engine that converts the video resolution to give you an optimal image quality. You can operate the VC182 via the built-in On-Screen Display (OSD), which can be controlled through accessible front panel pushbuttons. - Converts VGA signals to HDMI output
- Supports analog/digital audio
- Optimum video quality of up to 1080p, 1920 x 1200
- Built-in scaler engine that converts various input video resolutions into the display's native resolution, adjusting picture ratio automatically for viewing comfort
- 3D de-interlacing increases image clarity for optimal viewing quality by processing and scanning digital video signals
- Built-in OSD function for video and system settings configuration
- Integrated video noise reduction
- Integrated color engine for automatic picture quality/color adjustment and enhancement
- Automatically detects video input signals
- LED indication of power status and source device
- No software installation is required, eliminating incompatibility and installation issues
- Device configuration using a utility tool via mini USB port
- Supports 16:9 and 4:3 video aspect ratios
- Multiple selectable video resolutions
UPC: 672792005404 In the Box ATEN VC182 VGA to HDMI Converter with Scaler Power Adapter Software CD Limited 3-Year Warranty Table of Contents
|
Upload User Manual
Have you got an user manual for the ATEN VC182 VGA to HDMI Converter with Scaler in electronic form? Please send it to us and help us expand our library of instruction manuals.
Thank you, too, on behalf of other users.
To upload the product manual, we first need to check and make sure you are not a robot. After that, your "Submit Link" or "Upload File" will appear.
Technical parametersATEN VC182 Specs | | | Interface | 1 x HDB-15 female (blue) | | Impedance | 75 ohms | | | | Interface | 1 x HDMI type A female (black) | | Impedance | 100 ohms | | | | Maximum Pixel Clock | 165 MHz | | Resolutions Supported | Up to 1080p | | Scaler Resolutions | 480p; 480i; 576p; 576i;
800 x 600; 1024 x 768; 1280 x 720; 1280 x 1024;
1360 x 768; 1440 x 900; 1400 x 1050;
1600 x 1200; 1680 x 1050; 1080i;
1080p; 1920 x 1200 | | | | Input | Analog: 1 x 3.5 mm mini stereo jack (black)
Digital: 1 x RCA (yellow) | | Power | Connector: 1 x DC jack
Consumption: 5 VDC, 5 W | | | | Operating Temperature | +32 to +104°F (0 to +40°C) | | Storage Temperature | -4 to +140°F (-20 to +60°C) | | Humidity (Non-condensing) | 20 to 90% RH | | | | Casing | Metal | | Dimensions (L x W x H) | 4.33 x 3.26 x 1.10" (11.00 x 8.30 x 2.80 cm) | | Weight | 10.93 oz (310.00 g) | | | | Package Weight | 1.4 lb | | Box Dimensions (LxWxH) | 9.4 x 6.4 x 2.5" |
